Introduction The Siemens 6AG4104-4DA02-3XX0 is a SIMATIC IPC547G industrial rack PC designed for manufacturing, automation, and industrial data-processing applications. It combines an Intel Core i7-6700 processor, 4 GB DDR4 memory, and a 1 TB internal hard drive in a 19-inch, 4U rack-mounted enclosure.
One important feature of this configuration is its operating-system-free delivery. This allows system integrators to select and install a suitable software environment according to existing industrial applications, licensing arrangements, and operational requirements.
The IPC547G also provides seven expansion slots, dual Gigabit Ethernet connectivity, and integrated hardware monitoring. These capabilities make it a practical choice for industrial installations requiring configurable computing performance, additional interface options, and integration with established automation infrastructure.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Model Number
6AG4104-4DA02-3XX0
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Intel Core i7-6700
Processor Cores / Threads
4 cores / 8 threads
Base Frequency
3.4 GHz
Maximum Turbo Frequency
4.0 GHz
Processor Cache
8 MB
Chipset
Intel H110
Installed Memory
4 GB DDR4 SDRAM
Memory Configuration
1 × 4 GB, Single Channel
Maximum Memory
64 GB
Storage
1 × 1 TB Internal HDD
Graphics
Integrated Intel HD Graphics 530
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Display Interfaces
1 × DisplayPort 1.2, 1 × DVI-D
Additional Interfaces
2 × PS/2, Audio
Serial Interface
COM2
Parallel Interface
LPT
Expansion Slots
5 × PCI Express, 2 × PCI
Optical Drive
DVD±RW Slim
Monitoring Functions
Temperature Monitoring, Fan Monitoring, Watchdog
Power Supply
100–240 V AC
Operating System
Without Operating System
Enclosure
Blue-Chromated Industrial Enclosure
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Net Weight
Approximately 17 kg; configuration-dependent
Recommended Related Models Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA01-0BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 4 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA01-0GX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 4 GB RAM, 1 TB HDD, Windows Server 2012 R2
6AG4104-4DC22-0EX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7 Configuration with SSD Storage
Popular Related Models Model Number
Product Name
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 4 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4CB10-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5 Configuration with Dual HDD Storage
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 8 GB RAM, 480 GB SSD, Redundant Power Supply
6AG4104-4GN16-4BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 8 GB RAM, RAID 1 Storage
Applications - Industrial Automation and Process Supervision: Provides a centralized computing platform for industrial automation software, PLC communication, equipment monitoring, and supervisory control applications.
- Manufacturing Data Processing: Supports production information collection, operational data processing, and reporting across manufacturing environments.
- HMI and SCADA Integration: Runs compatible industrial visualization and supervisory applications, helping operators monitor equipment status and manage production information.
- Machine Integration and Inspection: Supports compatible expansion cards for industrial measurement, specialized communication interfaces, and machine-monitoring applications.
- Industrial Control Room Operations: Its 19-inch rack-mounted design makes it suitable for centralized computing installations, manufacturing control rooms, and industrial equipment racks.
Advantages - Intel Core i7 Processing Performance: Equipped with an Intel Core i7-6700 processor featuring four cores, eight threads, a 3.4 GHz base frequency, and up to 4.0 GHz Turbo frequency.
- Balanced Memory Configuration: The installed 4 GB DDR4 SDRAM provides a basic computing configuration for compatible industrial applications, with additional memory expansion available subject to platform requirements.
- Integrated 1 TB Storage: The internal hard drive provides storage capacity for operating-system files, industrial applications, production records, and local data management.
- Flexible Expansion Architecture: Five PCI Express slots and two PCI slots allow integration of compatible communication cards, measurement equipment, and specialized industrial peripherals.
- Industrial Monitoring and Connectivity: Dual Intel Gigabit Ethernet interfaces, temperature monitoring, fan monitoring, and watchdog functionality support system integration and maintenance.
Technical FAQs Q1. Which processor is installed in the Siemens 6AG4104-4DA02-3XX0?
This model uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, a maximum Turbo frequency of 4.0 GHz, and 8 MB cache.
Q2. What motherboard chipset does this model use?
It uses an Intel H110 chipset motherboard with integrated DisplayPort and DVI-D connectivity. The motherboard also provides USB 3.0 and USB 2.0 interfaces.
Q3. Can the system communicate with Siemens SIMATIC PLCs?
Yes. It supports communication with compatible SIMATIC controllers through Ethernet interfaces and suitable engineering or runtime software. The communication protocol depends on the installed application.
Q4. Does the IPC547G support PROFINET?
PROFINET communication can be implemented using compatible software and network configurations. The required drivers and communication components depend on the intended automation application.
Q5. Which expansion cards are compatible with this model?
The system provides five PCI Express slots and two PCI slots. Compatible cards can support additional network interfaces, data acquisition, measurement, and specialized industrial functions.
Q6. Does this model support memory upgrades?
Yes. The IPC547G platform supports DDR4-2133 SDRAM and a maximum memory capacity of 64 GB. Memory upgrades should follow the motherboard's supported module and configuration requirements.
Q7. What network interfaces are provided?
The system includes two Intel Gigabit Ethernet ports with RJ45 connectors. These support industrial network communication and connections to compatible controllers and supervisory systems.
Q8. Does the system include an operating system?
The 6AG4104-4DA02-3XX0 configuration is supplied without a preinstalled operating system. Users can select a compatible operating system according to application requirements and hardware driver availability.
Q9. What diagnostic functions are available?
The IPC547G includes temperature and fan monitoring, watchdog functionality, and card-retention features. These functions help maintenance teams monitor hardware conditions and investigate system faults.
Q10. Can the IPC547G operate continuously in industrial environments?
It is designed for industrial computing applications. Reliable operation requires suitable environmental conditions, adequate ventilation, regular cooling-system inspections, and maintenance according to the operating instructions.
