Introduction The Siemens 6AG4104-4DA02-3XX3 is a SIMATIC IPC547G industrial rack PC configured for manufacturing, automation, and industrial data-processing applications. It combines an Intel Core i7-6700 processor, 4 GB DDR4 memory, and a 1 TB internal hard drive in a 19-inch, 4U rack-mounted enclosure.
A notable feature of this configuration is its operating-system-free delivery, giving system integrators greater flexibility when selecting software for existing industrial applications. It also includes onboard graphics, serial and parallel connectivity, and an optical DVD±RW drive.
With seven expansion slots and dual Gigabit Ethernet interfaces, the IPC547G provides a flexible foundation for industrial visualization, machine integration, and production monitoring. Its hardware architecture makes it a practical option for facilities maintaining established automation systems or developing customized industrial computing installations.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Model Number
6AG4104-4DA02-3XX3
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Intel Core i7-6700
Processor Cores / Threads
4 cores / 8 threads
Base Frequency
3.4 GHz
Maximum Turbo Frequency
4.0 GHz
Processor Cache
8 MB
Chipset
Intel H110
Installed Memory
4 GB DDR4 SDRAM
Memory Arrangement
1 × 4 GB, Single Channel
Maximum Memory
Up to 64 GB, platform-dependent
Storage
1 × 1 TB Internal HDD
Graphics
Integrated Graphics
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Display Interfaces
1 × DisplayPort 1.2, 1 × DVI-D
Additional Interfaces
2 × PS/2, Audio
Serial Interface
COM2
Parallel Interface
LPT
Expansion Slots
5 × PCI Express, 2 × PCI
Optical Drive
DVD±RW Slim
Monitoring Functions
Temperature Monitoring, Fan Monitoring, Watchdog
Power Supply
100–240 V AC
Operating System
Without Operating System
Enclosure
Blue-Chromated Industrial Enclosure
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
Approximately 17 kg; configuration-dependent
Recommended Related Models Model Number
Product Name
6AG4104-4DA02-3XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 4 GB RAM, 1 TB HDD, Without Operating System
6AG4104-4DA04-3XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 4 GB RAM, 1 TB HDD, Redundant Power Supply
6AG4104-4DA12-0BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA12-3EX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise 2016 LTSB
Popular Related Models Model Number
Product Name
6AG4104-4CH02-3XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 4 GB RAM, 1 TB Removable HDD, Without Operating System
6AG4104-4DA11-1EX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, Windows 10 IoT Enterprise 2016 LTSB
6AG4104-4DA22-0BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 16 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DB21-0XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 16 GB RAM, Dual 1 TB HDD, Without Operating System
Applications - Industrial Automation and Process Control: Provides a centralized computing platform for industrial automation software, PLC communication, equipment supervision, and process-monitoring applications.
- Manufacturing Data Management: Supports production data collection, local processing, operational reporting, and communication between shop-floor equipment and higher-level information systems.
- HMI and SCADA Operations: Runs compatible industrial visualization and supervisory applications, allowing operators to monitor production conditions and access equipment information.
- Machine Integration and Inspection: Supports compatible expansion cards for industrial measurement, specialized communication interfaces, and machine-monitoring applications.
- Industrial Control Room Systems: Designed for rack-based computing installations where centralized equipment management, flexible expansion, and convenient maintenance are important.
Advantages - Intel Core i7 Processing Performance: Features the Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, and up to 4.0 GHz Turbo frequency.
- Flexible Memory Configuration: Includes 4 GB DDR4-2133 SDRAM in a single-channel arrangement, providing a defined starting configuration with platform-supported upgrade options.
- Integrated 1 TB Storage: The internal hard drive provides space for operating-system files, industrial applications, production records, and local data storage.
- Versatile Expansion Architecture: Five PCI Express slots and two PCI slots accommodate compatible communication cards, measurement devices, and specialized industrial peripherals.
- Industrial Connectivity and Monitoring: Dual Intel Gigabit Ethernet interfaces, temperature monitoring, fan monitoring, and watchdog functionality support system integration and maintenance.
Technical FAQs Q1. Which processor is installed in the Siemens 6AG4104-4DA02-3XX3?
This configuration uses an Intel Core i7-6700 processor featuring four cores, eight threads, a 3.4 GHz base frequency, up to 4.0 GHz Turbo frequency, and 8 MB cache.
Q2. What motherboard chipset does this model use?
It uses an Intel H110 chipset motherboard, providing integrated network, display, USB, and peripheral connectivity for the industrial computing platform.
Q3. Can the IPC547G communicate with Siemens SIMATIC PLCs?
Yes. Compatible SIMATIC controllers can communicate through the integrated Ethernet interfaces using appropriate engineering software, runtime applications, and communication drivers.
Q4. Does this model support PROFINET communication?
PROFINET communication can be implemented through compatible software and network configurations. The necessary components depend on the intended communication role and automation architecture.
Q5. Which expansion cards are supported?
The system provides five PCI Express slots and two PCI slots. Compatible cards can provide additional communication, measurement, data-acquisition, and specialized industrial functions.
Q6. Can the installed memory be upgraded?
Yes. The IPC547G platform supports DDR4-2133 SDRAM and memory expansion up to 64 GB, subject to supported module configurations and motherboard requirements.
Q7. What network interfaces are available?
The system provides two Intel Gigabit Ethernet interfaces with RJ45 connectors. These support connections to industrial networks, automation controllers, and supervisory systems.
Q8. Which operating system is supplied with this configuration?
The 6AG4104-4DA02-3XX3 configuration is supplied without a preinstalled operating system. A compatible operating system can be selected according to application, licensing, and driver requirements.
Q9. What diagnostic functions are integrated into the IPC547G?
The platform includes temperature and fan monitoring, watchdog functionality, and system status indicators to assist with hardware supervision and troubleshooting.
Q10. Can this industrial PC support continuous production applications?
The IPC547G is designed for industrial computing environments. Reliable operation requires suitable ambient conditions, sufficient airflow, appropriate software configuration, and regular preventive maintenance.
