Introduction The Siemens 6AG4104-4DA11-0AX0 belongs to the SIMATIC IPC547G industrial rack PC family, a platform developed for demanding industrial computing and automation environments.
Designed around a 19-inch, 4U rack architecture, the IPC547G combines expandable hardware interfaces, industrial Ethernet connectivity, and integrated diagnostic functions. Its architecture supports manufacturing applications such as production monitoring, process visualization, machine integration, and centralized data processing.
The platform is particularly useful for system integrators who require additional expansion capacity for industrial communication and measurement equipment. Its configurable memory and storage architecture also provides flexibility when adapting computing resources to different operational workloads.
For replacement projects and new industrial installations, the 6AG4104-4DA11-0AX0 should be evaluated against the required processor, motherboard, storage, operating-system, and power-supply specifications. Confirming these details before ordering helps ensure a suitable fit within the existing automation environment.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Order Number
6AG4104-4DA11-0AX0
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Exact configuration requires verification
Supported Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon, depending on variant
Chipset
Intel H110 or C236, depending on motherboard
Memory Technology
DDR4-2133 SDRAM
Maximum Memory
64 GB
Storage
HDD / SSD, configuration-dependent
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
USB 3.0 and USB 2.0, motherboard-dependent
Display Interfaces
DisplayPort 1.2 and DVI-D
Additional Interfaces
PS/2, Audio
Expansion Slots
5 × PCI Express, 2 × PCI
Storage Options
HDD, SSD, selected RAID configurations
Monitoring Functions
Temperature monitoring, fan monitoring, watchdog
Power Supply
100–240 V AC
Operating System
Requires exact order-code verification
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short-Enclosure Dimensions
481.4 × 176.6 × 356.6 mm, where applicable
Net Weight
15–23 kg, depending on installed equipment
Recommended Companion Models Model Number
Product Name
6AG4104-4DA11-0BX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4HA12-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, C236 Chipset
6AG4104-4DA22-0HX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 16 GB RAM, 1 TB HDD, Windows Server 2016
Popular Related Models Model Number
Product Name
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 4 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DB12-0XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, Dual 1 TB HDD
6AG4104-4DA12-0BX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7 Configuration, Windows-Based Configuration
6AG4104-4DC22-0EX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7 Configuration with SSD Storage
Applications - Industrial Automation and Production Control: Provides a centralized computing platform for automation software, PLC communication, equipment monitoring, and production supervision.
- Manufacturing Data Management: Supports production data collection, local processing, and reporting, helping industrial operators maintain better visibility into manufacturing operations.
- HMI and SCADA Integration: Runs compatible visualization and supervisory applications for monitoring machine conditions, process parameters, and production performance.
- Machine Vision and Data Acquisition: Supports compatible PCI Express expansion cards for industrial measurement, specialized interfaces, and machine-monitoring equipment.
- Industrial Control Room Deployment: Its 19-inch rack-mounted architecture is suitable for centralized installations requiring organized equipment integration and convenient maintenance access.
Advantages - Intel Core i7 Processing: The IPC547G configuration family supports the Intel Core i7-6700 processor, offering four cores, eight threads, and a maximum Turbo frequency of 4.0 GHz.
- Flexible Memory Expansion: DDR4-2133 memory architecture supports configurations up to 64 GB, providing room for more demanding industrial applications.
- Extensive Hardware Integration: Five PCI Express slots and two PCI slots accommodate compatible communication, measurement, and specialized industrial expansion cards.
- Dual Gigabit Network Interfaces: Two Intel Gigabit Ethernet ports support connections to automation controllers, industrial networks, and supervisory systems.
- Integrated System Monitoring: Temperature and fan monitoring, watchdog functionality, and card-retention features support maintenance and hardware supervision.
Technical FAQs Q1. Which processor is compatible with the SIMATIC IPC547G platform?
The IPC547G supports several processor configurations, including Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5. The exact processor for 6AG4104-4DA11-0AX0 should be verified against its individual order-code configuration.
Q2. What memory technology does this industrial PC use?
The platform uses DDR4-2133 SDRAM and supports memory capacities from 4 GB to 64 GB, depending on the installed motherboard and memory arrangement.
Q3. Does the IPC547G support dual-channel memory?
Yes. Dual-channel operation is supported when compatible memory modules are installed in the appropriate configuration.
Q4. Can this system communicate with Siemens S7 PLCs?
Yes. It can communicate with compatible SIMATIC S7 controllers through Ethernet using appropriate Siemens engineering software, runtime applications, and communication drivers.
Q5. Is PROFINET communication available?
PROFINET communication can be implemented using compatible software and network interfaces. Configuration depends on the application and the communication role assigned to the industrial PC.
Q6. What expansion interfaces are available?
The system provides five PCI Express slots and two PCI slots. These accommodate compatible industrial Ethernet cards, measurement devices, communication modules, and other specialized peripherals.
Q7. Does the IPC547G support RAID functionality?
Selected IPC547G configurations support RAID 1 and RAID 5, depending on the motherboard, storage controller, and installed drives.
Q8. Can the system use SSD storage instead of conventional HDDs?
Yes. The IPC547G family supports compatible SSD configurations, including selected removable-drive and RAID arrangements. The available storage options depend on the particular order variant.
Q9. What hardware monitoring capabilities are integrated?
The platform includes temperature and fan monitoring, watchdog functionality, and system status indicators. These features assist with preventive maintenance and hardware diagnostics.
Q10. Is the IPC547G suitable for upgrading an existing industrial control system?
Yes, provided the processor, operating system, expansion interfaces, storage configuration, and application software are compatible with the existing installation. A complete hardware and software compatibility assessment is recommended before replacement.
