Introduction The Siemens 6AG4104-4DA11-0CX3 belongs to the SIMATIC IPC547G industrial rack PC family, developed for industrial computing, manufacturing operations, and automation-related applications.
The IPC547G combines a 19-inch, 4U rack-mounted design with extensive hardware expansion capabilities. Its architecture accommodates industrial communication cards, measurement equipment, and specialized peripherals, making it suitable for applications that require more than standard office computing functionality.
With dual Intel Gigabit Ethernet connectivity, integrated hardware monitoring, and multiple expansion interfaces, the platform offers flexibility for industrial system integration. It can serve as a computing foundation for compatible HMI applications, SCADA systems, production data processing, and machine-monitoring solutions.
For industrial buyers and system integrators, the 6AG4104-4DA11-0CX3 should be selected according to its exact hardware and software configuration. Processor type, memory capacity, storage arrangement, and operating-system edition should be checked against the equipment identification label before ordering. This helps ensure reliable compatibility with existing production systems and application requirements.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Model Number
6AG4104-4DA11-0CX3
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Requires exact configuration verification
Supported Processor Family
Intel Core i5 / Core i7 / Xeon
Chipset
Intel H110 / C236, configuration-dependent
Memory Technology
DDR4 SDRAM
Installed Memory
Requires order-code verification
Maximum Memory
Up to 64 GB
Storage
HDD / SSD, configuration-dependent
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Display Interfaces
DVI-D and DisplayPort 1.2
Additional Interfaces
2 × PS/2, Audio
Expansion Slots
5 × PCI Express, 2 × PCI
Monitoring Functions
Temperature Monitoring, Fan Monitoring, Watchdog
Power Supply
100–240 V AC
Operating System
Requires exact order-code verification
Enclosure
Industrial Rack-Mounted Housing
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short-Enclosure Dimensions
481.4 × 176.6 × 356.6 mm, where applicable
Net Weight
15–23 kg, depending on configuration
Dimensions and weight are based on the standard SIMATIC IPC547G enclosure specifications. The actual weight depends on the installed drives, expansion cards, and power-supply arrangement.
Recommended Companion Models Model Number
Product Name
6AG4104-4DA11-0BX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB DDR4, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB DDR4, 1 TB HDD, Windows 7 Ultimate
6AG4104-4HA12-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB DDR4, C236 Chipset
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 8 GB DDR4, 480 GB SSD, Redundant Power Supply
Popular Related Models Model Number
Product Name
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 4 GB DDR4, 1 TB HDD
6AG4104-4DA22-0HX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 16 GB DDR4, 1 TB HDD, Windows Server 2016
6AG4104-4DB12-0XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB DDR4, Dual 1 TB HDD
6AG4104-4GN16-4BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 8 GB DDR4, RAID 1 Storage
Applications - Industrial Automation and Process Control: Provides a centralized computing platform for PLC communication, automation software, equipment supervision, and industrial process monitoring.
- Manufacturing Data Management: Supports production data collection, process information management, and operational reporting across manufacturing facilities.
- HMI and SCADA Integration: Runs compatible industrial visualization and supervisory applications for monitoring machine conditions, production parameters, and operational status.
- Machine Integration and Data Acquisition: Supports compatible PCI Express and PCI expansion cards for industrial communication, measurement, and specialized equipment integration.
- Industrial Control Room Computing: Its 19-inch rack-mounted construction makes it suitable for centralized computing installations, factory control rooms, and industrial equipment cabinets.
Advantages - Intel Core i7 Computing Performance: Combines a quad-core Intel Core i7-6700 processor with eight threads, a 3.4 GHz base frequency, and up to 4.0 GHz Turbo frequency.
- Dual-Channel DDR4 Memory: The 8 GB memory configuration uses two 4 GB DDR4 modules, providing efficient memory access for compatible industrial applications.
- Integrated 1 TB HDD Storage: Provides local storage for the operating system, industrial software, production records, and application data.
- Extensive Expansion Options: Seven expansion slots, including five PCI Express and two PCI slots, support integration of compatible industrial peripherals and specialized interface cards.
- Industrial Network Connectivity: Dual Intel Gigabit Ethernet interfaces, temperature monitoring, fan monitoring, and watchdog functionality support equipment integration and maintenance.
Technical FAQs Q1. Which processor is used in the Siemens 6AG4104-4DA11-0CX3?
The exact processor configuration should be confirmed against the individual order number. The IPC547G platform supports Intel Core i5, Core i7, and Xeon processor variants.
Q2. Which chipset is supported by the IPC547G platform?
The product family uses Intel H110 or Intel C236 chipsets, depending on the motherboard configuration.
Q3. Does this model support DDR4 memory expansion?
Yes. The IPC547G platform supports DDR4 SDRAM, with a maximum memory capacity of up to 64 GB, subject to the installed motherboard and supported memory modules.
Q4. Can this industrial computer communicate with Siemens S7 PLCs?
Yes. Compatible SIMATIC S7 controllers can communicate through Ethernet using appropriate Siemens engineering software, communication drivers, and automation applications.
Q5. Does the system support PROFINET communication?
PROFINET communication can be implemented using compatible network interfaces and software components. The required configuration depends on the intended automation application.
Q6. What expansion options are available?
The IPC547G provides five PCI Express slots and two PCI slots, supporting compatible industrial communication cards, measurement devices, and specialized peripherals.
Q7. How many Ethernet interfaces are integrated?
The platform provides two Intel Gigabit Ethernet interfaces with RJ45 connectors, allowing connections to industrial networks, PLCs, and supervisory systems.
Q8. Does the IPC547G support SSD storage?
Yes. Compatible SSD storage configurations are available within the IPC547G family. Drive selection and installation depend on the specific hardware arrangement.
Q9. What hardware monitoring functions are included?
The system incorporates temperature monitoring, fan monitoring, watchdog functionality, and card-retention features to support system supervision and maintenance.
Q10. Can this model be integrated into an existing industrial automation network?
Yes. It can be integrated when its network interfaces, operating system, communication drivers, and application software meet the requirements of the existing automation infrastructure.
