Introduction The Siemens 6AG4104-4DA12-0XX3 is associated with the SIMATIC IPC547G industrial rack PC series, a computing platform developed for manufacturing, industrial automation, and centralized process management.
Built around a 19-inch, 4U rack-mounted enclosure, the IPC547G combines flexible processing options with extensive hardware expansion capabilities. Its architecture accommodates different industrial peripherals, allowing system integrators to configure computing resources according to specific operational requirements.
One of its key characteristics is the seven-slot expansion architecture. Five PCI Express slots and two conventional PCI slots provide flexibility for integrating communication adapters, data acquisition devices, and specialized industrial hardware. Dual Intel Gigabit Ethernet interfaces also support connections to automation controllers and factory networks.
The IPC547G incorporates temperature and fan monitoring, watchdog functionality, and industrial power supply options. These features help maintenance teams supervise hardware conditions and support stable operation in demanding industrial environments.
For industrial operators and automation engineers, the IPC547G offers a practical computing solution for production monitoring, SCADA applications, machine integration, and industrial data processing. Its established rack-mounted design also makes it suitable for maintaining existing automation infrastructure.
When selecting the 6AG4104-4DA12-0XX3, the exact processor, memory, storage, operating system, and power supply configuration should be checked against the original Siemens ordering information to ensure the correct equipment is supplied.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA12-0XX3
Product Family
SIMATIC IPC
Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon E3
Processor Model
Configuration dependent
Chipset
Intel H110 / C236
Memory Type
DDR4 SDRAM
Memory Capacity
Configuration dependent, up to 64 GB
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
4 × USB 3.0 / 4 × USB 2.0, depending on motherboard
Display Interfaces
DVI-D / DisplayPort, configuration dependent
Expansion Slots
5 × PCI Express, 2 × PCI
Storage Options
HDD / SSD
RAID Support
Available on selected configurations
Monitoring Functions
Temperature and fan monitoring
System Protection
Watchdog
Power Supply
100–240 V AC
Redundant Power Supply
Optional, configuration dependent
Installation
Horizontal or vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
15–23 kg, depending on equipment
Product Lifecycle
Discontinued
Recommended Companion Models Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 4 GB RAM, 1 TB HDD
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 480 GB SSD
6AG4104-4JP22-0BB1
Siemens SIMATIC IPC547G Xeon E3-1275 v5 Industrial Rack PC, 16 GB RAM, RAID1
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DB12-0XX0
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, Dual 1 TB HDD Configuration
6AG4104-4DC12-0XX3
Siemens SIMATIC IPC547G Industrial Rack PC, Configurable Hardware Version
6AG4104-4DD12-0BX1
Siemens SIMATIC IPC547G Industrial Rack PC, 8 GB RAM, 480 GB SSD Configuration
6AG4104-4EP12-5XX0
Siemens SIMATIC IPC547G Pentium G4400 Industrial Rack PC, 8 GB RAM, RAID1 Configuration
Where It Excels in Industrial Use - Industrial Automation: Provides a centralized computing platform for factory automation, machine supervision, and PC-based control applications.
- Production Line Management: Supports manufacturing data collection, equipment status monitoring, and production process visualization.
- SCADA and HMI Systems: Provides a suitable hardware foundation for supervisory control, operator interfaces, alarm management, and industrial visualization software.
- Industrial Data Acquisition: Supports compatible expansion cards for collecting measurement signals and processing information from connected machinery.
- Machine Vision Applications: Offers expansion flexibility for integrating compatible graphics and image acquisition hardware used in automated inspection systems.
- Control Room Installations: Its 19-inch rack-mounted construction makes it suitable for centralized industrial cabinets, monitoring stations, and equipment rooms.
Key Strengths at a Glance - Industrial Computing Platform: Based on the Siemens SIMATIC IPC547G architecture, designed for demanding industrial applications.
- Flexible Expansion Architecture: Seven expansion slots, including five PCI Express and two PCI slots, support different industrial hardware requirements.
- Dual Gigabit Ethernet: Provides two Intel Gigabit Ethernet interfaces for communication with automation controllers and industrial networks.
- Hardware Monitoring: Integrated temperature and fan monitoring help identify abnormal operating conditions.
- Watchdog Functionality: Supports system supervision and configured responses to unexpected operating conditions.
- Flexible Installation: Supports horizontal and vertical installation, with provisions for telescopic rails and optional tower conversion.
- Industrial Power Options: Supports standard 100–240 V AC power and optional redundant power supply configurations, depending on the selected hardware.
Technical FAQs Q1: What is the primary function of the Siemens 6AG4104-4DA12-0XX3?
This ordering number is associated with the SIMATIC IPC547G industrial rack PC family, which is designed for industrial computing, process monitoring, and PC-based automation applications.
Q2: Which processors are supported by the IPC547G platform?
The IPC547G family supports selected Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processor configurations. The exact processor installed in this ordering variant requires confirmation.
Q3: How many expansion slots does the IPC547G provide?
The platform provides seven expansion slots, consisting of five PCI Express slots and two conventional PCI slots for compatible industrial expansion hardware.
Q4: Does the IPC547G support industrial Ethernet communication?
Yes. The platform provides two Intel Gigabit Ethernet interfaces for connecting PLCs, industrial switches, supervisory computers, and other networked devices.
Q5: Can this industrial PC communicate with Siemens SIMATIC PLCs?
Yes. It can communicate with compatible SIMATIC controllers through supported industrial Ethernet protocols and appropriate Siemens automation software.
Q6: Does the IPC547G support RAID storage?
Selected configurations support onboard RAID functionality through compatible motherboard chipsets and storage arrangements. The available RAID levels depend on the installed hardware.
Q7: What diagnostic functions are available?
The IPC547G provides temperature and fan monitoring functions that help maintenance personnel identify abnormal hardware conditions and plan preventive maintenance.
Q8: How does the watchdog function support industrial operation?
The watchdog supervises system activity and can initiate a predefined response when abnormal computer operation is detected, helping improve application reliability.
Q9: Can additional industrial communication cards be installed?
Yes. Compatible PCI Express and PCI cards can extend the computer's communication capabilities for specialized industrial networks, measurement equipment, and automation peripherals.
Q10: Which factors should be checked before replacing an IPC547G unit?
Users should verify the processor, motherboard chipset, memory, storage arrangement, expansion cards, operating system, BIOS configuration, and power supply requirements to maintain compatibility with the existing installation.
