Brand:Allen Bradley PLC Item No.:20F1AGE063AA0NNNNN Product Origin:USA Product Dimensions:1298.3 x 609.4 x 464.7 mm Product Weight:91 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 20F1AGE063AA0NNNNN is a PowerFlex 753 AC Packaged Drive designed for industrial motor speed and torque control. As part of the PowerFlex 750-Series, it provides a combination of motor control functionality, embedded I/O, and industrial installation features.
This configuration operates with a 600 V AC three-phase input and delivers a 63 A output rating. It supports 60 HP normal-duty and 50 HP heavy-duty applications. The drive also features forced-air cooling, EMC filtering, an integrated dynamic braking transistor, and an IP54 / NEMA Type 12 enclosure.
The PowerFlex 753 series is commonly used in applications such as pumps, fans, conveyors, compressors, and production machinery. Variable-frequency operation allows motor speed to be adjusted according to process requirements, supporting more flexible equipment control.
For maintenance teams and system integrators, the 20F1AGE063AA0NNNNN is relevant to industrial drive replacement, equipment upgrades, and automation system maintenance. Its catalog number identifies a specific configuration, so electrical ratings, enclosure requirements, braking arrangements, and control options should be checked carefully before ordering.
Technical Specifications
Parameter
Specification
Brand
Allen Bradley
Model
20F1AGE063AA0NNNNN
Product Series
PowerFlex 753
Product Type
AC Drive
Drive Configuration
AC Packaged Drive
Input Voltage
600 V AC
Input Phase
Three-phase
Output Current
63 A
Normal-Duty Power Rating
60 HP
Heavy-Duty Power Rating
50 HP
Frame Size
Frame 6
Cooling Method
Forced Air
Enclosure Rating
IP54 / NEMA Type 12
I/O Configuration
Embedded I/O
EMC Filtering
Filtered
Dynamic Braking
Integrated DB Transistor
Human Interface Module
Not Included
Input Configuration
AC Input with Precharge, No DC Terminals
Dimensions
1298.3 × 609.4 × 464.7 mm
Weight
91 kg / 200.62 lb
