ABB 216VC62A Digital Input/Output Module

Introduction

The ABB 216VC62A is a digital I/O module designed to handle high-performance input and output tasks in industrial automation systems. This module features 16 digital inputs and 16 digital outputs, facilitating seamless communication between various field devices, such as sensors, actuators, and controllers. The 216VC62A is built to operate at 24 VDC, ensuring compatibility with most industrial devices. Its DIN rail mounting feature provides ease of installation and efficient space utilization in control panels. The module is designed to withstand the challenging conditions of industrial environments, offering reliable performance across a wide range of temperatures and offering protection against overloads and short circuits.

Technical Specifications

Specification	Details
Model	216VC62A
Module Type	Digital Input/Output Module
Number of Inputs	16 Digital Inputs
Number of Outputs	16 Digital Outputs
Input Voltage	24 VDC
Output Voltage	24 VDC
Size (W x H x D)	120 x 120 x 80 mm
Weight	0.9 kg
Mounting Type	DIN Rail
Operating Temperature	-20°C to +60°C
Certifications	CE, UL, RoHS
