The Schneider Electric 140CPS11100C is a high-performance power supply module specifically designed to provide 24V DC power to Modicon M340 and Modicon M580 PLC systems. This module is engineered to ensure that PLC systems and connected field devices receive a stable and uninterrupted power supply, which is crucial for reliable operation in industrial environments. With a compact design, efficient power conversion, and enhanced protection features, the 140CPS11100C is ideal for use in demanding applications such as industrial automation, process control, remote monitoring, and more.

This power supply module is part of Schneider Electric’s robust family of Modicon PLC accessories, providing a reliable solution for powering critical control systems. Offering overcurrent, overvoltage, and short-circuit protection, the 140CPS11100C is designed to safeguard your system and ensure continuous operation, even in harsh conditions.

Technical Specifications

Specification	Details
Model	140CPS11100C
Module Type	Power Supply Module
Input Voltage Range	85-264 VAC, 47-63 Hz
Output Voltage	24 VDC
Output Current	5 A maximum (120W)
Power Consumption	120W (maximum)
Efficiency	≥ 93%
Operating Temperature Range	0°C to 60°C (32°F to 140°F)
Storage Temperature Range	-40°C to 85°C (-40°F to 185°F)
Dimensions (L x W x H)	4.9 x 3.2 x 5.4 inches (125 x 82 x 137 mm)
Weight	0.75 lbs (0.34 kg)
Protection Features	Overvoltage, overcurrent, short-circuit protection
Environmental Protection	IP20 (protected against solid objects greater than 12mm)

Recommended Related Models

Schneider Electric 140DPS11400 – A higher-capacity power supply module designed for larger automation systems, offering reliable power for high-demand applications.
Schneider Electric 140CRP31200 – Modicon M340 processor module, designed for integration with the 140CPS11100C to control complex industrial systems.
Schneider Electric 140AOA78100 – A high-performance analog output module that can be paired with the 140CPS11100C for enhanced signal processing in industrial automation systems.

Popular Schneider Electric Models

Modicon M340 PLC – A flexible and scalable PLC designed to handle a wide range of industrial automation tasks. It integrates seamlessly with the 140CPS11100C power supply for reliable operation.
Modicon M580 ePAC – A high-performance, Ethernet-based PLC designed for demanding applications, offering high-speed processing and communication capabilities.
140DDI35300 Digital Input Module – A digital input module that can be used with the 140CPS11100C to capture fast digital signals from field devices and integrate them into your automation system.
140CPS11000 – Another power supply module from Schneider Electric that can be used in systems with Modicon M340 PLCs, providing 24V DC output for reliable power delivery.

Applications

The 140CPS11100C power supply module is designed for a range of industrial applications that require reliable and continuous power. Some common applications include:

Industrial Automation: Supplies stable 24V DC power to PLCs, sensors, actuators, and other automation devices, ensuring uninterrupted performance in automated control systems.
Process Control: Used in chemical, pharmaceutical, and food and beverage industries, where consistent and reliable power is required to maintain production continuity and safety.
Energy and Utilities: Vital for power plants, smart grids, and substations, where a stable power supply is essential for controlling energy distribution and monitoring systems.
Building Automation: Ensures reliable power to building management systems, including HVAC, lighting, and security systems, enhancing comfort and energy efficiency.
Remote Monitoring: Ideal for remote locations that require stable power to monitor and control devices, ensuring continuous operation in environments where maintenance access is limited.

Advantages

High Efficiency: The 140CPS11100C operates with ≥ 93% efficiency, ensuring minimal power loss and contributing to energy savings.
Wide Input Voltage Range: With an input voltage range of 85-264 VAC, it can adapt to a wide range of industrial power sources, making it suitable for global installations.
Reliable Power Delivery: The module provides 5A of stable 24V DC power, ensuring the reliable operation of Modicon M340 and M580 PLC systems and their connected components.
Compact Form Factor: Despite its high power output, the module’s compact size (4.9 x 3.2 x 5.4 inches) allows easy integration into industrial control panels and cabinets.
Advanced Protection Features: Equipped with overvoltage, overcurrent, and short-circuit protection, this module safeguards both the power supply and the connected devices.
Environmental Durability: The 140CPS11100C has an IP20 rating, offering protection against solid objects greater than 12mm and making it suitable for most industrial environments.
Wide Operating Temperature Range: It can operate effectively between 0°C to 60°C (32°F to 140°F), making it suitable for a wide variety of industrial environments.
Easy Installation: Designed for seamless integration with Modicon M340 and M580 PLCs, the module simplifies installation and reduces setup time.
Reduced Operational Costs: Its high efficiency and reliable performance reduce maintenance needs and the likelihood of downtime, contributing to lower operational costs.
Global Compatibility: The wide input voltage range (85-264 VAC) makes this module ideal for use in various regions, accommodating global industrial power standards.

Technical FAQs

What output voltage does the 140CPS11100C provide?
The 140CPS11100C provides a 24V DC output for powering Modicon M340 and M580 PLC systems and connected devices.
What is the maximum output current of the 140CPS11100C?
The module provides 5A maximum output current, with a power output of 120W.
What input voltage range does the 140CPS11100C support?
The 140CPS11100C supports an input voltage range of 85-264 VAC, making it suitable for a variety of global industrial power sources.
What protection features are included in the 140CPS11100C?
The module is equipped with overvoltage, overcurrent, and short-circuit protection, ensuring the safety and longevity of your system.
What is the efficiency rating of the 140CPS11100C?
The module operates with an efficiency of ≥ 93%, which helps minimize energy loss and contributes to energy savings.
What is the operating temperature range of the 140CPS11100C?
The operating temperature range is from 0°C to 60°C (32°F to 140°F), making it suitable for most industrial environments.
What is the environmental protection rating of the 140CPS11100C?
The module has an IP20 rating, which protects against solid objects larger than 12mm, making it suitable for typical industrial conditions.
Can the 140CPS11100C be used in remote monitoring systems?
Yes, the 140CPS11100C is ideal for remote monitoring applications, where stable and reliable power is required for continuous operation.
How is the 140CPS11100C installed?
The module integrates easily into Modicon M340 and M580 PLC systems, reducing installation time and effort.
What industries can benefit from using the 140CPS11100C?
This power supply module is ideal for industries like industrial automation, process control, energy and utilities, building automation, and remote monitoring, where reliable power is crucial.
