ABB 23NG23 Digital Output Module

Introduction

The ABB 23NG23 is a digital output module designed for industrial automation systems that require high-speed, reliable control of digital devices. This module is equipped with 16 digital outputs, making it ideal for applications that involve controlling various field devices such as actuators, relays, solenoids, and motors. It operates with 24 VDC, ensuring compatibility with standard industrial equipment. The module’s DIN rail mounting feature provides a convenient and space-saving installation method, making it easy to integrate into control cabinets. Designed for harsh industrial environments, the 23NG23 comes with built-in protection features such as short-circuit, overload, and thermal protection to ensure safety and durability.

Technical Specifications

Specification	Details
Model	23NG23
Module Type	Digital Output Module
Number of Outputs	16 Digital Outputs
Output Voltage	24 VDC
Size (W x H x D)	120 x 120 x 80 mm
Weight	0.9 kg
Mounting Type	DIN Rail
Operating Temperature	-20°C to +60°C
Protection	Short-circuit, Overload, Thermal Protection
Certifications	CE, UL, RoHS

Recommended Related Models

Model	Module Type	Number of Outputs	Output Voltage
ABB 23NG24	Digital Output Module	16 Digital Outputs	24 VDC
ABB 23NG25	Digital Output Module	8 Digital Outputs	24 VDC
ABB 23NG26	Digital Output Module	8 Digital Outputs	24 VDC

Popular ABB Models

Model	Module Type	Number of Outputs	Output Voltage
ABB 23NG23	Digital Output Module	16 Digital Outputs	24 VDC
ABB 23NG22	Digital Output Module	16 Digital Outputs	24 VDC
ABB 23NG27	Digital Output Module	16 Digital Outputs	24 VDC

Applications

Industrial Automation: The ABB 23NG23 module is used in industrial automation systems to control digital devices such as relays, motors, and solenoids, ensuring precise operation of complex automated processes.
Process Control: It can be used in process control systems to provide control signals for devices like valves, pumps, and actuators, crucial for industries such as oil & gas, chemicals, and pharmaceuticals.
Machine Automation: The 23NG23 module is ideal for machine automation, where it controls actuators and motors in high-speed, high-precision systems such as packaging lines or robotic arms.
Energy Management: This module can be applied in energy management systems to control power actuators, meters, and other energy devices, ensuring efficient operation and monitoring of energy consumption.
Building Automation: The 23NG23 is used in building automation, controlling systems such as HVAC, lighting, and security, providing reliable operation in commercial and residential environments.

Advantages

High-Performance Control: The 23NG23 module provides 16 digital outputs, enabling efficient and reliable control of a wide range of field devices, ideal for complex industrial automation systems.
Space-Efficient Design: With DIN rail mounting, the module offers a space-saving installation solution that is ideal for crowded control panels and automation systems.
Wide Operating Range: With an operating temperature range of -20°C to +60°C, this module is designed to perform reliably in various industrial conditions, from harsh factory floors to outdoor installations.
Built-In Protection: The 23NG23 comes equipped with short-circuit protection, overload protection, and thermal protection, ensuring the safety of both the module and connected devices during operation.
Global Certifications: The 23NG23 is CE, UL, and RoHS certified, meeting international standards for safety, environmental sustainability, and product quality.
