The Yokogawa AIP423 is a high-performance industrial automation processor engineered to handle complex control, monitoring, and data processing tasks in modern industrial environments. Offering exceptional reliability and flexibility, the AIP423 is ideal for industries such as oil & gas, chemical, power generation, and pharmaceuticals. Designed to meet the rigorous demands of real-time data acquisition, advanced diagnostics, and multi-protocol communication, the AIP423 plays a key role in enhancing operational efficiency, ensuring system reliability, and facilitating smooth communication between field devices and control systems. With its multi-core processing, high-speed data exchange, and easy integration, the AIP423 is a versatile solution for both centralized and decentralized control systems.

Technical Specifications

Model: AIP423
Type: Industrial Automation Processor
Dimensions: 9.4 inches x 7.1 inches x 4.7 inches (240 mm x 180 mm x 120 mm)
Weight: 3.1 lbs (1.4 kg)
Power Supply: 24V DC ± 10%
Power Consumption: 50 W
Communication Ports:
- 2x Ethernet Ports (10/100/1000 Mbps)
- 2x Serial Ports (RS-232/RS-485)
- 1x USB Port (for local connections)
Supported Protocols: Ethernet/IP, Modbus TCP/IP, OPC, Profibus DP, HART, DeviceNet
Operating Temperature: -10°C to 60°C (14°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
Environmental Rating: IP20 (for indoor use)
Mounting: DIN Rail Mountable
Data Processing: Multi-core processor with real-time data capabilities

Recommended Related Models

Yokogawa CENTUM VP: The CENTUM VP DCS, integrated with the AIP423, offers a powerful, reliable control solution for large-scale industrial processes, supporting high-performance data processing and communication.
Yokogawa STARDOM FCN: The STARDOM FCN distributed control system, in combination with the AIP423, provides scalability, flexibility, and high availability for industrial control applications.
Yokogawa ADMAG AXF: The ADMAG AXF series of magnetic flow meters, paired with the AIP423, ensures accurate flow measurement and enhanced process monitoring in industries such as chemicals and power.
Yokogawa PRM (Plant Resource Manager): Integrated with the AIP423, PRM helps optimize plant performance by providing real-time diagnostics, predictive maintenance, and comprehensive asset management.

Popular Yokogawa Models

Yokogawa CENTUM VP DCS: The CENTUM VP distributed control system, when paired with the AIP423, delivers advanced control capabilities, ensuring seamless operation and real-time data management for large and complex industrial systems.
Yokogawa DX1000: The DX1000 controller, combined with the AIP423, enhances process automation by enabling rapid data processing and reliable communication for various industrial applications.
Yokogawa PRM (Plant Resource Manager): PRM integrated with the AIP423 ensures proactive maintenance and management of field devices, preventing unplanned downtime and optimizing system performance.

Applications

The Yokogawa AIP423 is well-suited for applications requiring high-performance data processing, multi-protocol communication, and seamless integration with various control systems:

Centralized Control Systems: In large-scale facilities, the AIP423 functions as the central processor, ensuring smooth data communication between field devices and control systems for optimized process management.
Distributed Control Systems (DCS): The AIP423, when integrated with Yokogawa’s CENTUM VP or STARDOM FCN, provides decentralized control, allowing flexibility and scalability in complex industrial processes.
Predictive Maintenance: The AIP423 works with PRM to provide real-time diagnostics and predictive maintenance capabilities, helping extend the lifespan of field devices and reduce downtime.
Data Acquisition and Process Monitoring: The AIP423 enables seamless data acquisition and monitoring for real-time process control, making it ideal for industries such as oil & gas, chemical, and power generation.
Advanced Process Control (APC): The AIP423 ensures that advanced process control strategies are implemented effectively by processing large volumes of data quickly and accurately.

Advantages

Multi-Protocol Support: The AIP423 supports a broad range of communication protocols, including Ethernet/IP, Modbus TCP/IP, OPC, Profibus DP, HART, and DeviceNet, ensuring compatibility with a variety of field devices and systems.
High-Speed Communication: Equipped with 2 Ethernet ports (10/100/1000 Mbps), the AIP423 ensures rapid data exchange and efficient communication between devices and control systems.
Real-Time Data Processing: Featuring a multi-core processor, the AIP423 delivers real-time data processing, enabling minimal latency and optimal performance for critical applications.
Flexible Mounting and Integration: The AIP423 is DIN rail mountable, making it easy to integrate into control panels and compact spaces without compromising on performance.
Energy-Efficient: With a 50 W power consumption, the AIP423 is designed for energy-efficient operation, reducing operational costs while providing high processing power.
