The Schneider Electric 140DAI55300C is a 16-channel analog input module designed for the Modicon Premium I/O system. It is engineered to handle a wide variety of analog signal inputs, including both voltage (0-10 VDC) and current (4-20 mA), providing flexibility in sensor compatibility. With 12-bit resolution and ±0.5% accuracy, this module ensures that your control system captures precise analog data for real-time process monitoring and control. Whether you're in the manufacturing, energy, water treatment, or automation sectors, the 140DAI55300C offers reliable data acquisition to ensure operational efficiency and system optimization.

Technical Specifications

Feature	Description
Model Number	140DAI55300C
Module Type	Analog Input Module (16 Channels)
Input Voltage Range	0 to 10 VDC (or configurable to 4-20 mA)
Resolution	12 bits
Accuracy	±0.5% of full scale
Input Type	Voltage (0-10 VDC) or Current (4-20 mA)
Channel Count	16 Inputs
Mounting Style	Rack Mountable (for Modicon Premium system)
Dimensions (H x W x D)	4.3 x 5.1 x 2.4 inches (110 x 130 x 60 mm)
Weight	0.55 kg
Operating Temperature Range	0°C to 55°C
Humidity	10% to 95%, non-condensing
Certifications	CE, UL, CSA, IECEx
Status Indicators	LED indicators for power and communication

Recommended Related Models

For enhanced system capabilities and integration, consider the following Schneider Electric models:

140CRA93100: Modicon Premium I/O Rack (16 slots)
140PRA93100: Modicon Premium Power Supply Module
140CPS11400: Modicon Ethernet Communication Processor
140DTA35300: Modicon Digital Output Module (16 points)
140DOA35300: Modicon Digital Output Module (32 points)

Popular Schneider Electric Models

The Modicon Premium range from Schneider Electric offers a broad spectrum of reliable, high-performance components for industrial automation. Popular models include:

140CPU67160: Modicon Premium CPU with 1.5MB memory
140CRA93110: Modicon Premium I/O Rack (32 slots)
140PRA93100: Modicon Premium Power Supply Module
140EHC02000: Modicon Analog I/O Module (8 input/8 output)
140NOA93100: Modicon Premium I/O Power Supply Module

Applications

The 140DAI55300C is perfect for industrial applications that require high-accuracy analog data acquisition. Key applications include:

Automated Manufacturing: Collecting data from sensors such as temperature, pressure, and flow meters to maintain efficient production processes.
Energy Management: Monitoring electrical parameters like voltage, current, and power to optimize energy consumption in industrial operations.
Water and Wastewater Treatment: Collecting data from pH sensors, flow meters, and chemical dosing systems to ensure efficient water treatment processes.
Building Automation: Integrating environmental sensors for temperature, humidity, and light levels to optimize energy usage and manage HVAC and lighting systems.
Oil & Gas: Monitoring vital parameters such as pressure, temperature, and flow to ensure the safe and efficient operation of equipment in harsh environments.

Advantages

The 140DAI55300C offers numerous advantages that enhance its appeal for various industrial applications:

High Accuracy and Precision: With a 12-bit resolution and ±0.5% accuracy, it ensures high-quality data collection for critical process control.
16 Input Channels: The module supports 16 simultaneous inputs, enabling it to monitor multiple sensors and inputs at the same time, which is ideal for large-scale systems.
Flexible Input Compatibility: Supports both voltage (0-10 VDC) and current (4-20 mA) inputs, providing versatility in sensor selection and system design.
Compact and Durable Design: The module's compact size and rugged design allow it to operate reliably in industrial environments with temperature ranges from 0°C to 55°C.
Seamless System Integration: Integrates easily with Schneider Electric’s Modicon Premium automation components, allowing for efficient system expansion.
Efficient Monitoring: Features LED indicators that display power and communication status, ensuring continuous monitoring of the module's operational health.

Technical FAQs

What types of inputs does the 140DAI55300C support?
The module supports voltage (0-10 VDC) and current (4-20 mA) inputs, allowing it to work with a wide range of analog sensors.
How many input channels does the 140DAI55300C offer?
The module provides 16 input channels, making it ideal for applications requiring simultaneous monitoring of multiple analog signals.
What is the resolution of the 140DAI55300C?
The module provides a 12-bit resolution, ensuring precise and reliable data acquisition for critical processes.
What is the accuracy of the 140DAI55300C?
The module has an accuracy of ±0.5% of full scale, which ensures consistent and precise measurements across its operational range.
Can the 140DAI55300C be used for temperature monitoring?
Yes, the module can be used for temperature sensing when interfacing with temperature sensors that provide voltage or current outputs.
What is the operating temperature range for the 140DAI55300C?
The module operates effectively within a temperature range of 0°C to 55°C, making it suitable for diverse industrial environments.
What certifications does the 140DAI55300C hold?
The module holds CE, UL, CSA, and IECEx certifications, ensuring it meets global safety standards.
What is the weight of the 140DAI55300C?
The module weighs approximately 0.55 kg (1.21 lbs), making it both compact and easy to install.
Can the 140DAI55300C be used in hazardous environments?
Yes, the module is IECEx certified, which means it can be used in potentially explosive or hazardous environments such as those found in the oil and gas sector.
How does the 140DAI55300C compare to other Schneider Electric analog input modules?
The 140DAI55300C stands out for its 16 input channels and support for both voltage and current inputs, making it an excellent choice for larger or more complex automation systems compared to other modules with fewer inputs.
