The Schneider Electric 140DAO84000 is a 16-point digital output module designed for use in Modicon Premium automation systems. Operating with 24V DC signals, this module is ideal for controlling various industrial devices like relays, solenoids, actuators, and other output devices. The 140DAO84000 features transistor-type outputs, providing fast and reliable control of output devices in manufacturing, process control, building automation, and energy management systems. With its robust design and compact size, the 140DAO84000 offers seamless integration into larger automation systems, making it a perfect choice for modern industrial applications.

Technical Specifications

Feature	Description
Model Number	140DAO84000
Module Type	Digital Output Module (16 Points)
Output Type	Transistor Output (Saturation Type)
Output Voltage	24V DC
Output Current per Point	0.5A (max) per point
Total Output Current	8A max (for all 16 points)
Response Time	< 2 ms
Mounting Style	Rack Mountable (for Modicon Premium system)
Dimensions (H x W x D)	4.3 x 5.1 x 2.4 inches (110 x 130 x 60 mm)
Weight	0.55 kg
Operating Temperature Range	0°C to 55°C
Humidity	10% to 95%, non-condensing
Certifications	CE, UL, CSA, IECEx
Status Indicators	LED indicators for power and communication

Recommended Related Models

For optimal performance and system expansion, consider integrating these Schneider Electric products:

140CRA93100: Modicon Premium I/O Rack (16 slots)
140PRA93100: Modicon Premium Power Supply Module
140CPS11400: Modicon Ethernet Communication Processor
140DTA35300: Modicon Digital Output Module (16 points)
140DAO84001: Modicon Digital Output Module with Relay Outputs

Popular Schneider Electric Models

Schneider Electric’s Modicon Premium series includes a variety of high-performance modules. Popular models include:

140CPU67160: Modicon Premium CPU with 1.5MB memory
140CRA93110: Modicon Premium I/O Rack (32 slots)
140PRA93100: Modicon Premium Power Supply Module
140EHC02000: Modicon Analog I/O Module (8 input/8 output)
140NOA93100: Modicon Premium I/O Power Supply Module

Applications

The 140DAO84000 is ideal for a wide variety of industrial applications that require digital control of output devices. Common use cases include:

Manufacturing Automation: Controlling solenoids, actuators, or relays for process equipment, conveyors, or assembly lines.
Energy Management: Managing power circuits, circuit breakers, or switching devices in energy distribution systems.
Building Automation: Controlling HVAC systems, lighting, or access control devices within commercial or industrial buildings.
Process Control: Managing outputs like pumps, valves, and actuators in industries such as food & beverage, pharmaceuticals, and chemicals.
Material Handling: Controlling motorized systems like conveyors, gates, and lifts in warehouses or production environments.

Advantages

The 140DAO84000 offers a range of advantages, making it a preferred choice for industrial control applications:

16 Output Points: The module provides 16 transistor outputs, allowing simultaneous control of multiple devices in your automation system.
24V DC Operation: It operates with 24V DC outputs, a common voltage standard for digital devices in industrial automation, making it highly compatible with various equipment.
Fast Response Time: The module has a response time of less than 2 ms, enabling rapid switching and precise control of output devices.
High Current Rating: Each output point supports a maximum current of 0.5A, and the module can handle a total current of 8A across all 16 outputs.
Seamless Integration: The 140DAO84000 integrates effortlessly into the Schneider Electric Modicon Premium I/O system, providing a simple solution for expanding automation capabilities.
Compact and Reliable Design: The module’s small footprint and robust construction ensure dependable performance in harsh industrial environments, with an operating temperature range from 0°C to 55°C.

Technical FAQs

What type of outputs does the 140DAO84000 have?
The module features transistor outputs (saturation type), ideal for controlling digital devices like solenoids and relays.
What is the output voltage for the 140DAO84000?
The module operates with a 24V DC output voltage, which is typical for industrial automation applications.
How much current can each output point handle?
Each output point can handle up to 0.5A of current, with a total maximum current of 8A across all 16 points.
What is the response time of the 140DAO84000?
The module has a fast response time of less than 2 ms, making it suitable for applications that require high-speed switching.
What is the weight of the 140DAO84000?
The module weighs approximately 0.55 kg (1.21 lbs), making it compact and easy to install in your system.
Can the 140DAO84000 be used in hazardous environments?
Yes, the module is IECEx certified, ensuring it meets the safety standards required for use in hazardous environments.
What certifications does the 140DAO84000 hold?
The module is certified with CE, UL, CSA, and IECEx certifications, ensuring compliance with global safety and quality standards.
Can the 140DAO84000 be used for controlling motors?
Yes, the module can control various devices such as motors, actuators, and relays in automated systems, such as material handling and process control.
What is the operating temperature range for the 140DAO84000?
The module operates in temperatures ranging from 0°C to 55°C, making it suitable for a wide range of industrial environments.
How does the 140DAO84000 compare to other Schneider Electric digital output modules?
The 140DAO84000 stands out due to its 16 transistor-type outputs and the ability to handle 0.5A per output point, making it ideal for controlling a large number of devices with fast response times in industrial automation systems.
