The Schneider Electric 140DDO35310 is a powerful 24V DC digital output module designed to provide reliable and high-performance control over 32 output channels. Ideal for industrial automation systems requiring precise management of field devices such as actuators, relays, and solenoids, this module offers a scalable solution for a wide variety of applications. Featuring sourcing (positive logic) output, fast response times, and strong electrical isolation, the 140DDO35310 integrates seamlessly with Schneider Electric’s Modicon PLC systems, ensuring both flexibility and reliability in large-scale automation setups.

Technical Specifications

Model: 140DDO35310
Type: Digital Output Module
Voltage Rating: 24V DC
Number of Outputs: 32
Output Type: Sourcing (Positive Logic)
Rated Output Voltage: 24V DC
Output Current per Channel: 0.5 A (max)
Isolation: Galvanic Isolation between output channels and the control system
Response Time: 1 ms (typical)
Mounting Type: DIN Rail Mount
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Dimensions: 180 mm x 90 mm x 90 mm
Weight: 0.85 kg

Recommended Related Models

Schneider 140DDI35300: 32-Point Digital Input Module for larger input applications
Schneider 140DDO15310C: 16-Point Digital Output Module for smaller output setups
Schneider 140DDM69000C: 64-Point Digital I/O Module for large-scale input and output control

Popular Schneider Models

Schneider 140CPU65150: High-performance CPU for Modicon M340
Schneider 140CRA93100: Communication Processor for Modicon PLCs
Schneider 140DRA84000: Relay Output Module for industrial control applications

Applications

The 140DDO35310 Digital Output Module is ideal for various industrial automation applications that require high-density output control, including:

Manufacturing Automation: Controls actuators, relays, and other output devices on automated production lines, ensuring efficient, reliable, and continuous operation of machinery and equipment.
Process Control: Provides reliable output control in industries such as chemicals, pharmaceuticals, and food processing, where precise control is essential for system safety and operational efficiency.
Material Handling: Used to control output devices in material handling systems like conveyors, robotic arms, and sorting mechanisms, enabling smooth and automated material flow in factories and warehouses.
Packaging Systems: Manages output signals in packaging equipment such as filling stations, labeling machines, and conveyors, improving overall productivity and minimizing downtime.
Building Automation: Ideal for controlling output devices in HVAC, lighting, and security systems within commercial buildings, contributing to energy efficiency and seamless building management.

Advantages

High Output Density: The 140DDO35310 offers 32 output channels, making it an ideal solution for applications requiring a large number of output points in a compact form.
Fast Response Time: The module provides a rapid response time of 1 ms (typical), ensuring fast switching and reliable performance in time-sensitive industrial operations.
Galvanic Isolation: Galvanic isolation between the output channels and the control system enhances the system's resilience against electrical surges and reduces the risk of system failure.
Compact and Efficient Design: Despite the 32 output channels, the module is designed for easy DIN rail mounting and is space-efficient (180 mm x 90 mm x 90 mm), making it perfect for environments with limited space.
Wide Temperature Range: With an operating temperature range of -20°C to 60°C, the 140DDO35310 is suitable for a wide variety of industrial environments, ensuring stable performance across different conditions.
Seamless Integration with Schneider PLCs: The module integrates perfectly with Schneider Electric’s Modicon PLCs, making it a flexible and scalable solution for industrial automation systems.

Technical FAQs

How many digital outputs does the 140DDO35310 support?
The 140DDO35310 provides 32 sourcing (positive logic) digital outputs.
What is the output voltage for this module?
The module operates with a rated output voltage of 24V DC, suitable for most industrial applications.
What is the maximum current supported by each output channel?
Each output channel can handle up to 0.5 A of current, providing sufficient power to drive relays, actuators, and other field devices.
What is the response time of the 140DDO35310?
The module offers a typical response time of 1 ms, ensuring fast and efficient switching of output devices.
Does the module offer electrical isolation?
Yes, the 140DDO35310 provides galvanic isolation between the output channels and the system, protecting the system from electrical noise and voltage spikes.
How is the 140DDO35310 mounted?
The module is designed for easy DIN rail mounting, allowing for quick installation and efficient use of panel space.
What is the operating temperature range for this module?
The 140DDO35310 operates within a temperature range from -20°C to 60°C, making it versatile for use in various industrial environments.
Can multiple 140DDO35310 modules be used in the same system?
Yes, multiple modules can be easily integrated into a single system to expand the number of output channels as needed.
Is the 140DDO35310 compatible with Schneider Modicon PLCs?
Yes, the 140DDO35310 integrates seamlessly with Schneider Electric’s Modicon PLCs, providing a reliable and scalable solution for industrial automation systems.
Are additional accessories required for installation?
No, the 140DDO35310 is designed for straightforward DIN rail mounting, and no additional accessories are required for installation.
