The Schneider Electric 140DDO84300C is a compact, high-performance 24V DC digital output module designed to provide precise control over 8 output channels in industrial automation systems. This module is ideal for applications where a small footprint is required, yet high-density output control is needed for driving relays, actuators, solenoids, and other field devices. The 140DDO84300C offers sourcing (positive logic) outputs, making it a reliable solution for controlling output devices in manufacturing, material handling, and building automation systems. Fully compatible with Schneider Electric’s Modicon PLCs, the module ensures seamless integration and scalability within your control system.

Technical Specifications

Model: 140DDO84300C
Type: Digital Output Module
Voltage Rating: 24V DC
Number of Outputs: 8
Output Type: Sourcing (Positive Logic)
Rated Output Voltage: 24V DC
Output Current per Channel: 0.5 A (max)
Isolation: Galvanic Isolation between output channels and the control system
Response Time: 1 ms (typical)
Mounting Type: DIN Rail Mount
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Dimensions: 90 mm x 90 mm x 90 mm
Weight: 0.35 kg

Recommended Related Models

Schneider 140DDI84300C: 8-Point Digital Input Module for smaller I/O applications
Schneider 140DDO15310C: 16-Point Digital Output Module for medium-sized output control
Schneider 140DDM69000C: 64-Point Digital I/O Module for large-scale input/output systems

Popular Schneider Models

Schneider 140CPU65150: High-performance CPU for Modicon M340 series
Schneider 140CRA93100: Communication Processor for Modicon PLCs
Schneider 140DRA84000: Relay Output Module for industrial control applications

Applications

The 140DDO84300C Digital Output Module is ideal for a wide range of industrial automation applications, particularly those that require compact, reliable output control in small or medium-sized systems:

Manufacturing Automation: Ideal for controlling small batches of actuators, relays, and solenoids in production lines, robotic systems, and automated machinery.
Material Handling: Perfect for controlling output devices in material handling systems such as conveyors, sorting systems, and automated robotic arms in warehouses or factories.
Building Automation: Controls output devices in HVAC systems, lighting, and security systems in commercial buildings, optimizing energy efficiency and system performance.
Packaging Systems: Ensures reliable control of output devices in packaging systems, such as filling, labeling, and sealing stations, helping to streamline production.
Process Control: Provides precise output control for pumps, valves, and other field devices in industries like food and beverage, pharmaceuticals, and chemicals.

Advantages

Compact Design: The 140DDO84300C offers high performance with 8 output channels in a compact form factor (90 mm x 90 mm x 90 mm), making it ideal for applications where space is limited.
Fast Response Time: With a typical response time of 1 ms, the module provides quick and efficient switching of output devices, minimizing delays in system processes.
Galvanic Isolation: The module offers galvanic isolation between the output channels and the control system, ensuring protection from electrical noise, surges, and other external disturbances.
Reliable Control: The sourcing (positive logic) output type ensures that connected devices like relays and actuators receive the correct control signal, ensuring reliable system operation.
Wide Temperature Range: The 140DDO84300C operates within a temperature range from -20°C to 60°C, making it suitable for a variety of industrial environments with varying temperature conditions.
Seamless Integration: Designed to integrate easily with Schneider Electric’s Modicon PLCs, the module offers flexibility and scalability for future system upgrades or expansions.

Technical FAQs

How many digital outputs does the 140DDO84300C support?
The 140DDO84300C provides 8 sourcing (positive logic) digital outputs.
What is the output voltage rating of this module?
The module operates with a rated output voltage of 24V DC, which is commonly used in industrial automation applications.
What is the maximum current supported by each output channel?
Each output channel can handle a maximum current of 0.5 A.
What is the response time of the 140DDO84300C?
The typical response time of the module is 1 ms, providing fast switching capabilities for real-time output control.
Does the module provide electrical isolation?
Yes, the 140DDO84300C features galvanic isolation between the output channels and the control system, which enhances system reliability by protecting it from electrical disturbances.
How is the 140DDO84300C mounted?
The module is designed for easy DIN rail mounting, simplifying installation and saving space in control panels.
What is the operating temperature range for this module?
The 140DDO84300C operates within a temperature range of -20°C to 60°C, making it suitable for most industrial environments.
Can multiple 140DDO84300C modules be used in the same system?
Yes, you can combine multiple modules to expand the number of output channels as needed for your application.
Is the 140DDO84300C compatible with Schneider Modicon PLCs?
Yes, this module integrates seamlessly with Schneider Electric’s Modicon PLC systems, providing a scalable solution for a wide range of automation tasks.
Are additional accessories required for installation?
No, the 140DDO84300C is designed for quick and easy installation on DIN rails, with no additional accessories required for basic setup.
