The Schneider Electric 140NOE77100 Ethernet Communication Module is designed to enhance the networking capabilities of Schneider Electric’s Modicon PLC systems. With support for high-speed Ethernet communication and advanced protocol support, this module enables seamless integration with Ethernet-based industrial networks. The 140NOE77100 is ideal for applications requiring reliable data exchange, real-time monitoring, and control, making it an essential component for manufacturing, process automation, and complex industrial environments. It provides robust performance, flexibility, and scalability to meet the needs of modern industrial automation systems.

Technical Specifications

Model: 140NOE77100
Type: Ethernet Communication Module
Communication Protocols: Modbus TCP/IP, Ethernet/IP
Ethernet Ports: 1 x 10/100/1000 Mbps Ethernet Port
Operating Voltage: 24V DC
Power Consumption: 3 W (typical)
Mounting Type: DIN Rail Mount
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Dimensions: 90 mm x 140 mm x 90 mm
Weight: 0.45 kg
Status Indicators: LED indicators for power, network, and communication status

Recommended Related Models

Schneider 140CRA93100: Communication Processor for Modicon PLC systems, offering advanced communication capabilities
Schneider 140EHC20200: Ethernet Communication Module with multiple Ethernet ports for larger network setups
Schneider 140DDM69000C: 64-Point Digital I/O Module for large-scale control systems

Popular Schneider Models

Schneider 140CPU65150: High-performance CPU for Modicon M340 series
Schneider 140CRA93100: Communication Processor designed to enhance network connectivity for Modicon PLCs
Schneider 140DDM69000C: 64-Point Digital I/O Module for extensive I/O management

Applications

The 140NOE77100 Ethernet Communication Module is perfect for a wide variety of industrial automation applications that require reliable and fast communication. Common use cases include:

Manufacturing Automation: Integrates production machines, robotic systems, and centralized control systems over an Ethernet network for real-time monitoring and data exchange.
Process Control: Enables seamless communication in industries like chemical, food processing, and pharmaceuticals, ensuring smooth control of process equipment like valves, pumps, and mixers.
Building Automation: Connects building management systems (BMS), such as HVAC, lighting, and security systems, to PLC networks, ensuring optimized energy use and centralized management.
Material Handling Systems: Supports communication between automated devices such as conveyors, robotic arms, and sorting systems to enhance operational efficiency in warehouses and distribution centers.
Energy Management: Allows real-time communication with energy mete

Advantages

High-Speed Ethernet Communication: The 140NOE77100 supports 10/100/1000 Mbps Ethernet speeds, providing fast, stable, and reliable data transfer for real-time control and monitoring in industrial environments.
Wide Protocol Support: With support for both Modbus TCP/IP and Ethernet/IP, the module offers flexibility in connecting to various industrial devices and systems, making it adaptable to a range of applications.
Compact and Space-Saving Design: Despite its advanced capabilities, the module is compact (90 mm x 140 mm x 90 mm), making it ideal for installation in tight spaces within control panels.
Seamless Integration with Modicon PLCs: Fully compatible with Schneider Electric’s Modicon PLC systems, this module allows for easy network integration and system expansion.
Reliable Performance in Harsh Environments: Designed to operate in environments with temperatures ranging from -20°C to 60°C, the 140NOE77100 ensures dependable performance in various industrial conditions.
LED Status Indicators: Real-time LED indicators for power, network connection, and communication status help simplify troubleshooting and ensure efficient monitoring of the system.

Technical FAQs

What communication protocols does the 140NOE77100 support?
The module supports both Modbus TCP/IP and Ethernet/IP, providing versatile communication options for connecting a wide range of industrial devices.
What is the Ethernet speed supported by this module?
The 140NOE77100 supports Ethernet speeds up to 1 Gbps (1000 Mbps), ensuring fast and reliable data transfer in real-time applications.
How many Ethernet ports does the module have?
The module is equipped with 1 Ethernet port, supporting 10/100/1000 Mbps speeds.
What is the operating voltage for the 140NOE77100?
The 140NOE77100 operates at 24V DC, which is standard for industrial communication modules.
What is the typical power consumption of the module?
The 140NOE77100 typically consumes 3 W of power, making it an energy-efficient communication solution.
How is the 140NOE77100 mounted?
This module is designed for easy DIN rail mounting, making installation straightforward and minimizing the space required in control panels.
What is the operating temperature range for the 140NOE77100?
The module operates within a temperature range of -20°C to 60°C, ensuring stable performance in most industrial environments.
Does the module have any status indicators?
Yes, the 140NOE77100 has LED indicators for network, power, and communication status, allowing easy monitoring of the system’s health.
Can multiple 140NOE77100 modules be used in the same network?
Yes, you can integrate multiple modules within the same system to expand connectivity and enhance network performance.
Is the 140NOE77100 compatible with Schneider Modicon PLCs?
Yes, this module is fully compatible with Schneider Electric’s Modicon PLCs, providing seamless integration into existing control systems.
