The Schneider Electric 140NOM21200 Modbus Communication Module is designed to provide efficient and reliable communication between Schneider Electric’s Modicon PLC systems and Modbus-based devices. Offering support for both Modbus RTU and Modbus TCP/IP communication protocols, this module ensures seamless integration into existing industrial networks. The 140NOM21200 allows for enhanced data exchange, real-time control, and monitoring, making it an ideal solution for applications in manufacturing automation, process control, and other industrial environments that rely on Modbus communication.

Technical Specifications

Model: 140NOM21200
Type: Modbus Communication Module
Communication Protocols: Modbus RTU (RS-485), Modbus TCP/IP
Ethernet Ports: 1 x 10/100/1000 Mbps Ethernet Port (for Modbus TCP)
RS-485 Ports: 1 x RS-485 Port (for Modbus RTU)
Operating Voltage: 24V DC
Power Consumption: 2.9 W (typical)
Mounting Type: DIN Rail Mount
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Dimensions: 90 mm x 140 mm x 90 mm
Weight: 0.45 kg
Status Indicators: LED indicators for power, network, and communication status
