The Schneider ABL8RPS24100 Power Supply Module is a high-capacity, reliable, and efficient solution designed to meet the demanding power requirements of industrial automation systems. With a robust output of 100 W, the ABL8RPS24100 ensures your automation devices, such as PLCs, I/O modules, sensors, and actuators, receive continuous and stable power, even in the most challenging industrial environments. Engineered with efficiency and reliability in mind, this power supply module delivers consistent performance, making it ideal for critical applications where downtime is not an option.

The ABL8RPS24100 is specifically designed for seamless integration with Schneider Electric’s comprehensive range of automation products, allowing for efficient system designs and reduced installation time. With its compact design, extended temperature range, and high power output, it is an ideal choice for a wide array of industrial control, process monitoring, and automation applications.

Technical Specifications

Model: ABL8RPS24100
Type: Power Supply Module
Input Voltage: 100–240 VAC
Output Voltage: 24 VDC
Power Output: 100 W
Output Current: 4.2 A
Dimensions: 90 mm x 70 mm x 140 mm
Weight: 0.85 kg (1.87 lbs)
Operating Temperature: -10°C to 60°C (14°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Protection: IP20 ingress protection
Mounting Type: DIN rail mount
Certifications: CE, UL, RoHS, EN60950 compliant

Recommended Related Models

For extended power capabilities and other industrial automation solutions, consider the following Schneider Electric models:

Schneider ABL8RPS24050: 50 W Power Supply Module, ideal for smaller, less demanding systems
Schneider ABL8RPS48050: 48 VDC Power Supply Module, suitable for high-voltage applications
Schneider ABL8PB10: Power distribution box for distributing power across multiple automation devices
Schneider ABL8RB40: Redundant Power Supply Module, providing continuous power for mission-critical systems

These Schneider models complement the ABL8RPS24100, offering additional options for scaling up or customizing your industrial automation power solution.

Popular Schneider Electric Models

Schneider Modicon M340 – A robust PLC for managing complex industrial processes
Schneider Modicon M580 – ePAC controller for highly distributed automation tasks
Schneider 171CCS70000 – Communication Module for managing network connections within automation systems
Schneider 140DRA96000 – Digital I/O Module for seamless I/O integration in industrial environments
Schneider 171BPS20000 – Power Supply Module for stable power to I/O systems and automation devices

These Schneider models integrate well with the ABL8RPS24100, creating a complete and efficient solution for your automation system.

Applications

The Schneider ABL8RPS24100 Power Supply Module is designed for a wide range of applications where reliable power is critical:

Industrial Automation: Provides stable power for PLCs, I/O modules, sensors, and actuators, ensuring continuous operation in automated processes.
Process Control: Ensures stable power for process monitoring and control systems used in industries such as chemicals, pharmaceuticals, and food & beverage.
Factory Automation: Powers machinery and production lines, improving efficiency and reducing downtime in manufacturing environments.
Energy Management: Powers energy monitoring devices, enabling businesses to optimize energy consumption and reduce operational costs.
Building Automation: Supports the operation of HVAC, lighting, and security systems, enhancing efficiency in commercial and industrial buildings.

Advantages

High Power Output: With a maximum output of 100 W and 4.2 A, the ABL8RPS24100 provides the necessary power for demanding automation applications.
Efficient and Compact: Its high-efficiency design ensures minimal power loss, while the compact form factor saves valuable panel space.
Wide Temperature Range: The module operates efficiently in a wide temperature range of -10°C to 60°C (14°F to 140°F), making it suitable for use in a variety of industrial environments.
Seamless Integration: Designed for easy integration with Schneider Electric’s PLCs and I/O modules, the ABL8RPS24100 simplifies installation and reduces setup time.
DIN Rail Mounting: This module is compatible with DIN rail mounting, ensuring a quick and secure installation process.
Built-In Protection: With an IP20 protection rating, the module is protected from dust and small objects, increasing its longevity and reliability in industrial settings.
Global Compliance: The ABL8RPS24100 is CE, UL, RoHS, and EN60950 compliant, ensuring it meets international safety and environmental standards.

Technical FAQs

What is the output power of the ABL8RPS24100?
The ABL8RPS24100 provides 100 W of power, with a 24 VDC output and a maximum current of 4.2 A.
What input voltage does the ABL8RPS24100 support?
The module accepts an input voltage range of 100–240 VAC.
What is the operating temperature range of the ABL8RPS24100?
The module operates in a temperature range of -10°C to 60°C (14°F to 140°F).
How is the ABL8RPS24100 mounted?
The ABL8RPS24100 is designed for DIN rail mounting, ensuring easy installation and secure mounting in control panels.
What protection rating does the ABL8RPS24100 have?
The ABL8RPS24100 has an IP20 protection rating, offering basic protection against dust and small foreign objects.
What certifications does the ABL8RPS24100 have?
The module is CE, UL, RoHS, and EN60950 certified, ensuring compliance with international safety and environmental standards.
What is the weight of the ABL8RPS24100?
The ABL8RPS24100 weighs 0.85 kg (1.87 lbs).
Can the ABL8RPS24100 be used in outdoor applications?
No, the ABL8RPS24100 is intended for indoor use with an IP20 protection rating and should not be exposed to harsh outdoor environments.
What is the storage temperature range of the ABL8RPS24100?
The module can be stored in temperatures ranging from -40°C to 85°C (-40°F to 185°F).
Can the ABL8RPS24100 support redundant power configurations?
The ABL8RPS24100 does not have built-in redundancy; however, Schneider Electric offers redundant power solutions, such as the ABL8RB40, for high-availability applications.
