The Schneider ATV340D45N4E Variable Frequency Drive (VFD) is a high-power, high-performance motor control solution designed for complex and demanding industrial applications. With a rated output power of 45 kW, the ATV340D45N4E is engineered to provide precise, energy-efficient control for large motors, commonly used in applications like pumps, conveyors, HVAC systems, and manufacturing equipment. It offers advanced features that help improve performance, optimize energy usage, and extend the life of your equipment.

As part of the ATV340 series, the ATV340D45N4E provides enhanced motor control capabilities, including Sensorless Vector Control (SVC) and V/f control, which ensure smooth and reliable operation across various industrial settings. This VFD is ideal for applications requiring high torque and power, ensuring that your systems operate efficiently and reliably even in the most challenging environments.

Technical Specifications

Model: ATV340D45N4E
Type: Variable Frequency Drive (VFD)
Power Supply: 3-phase, 380–480 VAC ±10%, 50/60 Hz
Rated Output Power: 45 kW
Rated Output Current: 85 A
Input Current: 60 A
Dimensions: 395 mm x 330 mm x 395 mm
Weight: 27.5 kg (60.6 lbs)
Control Mode: V/f control, Sensorless Vector Control (SVC)
Cooling Method: Forced air cooling with internal fan
Protection: IP20 ingress protection
Mounting Type: Wall-mounted, panel installation
Environmental Conditions:
- Operating Temperature: -10°C to 50°C (14°F to 122°F)
- Storage Temperature: -40°C to 70°C (-40°F to 158°F)
- Humidity: 0–95% RH (non-condensing)
Certifications: CE, UL, RoHS, and CSA compliant

Recommended Related Models

For users requiring different power options or additional capabilities, Schneider Electric offers a range of complementary VFDs:

Schneider ATV340D55N4E: A higher power variant (55 kW) of the ATV340 series, suitable for more demanding motor control needs.
Schneider ATV320U75N4C: A 75 kW VFD for more complex motor control tasks, offering additional features for advanced automation systems.
Schneider ATV600: A heavy-duty VFD for high-power industrial applications, ideal for large-scale motors and complex automation systems.
Schneider ABE7CPA02: An auxiliary control device to expand the functionality of Schneider Electric’s motor control products in automation systems.
Schneider ABL8REM24050: A power supply module designed to complement Schneider Electric’s VFDs for consistent and efficient performance.

These Schneider models enhance the versatility and scalability of your motor control systems and allow for seamless integration into various industrial applications.

Popular Schneider Electric Models

Schneider Modicon M340 – A powerful PLC for complex industrial automation processes and control systems.
Schneider ATV12 – A cost-effective and compact VFD for small motors and basic motor control applications.
Schneider ATV320 – A versatile VFD ideal for medium-sized applications, offering an excellent balance of performance and energy savings.
Schneider ATV600 – A high-end VFD with advanced features for managing large motors in demanding industrial environments.
Schneider Altivar 32 – A compact, energy-efficient drive for smaller-scale motor control needs.

These models can complement the ATV340D45N4E, offering a full suite of solutions for a wide variety of motor control tasks.

Applications

The Schneider ATV340D45N4E VFD is designed for applications that require reliable and high-performance motor control. It is widely used in the following industries and applications:

Pumps: Ideal for controlling pumps in water treatment, HVAC, and industrial processes, optimizing flow rates and energy consumption.
Conveyors: Ensures smooth and efficient operation of conveyors in material handling and logistics, reducing downtime and improving throughput.
HVAC Systems: Controls motors in HVAC applications, including fans and air handling units, improving efficiency and reducing energy consumption.
Manufacturing: Powers motors in production lines, enabling precise control over speed and torque to enhance operational efficiency and product quality.
Mining and Mineral Processing: Handles high-torque applications in mining equipment, providing reliable motor control for heavy machinery.
Cooling and Refrigeration: Optimizes compressor and fan speeds in cooling systems, improving energy efficiency and reducing operational costs.
Elevators and Lifts: Controls the operation of high-powered motors in vertical transportation systems, ensuring smooth, reliable movement.

Advantages

High Power Output: With 45 kW of output power, the ATV340D45N4E is well-suited for large industrial applications, providing the necessary torque and performance for demanding tasks.
Energy Efficiency: The drive dynamically adjusts motor speed based on load, significantly reducing energy consumption and operating costs, making it an ideal solution for energy-conscious operations.
Advanced Control Features: Featuring Sensorless Vector Control (SVC) and V/f control, the ATV340D45N4E ensures smooth motor control with precise speed and torque regulation, reducing mechanical stress and enhancing equipment lifespan.
Compact Design: Despite its high power output, the ATV340D45N4E features a compact and space-saving design, making it easy to integrate into existing systems without requiring significant space.
Durability and Reliability: With IP20 ingress protection and forced air cooling, this VFD is built to withstand harsh industrial conditions and ensure reliable operation over time.
Ease of Integration: The ATV340D45N4E integrates seamlessly with other Schneider Electric automation products, including PLCs, I/O devices, and control panels, streamlining installation and configuration.
User-Friendly Interface: The intuitive interface simplifies drive setup, operation, and monitoring, reducing the need for specialized training and improving overall ease of use for operators.

Technical FAQs

What is the rated output power of the ATV340D45N4E?
The ATV340D45N4E has a rated output power of 45 kW.
What is the input voltage range for the ATV340D45N4E?
The VFD operates on a 3-phase input voltage of 380–480 VAC ±10%.
What motor control modes does the ATV340D45N4E support?
The drive supports both V/f control and Sensorless Vector Control (SVC) for efficient motor speed and torque regulation.
What is the operating temperature range for the ATV340D45N4E?
The drive operates in temperatures from -10°C to 50°C (14°F to 122°F).
How much does the ATV340D45N4E weigh?
The ATV340D45N4E weighs 27.5 kg (60.6 lbs).
Can the ATV340D45N4E be used outdoors?
No, the drive is rated with IP20 protection, which is suitable for indoor use only.
What cooling method does the ATV340D45N4E use?
The drive uses forced air cooling with an internal fan to maintain optimal temperature during operation.
What certifications does the ATV340D45N4E have?
The ATV340D45N4E is CE, UL, RoHS, and CSA certified, ensuring it meets international safety and environmental standards.
What is the storage temperature range for the ATV340D45N4E?
The drive can be stored in temperatures ranging from -40°C to 70°C (-40°F to 158°F).
Can I integrate the ATV340D45N4E with other Schneider Electric products?
Yes, the ATV340D45N4E integrates seamlessly with other Schneider Electric automation systems, including PLCs, HMI panels, and I/O modules.
