The Schneider ATV630D37N4 is a robust and high-performance Variable Frequency Drive (VFD) engineered to meet the needs of demanding industrial applications. With a rated output power of 37 kW, this drive offers exceptional motor control and efficiency for controlling large motors in industries such as manufacturing, HVAC, water treatment, material handling, and many others. The ATV630D37N4 utilizes Sensorless Vector Control (SVC) and V/f control to ensure precise speed and torque regulation, making it an ideal solution for high-torque, high-load applications.

Designed for reliability and versatility, the ATV630D37N4 is part of Schneider Electric’s advanced ATV630 series, offering superior motor control, energy savings, and enhanced integration capabilities. This drive ensures seamless operation in harsh industrial environments and is optimized for applications that require both power and precision.

Technical Specifications

Model: ATV630D37N4
Type: Variable Frequency Drive (VFD)
Power Supply: 3-phase, 380–480 VAC ±10%, 50/60 Hz
Rated Output Power: 37 kW
Rated Output Current: 72 A
Input Current: 54 A
Dimensions: 450 mm x 320 mm x 580 mm
Weight: 29.5 kg (65 lbs)
Control Mode: V/f control, Sensorless Vector Control (SVC)
Cooling Method: Forced air cooling with internal fan
Protection: IP20 ingress protection
Mounting Type: Wall-mounted, panel installation
Environmental Conditions:
- Operating Temperature: -10°C to 50°C (14°F to 122°F)
- Storage Temperature: -40°C to 70°C (-40°F to 158°F)
- Humidity: 0–95% RH (non-condensing)
Certifications: CE, UL, RoHS, and CSA compliant

Recommended Related Models

Schneider Electric offers a range of complementary models for different power requirements or additional features:

Schneider ATV630D45N4: A higher-rated drive with 45 kW of output power, ideal for larger motors and applications requiring higher torque and performance.
Schneider ATV320U37N4C: A compact, 37 kW VFD offering advanced energy-saving features, suited for space-limited applications without sacrificing control precision.
Schneider ATV600: A heavy-duty VFD for high-torque, demanding applications in harsh industrial environments, such as mining and steel production.
Schneider ABE7CPA02: An auxiliary control unit that complements Schneider Electric VFDs, providing greater flexibility and control options for complex systems.
Schneider ABL8REM24050: A power supply module that ensures smooth, reliable operation of Schneider Electric’s VFD systems in large-scale industrial setups.

These models allow you to tailor the motor control solution to your specific industrial needs while maintaining seamless system integration.

Popular Schneider Electric Models

Schneider Modicon M340 – A scalable and flexible PLC for modern industrial automation applications.
Schneider ATV12 – A cost-effective, compact VFD for smaller motor control applications, perfect for light-duty operations.
Schneider ATV320 – A versatile and energy-efficient VFD suitable for general industrial applications, offering excellent performance for medium-sized motors.
Schneider ATV600 – A robust solution for controlling large motors in high-demand applications such as heavy industry and material handling.
Schneider Altivar 32 – A user-friendly VFD designed for small to medium motors, ideal for basic automation tasks and general motor control.

These models can integrate well with the ATV630D37N4 to offer a complete, scalable motor control solution.

Applications

The Schneider ATV630D37N4 is designed for high-power, high-precision applications where reliable motor control is crucial. It is commonly used in the following sectors:

HVAC Systems: Optimizes energy consumption in HVAC systems by regulating the speed of motors in air handling units, fans, and chillers, providing consistent climate control with reduced energy costs.
Pumps: Controls pumps in water treatment, chemical dosing, and industrial fluid transfer systems, offering precise flow control while minimizing energy usage.
Compressors: Ideal for controlling air and refrigeration compressors, ensuring smooth and efficient operation while reducing energy consumption and operational costs.
Conveyors: Perfect for controlling large motors in material handling, mining, and logistics, improving system efficiency and reducing wear on mechanical components.
Manufacturing: Powers motors in production lines, robotics, and heavy manufacturing processes, delivering precise speed control and enabling flexible motor-driven automation.
Mining and Heavy Industry: Designed for use in high-torque, high-load applications such as crushers, mills, and other mining equipment, ensuring reliable motor control in harsh conditions.
Water and Wastewater Treatment: Controls motors in pumps, filtration systems, and chemical dosing equipment, ensuring operational efficiency and reliability in water and wastewater treatment processes.

Advantages

High-Precision Motor Control: The ATV630D37N4 offers Sensorless Vector Control (SVC) for precise motor control even under varying loads, making it perfect for applications that require high torque and accurate speed regulation.
Energy Efficiency: The VFD’s advanced control features help reduce energy consumption by adjusting motor speed according to the load, resulting in significant energy savings and reduced operational costs.
Compact and Robust Design: Despite its high power output, the ATV630D37N4 has a compact and rugged design with IP20 protection, making it ideal for industrial settings where space is limited but high performance is essential.
Seamless Integration: The ATV630D37N4 integrates easily with other Schneider Electric automation products, such as PLCs, HMIs, and I/O devices, providing a complete, cohesive solution for motor control.
User-Friendly Interface: The intuitive control panel ensures easy setup, operation, and monitoring, minimizing downtime and reducing the need for specialized training.
Extended Motor Lifespan: By optimizing motor performance and reducing mechanical wear, the ATV630D37N4 helps extend the lifespan of motors and other connected equipment, reducing maintenance and replacement costs.
Flexible Installation Options: The ATV630D37N4 can be mounted on a wall or within a panel, offering flexibility in installation and saving space in your control system.

Technical FAQs

What is the rated output power of the ATV630D37N4?
The ATV630D37N4 offers a rated output power of 37 kW.
What voltage range does the ATV630D37N4 support?
The VFD supports a 3-phase input voltage range of 380–480 VAC ±10%.
What motor control modes does the ATV630D37N4 use?
It supports V/f control and Sensorless Vector Control (SVC), providing high precision and torque control for a wide range of applications.
What is the temperature range for the ATV630D37N4?
The drive operates in the temperature range of -10°C to 50°C (14°F to 122°F).
What is the weight of the ATV630D37N4?
The ATV630D37N4 weighs 29.5 kg (65 lbs).
Can the ATV630D37N4 be used outdoors?
No, the ATV630D37N4 is designed for indoor use only, with IP20 protection.
What cooling method is used in the ATV630D37N4?
The drive uses forced air cooling with an internal fan to maintain optimal operating temperatures.
What certifications does the ATV630D37N4 have?
The drive is certified for CE, UL, RoHS, and CSA, ensuring compliance with global safety and environmental standards.
What is the storage temperature range for the ATV630D37N4?
The storage temperature range is -40°C to 70°C (-40°F to 158°F).
Can the ATV630D37N4 integrate with other Schneider Electric products?
Yes, the ATV630D37N4 is compatible with other Schneider Electric automation products, such as PLCs, HMIs, and I/O devices, enabling a fully integrated motor control solution.
