The Schneider BMXAMO0802 is a 16-channel digital output module designed for integration with the Modicon M340 PLC. This module is part of Schneider Electric's Modicon M340 range, offering a high-performance, scalable solution for controlling multiple digital devices in industrial automation systems. Whether you’re managing actuators, relays, solenoids, or other industrial equipment, the BMXAMO0802 provides a reliable interface for controlling up to 16 digital outputs.

Ideal for applications that require high output capacity, the BMXAMO0802 is built to handle demanding environments while maintaining precision and performance. With 24V DC output voltage and a current rating of 0.5 A per channel, this module provides robust control over industrial devices, contributing to the efficient operation of automated systems in industries like manufacturing, process control, and energy management.

Technical Specifications

Model: BMXAMO0802
Type: Digital Output Module
PLC Compatibility: Modicon M340
Number of Outputs: 16 digital outputs
Output Voltage: 24V DC
Output Current: 0.5 A per channel
Output Type: Sinking (Negative Logic)
Mounting Type: DIN rail mount
Dimensions: 135 mm x 80 mm x 60 mm
Weight: 0.5 kg (1.1 lbs)
Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Power Supply: Powered from Modicon M340 power supply
Protection: IP20 (Protection against dust and accidental contact with electrical parts)
Communication Protocol: Modbus RTU via Modbus bus
Certifications: CE, UL, RoHS compliant

Recommended Related Models

For different types of digital or analog control, Schneider Electric provides a variety of complementary modules for the Modicon M340 PLC:

Schneider BMXAMO0410: A 16-channel digital output module, offering similar functionality with 0.5 A per channel and 24V DC output, ideal for applications requiring a larger number of outputs.
Schneider BMXAMO0210: An 8-channel digital output module, perfect for applications with fewer digital outputs while maintaining reliable performance.
Schneider BMXAMO0810: A 32-channel digital output module, designed for applications requiring high output density, such as large automation systems or complex industrial processes.
Schneider BMXPPS2000: A power supply module for the Modicon M340, ensuring stable power delivery and reliable operation across all connected modules.
Schneider BMXDRA0800: A digital relay output module with 8 channels, useful for systems requiring dry contact outputs for switching high-voltage or inductive loads.

These models are highly compatible with each other, enabling seamless expansion and optimization of Modicon M340-based control systems.

Popular Schneider Electric Models

Schneider Modicon M340 – A modular and flexible PLC platform that offers high performance for medium to large-scale industrial applications.
Schneider Modicon M580 – An advanced modular PLC offering enhanced processing power, real-time communication, and advanced cybersecurity, suitable for large, distributed systems.
Schneider ATV320 – A Variable Frequency Drive (VFD) that provides precise motor control for small-to-medium-sized motors used in applications like HVAC, pumps, and conveyors.
Schneider ATV630 – A high-performance VFD for demanding industrial applications, capable of controlling large motors with precision in systems such as crushers, mills, and industrial fans.
Schneider EcoStruxure™ Control Expert – Schneider Electric’s software platform for designing and programming automation systems, enhancing productivity and simplifying integration with Modicon PLCs.

These models, when combined with the BMXAMO0802, deliver complete and powerful automation solutions for industrial applications.

Applications

The Schneider BMXAMO0802 digital output module is suitable for controlling a wide variety of devices across various industries. Some key applications include:

Manufacturing Automation: Ideal for controlling machines, conveyors, and automated robotic systems in production lines and packaging processes.
Process Control: Controls actuators, solenoids, and valves in chemical, pharmaceutical, food and beverage, and other process industries.
HVAC Systems: Provides output control for HVAC systems, managing fans, compressors, and temperature sensors to maintain precise climate conditions in large buildings or industrial facilities.
Energy Management: Controls energy-consuming devices, such as lighting systems, heating, ventilation, and cooling (HVAC) units, optimizing energy usage across commercial and industrial environments.
Material Handling: Manages control systems for conveyors, sorting machines, and robotic arms in warehouses and logistics operations.
Safety Systems: Triggers alarms, shutdown procedures, or emergency systems, ensuring rapid response to safety incidents or system failures.

With 16 digital outputs, the BMXAMO0802 is particularly suited for large-scale applications requiring precise control and output management across a variety of connected devices.

Advantages

High Output Density: With 16 output channels, the BMXAMO0802 provides a compact and scalable solution for systems requiring multiple outputs in a single module.
Precise and Reliable Control: Each output channel handles up to 0.5 A at 24V DC, making it ideal for controlling various industrial devices, from relays to actuators.
Flexible Integration: Fully compatible with the Modicon M340 PLC, the module integrates seamlessly into automation systems and supports system expansion.
Durable and Robust: Built for industrial environments, the BMXAMO0802 has an IP20 protection rating, ensuring longevity and reliability even in challenging conditions.
Compact and Easy to Install: The DIN rail mountable design simplifies installation and saves space in control panels or enclosures, keeping systems organized and efficient.
Energy Efficiency: By providing precise control over industrial equipment, the BMXAMO0802 helps optimize energy consumption, contributing to cost savings in large-scale operations.
Scalability: The module is ideal for both small and large applications, with the flexibility to add more modules as system requirements grow.

Technical FAQs

How many digital outputs does the BMXAMO0802 provide?
The BMXAMO0802 provides 16 digital output channels, ideal for applications requiring a large number of outputs.
What is the output voltage of the BMXAMO0802?
The module offers 24V DC output voltage, suitable for controlling various industrial devices.
What is the current rating per output channel?
Each output channel can handle 0.5 A of current.
What type of output logic does the BMXAMO0802 use?
The BMXAMO0802 uses sinking output logic (negative logic), making it compatible with a wide range of industrial equipment.
What is the protection rating for the BMXAMO0802?
The module has an IP20 protection rating, which protects it against dust and accidental contact with electrical components.
What is the mounting type for the BMXAMO0802?
The module is designed for DIN rail mounting, ensuring easy installation in control panels or automation cabinets.
What is the operating temperature range of the BMXAMO0802?
The module operates within a temperature range of 0°C to 60°C (32°F to 140°F).
How does the BMXAMO0802 communicate with the Modicon M340 PLC?
It communicates via Modbus RTU over the Modbus bus, allowing seamless integration with the Modicon M340 PLC and other compatible devices.
What certifications does the BMXAMO0802 have?
The module is CE, UL, and RoHS certified, ensuring it meets international safety and environmental standards.
Can the BMXAMO0802 be used in hazardous environments?
The BMXAMO0802 is designed for use in general industrial environments and is not suitable for hazardous locations. It should be used in areas free from explosive gases or dangerous substances.
