The Schneider BMXCPS2000 is a power supply module designed to provide reliable and stable power for Modicon M340 PLC systems. As part of Schneider Electric's Modicon M340 platform, this power supply module plays a critical role in ensuring continuous operation of the entire PLC system, including input and output modules, communication devices, and other connected components.

With a power output of 24V DC, the BMXCPS2000 is engineered to deliver the necessary power to support the Modicon M340 PLC and its associated modules in demanding industrial environments. This power supply module is known for its efficiency, durability, and ease of integration, making it a key component in any control system that requires reliable and stable power distribution.

The BMXCPS2000 offers a redundant power supply option, enhancing the reliability of the automation system by providing backup power in case of failure, making it especially suitable for mission-critical applications in industries such as manufacturing, process control, and energy management.

Technical Specifications

Model: BMXCPS2000
Type: Power Supply Module
PLC Compatibility: Modicon M340
Input Voltage Range: 100-240V AC (Wide range for international compatibility)
Output Voltage: 24V DC
Power Output: 20W
Mounting Type: DIN rail mountable
Dimensions: 90 mm x 120 mm x 60 mm
Weight: 0.4 kg (0.88 lbs)
Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Efficiency: ≥ 90% (high efficiency for low energy consumption)
Protection: IP20 (Protection against dust and accidental contact with electrical components)
Certifications: CE, UL, RoHS compliant
Redundancy: Available with redundant power options, allowing for continuous power supply without interruption.

Recommended Related Models

For applications requiring additional power or different configurations, Schneider Electric offers a range of compatible power supply modules that can work with the Modicon M340 PLC:

Schneider BMXCPS1000: A 10W power supply module for smaller or less demanding applications within the Modicon M340 PLC family.
Schneider BMXCPS3000: A 30W power supply module, designed for systems requiring higher power outputs for larger-scale operations or high-power modules.
Schneider BMXPPS2000: Another power supply module designed specifically for the Modicon M340, with higher output and features for more extensive automation needs.

Each of these power supplies ensures stable and reliable operation of the Modicon M340 PLC, with redundancy and scalability to suit various system sizes and power requirements.

Popular Schneider Electric Models

Schneider Modicon M340 – A highly versatile and scalable PLC system designed for medium-to-large-scale industrial applications. It supports various I/O modules, communication modules, and expansion options.
Schneider Modicon M580 – A high-performance, fully redundant PLC system offering advanced capabilities for real-time data processing, distributed control, and robust cybersecurity.
Schneider ATV320 – A Variable Frequency Drive (VFD) that provides precise motor control, ensuring efficient operation in applications such as HVAC, pumps, conveyors, and more.
Schneider ATV630 – A rugged and high-performance VFD designed for demanding industrial processes, such as controlling large motors in crushers, mills, and fans.
Schneider EcoStruxure™ Control Expert – Schneider Electric’s integrated software platform for programming and configuring Modicon PLCs, enhancing productivity and streamlining automation processes.

The BMXCPS2000, when combined with these and other Schneider Electric products, provides a complete, reliable, and scalable automation solution.

Applications

The Schneider BMXCPS2000 power supply module is an essential component for applications that require stable and continuous power for automation systems. Key applications include:

Manufacturing Automation: Provides the necessary power to control systems for production lines, robotic arms, conveyors, and other manufacturing equipment.
Process Control: Ensures reliable power to systems that manage industrial processes such as mixing, heating, or chemical reactions in industries like chemicals, pharmaceuticals, and food processing.
HVAC Systems: Powers control systems for heating, ventilation, and air conditioning (HVAC) systems in large buildings or industrial environments, maintaining temperature, humidity, and air quality.
Energy Management: Supplies power to energy-efficient systems and devices, such as transformers, lighting, and climate control systems in large commercial and industrial buildings.
Water Treatment: Powers control systems for water and wastewater treatment facilities, ensuring proper functioning of pumps, sensors, and valves.
Energy Distribution: Used in power distribution systems where stable power is required for controlling switches, circuit breakers, and other electrical devices.

The BMXCPS2000 is ideal for any industrial application that demands reliable, redundant, and continuous power for PLC-based control systems.

Advantages

High Efficiency: With an efficiency rate of ≥90%, the BMXCPS2000 minimizes energy waste, helping to reduce overall energy costs in your automation system.
Redundancy Option: The ability to incorporate redundant power supplies ensures that your system remains operational even in the event of power supply failure, increasing reliability and uptime.
Wide Input Voltage Range: The 100-240V AC input voltage range ensures compatibility with international power standards, making the BMXCPS2000 suitable for global deployments.
Durable and Reliable: With an IP20 protection rating, the power supply module is designed to withstand dust and physical impacts, ensuring long-term durability in industrial environments.
Compact Design: The DIN rail mountable design allows for easy installation in control cabinets or automation panels, saving valuable space while providing powerful support for the Modicon M340 PLC system.
Flexible and Scalable: The module’s scalable power output allows for integration into various automation systems, from small control applications to larger industrial setups.
Global Certifications: Certified with CE, UL, and RoHS, the BMXCPS2000 meets international safety and environmental standards, ensuring safe and compliant operation.

Technical FAQs

What is the output voltage of the BMXCPS2000?
The BMXCPS2000 provides a 24V DC output voltage, ideal for powering Modicon M340 PLC and associated modules.
What is the power output of the BMXCPS2000?
The module offers a 20W power output, which is sufficient for most Modicon M340 PLC setups.
What is the input voltage range for the BMXCPS2000?
The module accepts an input voltage range of 100-240V AC, making it suitable for use in a variety of international environments.
Can the BMXCPS2000 be used in redundant configurations?
Yes, the BMXCPS2000 supports redundant power configurations, ensuring continuous power availability for critical applications.
What certifications does the BMXCPS2000 have?
The module is CE, UL, and RoHS certified, meeting international safety, quality, and environmental standards.
What is the operating temperature range of the BMXCPS2000?
The BMXCPS2000 operates within the temperature range of 0°C to 60°C (32°F to 140°F).
What is the protection rating of the BMXCPS2000?
The module has an IP20 protection rating, providing protection against dust and accidental contact with electrical parts.
How is the BMXCPS2000 mounted?
The BMXCPS2000 is designed for DIN rail mounting, making it easy to install in control panels or automation cabinets.
What is the weight of the BMXCPS2000?
The BMXCPS2000 weighs approximately 0.4 kg (0.88 lbs), making it lightweight and easy to handle during installation.
Can the BMXCPS2000 be used with other Schneider Electric PLCs?
While the BMXCPS2000 is specifically designed for the Modicon M340, it may also be compatible with other Schneider Electric PLCs that use similar voltage and power requirements.
