The Schneider BMXCPS2010 is a high-performance power supply module designed specifically for use with the Modicon M340 PLC system. It provides reliable and efficient 24V DC power for the operation of the Modicon M340 and its connected modules, including digital I/O, analog I/O, and communication modules. Whether you're integrating a small-scale or large-scale industrial control system, the BMXCPS2010 ensures a stable power source to keep your system functioning efficiently.

Offering an output power of 40W, the BMXCPS2010 provides an ideal solution for larger setups or systems that require more power for additional modules. It also includes redundancy options, further enhancing the reliability of your automation system by ensuring continuous power even in the event of a failure. This makes the BMXCPS2010 an excellent choice for mission-critical applications in industries such as manufacturing, process control, and energy management.

Technical Specifications

Model: BMXCPS2010
Type: Power Supply Module
PLC Compatibility: Modicon M340
Input Voltage Range: 100-240V AC
Output Voltage: 24V DC
Power Output: 40W
Mounting Type: DIN rail mountable
Dimensions: 90 mm x 120 mm x 60 mm
Weight: 0.5 kg (1.1 lbs)
Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Efficiency: ≥ 90% (energy-efficient design for low operational costs)
Protection: IP20 (Protection against dust and accidental contact with electrical parts)
Redundancy: Supports redundant power for enhanced reliability and backup in critical applications
Certifications: CE, UL, RoHS compliant

Recommended Related Models

For additional power supply needs or to complement your existing Modicon M340 system, Schneider Electric offers a variety of compatible modules:

Schneider BMXCPS1000: A 10W power supply module designed for smaller applications or when fewer modules need to be powered.
Schneider BMXCPS2000: A 20W power supply module, ideal for standard setups requiring moderate power output.
Schneider BMXCPS3000: A 30W power supply module offering more power for larger systems that require additional output capacity.
Schneider BMXPPS2000: Another power supply module designed for the Modicon M340, offering different output capacities and features for scaling systems.

Each of these modules allows you to customize your Modicon M340 PLC system based on your power requirements and system size.

Popular Schneider Electric Models

Schneider Modicon M340 – A modular PLC system that offers high performance, flexibility, and scalability for medium to large-scale automation projects.
Schneider Modicon M580 – A high-performance PLC system designed for large-scale and mission-critical applications, supporting real-time processing, distributed control, and advanced cybersecurity.
Schneider ATV320 – A Variable Frequency Drive (VFD) designed for precise motor control in HVAC systems, conveyors, pumps, and other industrial processes.
Schneider ATV630 – A high-performance VFD for controlling large motors in demanding industrial environments such as mills, crushers, and fans.
Schneider EcoStruxure™ Control Expert – A software platform designed for configuring, programming, and managing Modicon PLCs, enhancing productivity and streamlining system integration.

These Schneider Electric products, when combined with the BMXCPS2010, create a robust and scalable solution for industrial automation.

Applications

The Schneider BMXCPS2010 is suitable for a wide range of industrial applications requiring a reliable power source for the Modicon M340 PLC and its connected modules:

Manufacturing Automation: Provides essential power for controlling automated processes such as assembly lines, robotic arms, and material handling systems.
Process Control: Powers systems in industries like chemical processing, food production, and pharmaceuticals, where precise and reliable control is essential for maintaining consistent quality.
Energy Management: Used in energy monitoring and control systems, enabling efficient management of power distribution, transformers, lighting, and HVAC systems in large commercial and industrial settings.
Water Treatment: Supports critical infrastructure in water and wastewater treatment facilities, ensuring reliable power for pumps, sensors, and control valves.
HVAC Systems: Provides the necessary power for controlling HVAC components, such as fans, pumps, compressors, and temperature sensors, helping maintain optimal environmental conditions in buildings and industrial environments.
Building Automation: Supports control systems for building automation, including security, lighting, HVAC, and energy management, optimizing operational efficiency and sustainability.

The BMXCPS2010 is perfect for larger systems that require more power, ensuring stable and reliable operation across a broad spectrum of industries.

Advantages

High Power Output: With a 40W power output, the BMXCPS2010 is ideal for applications requiring a higher level of power, such as large-scale industrial automation systems.
Energy Efficiency: With ≥ 90% efficiency, the module minimizes energy losses, helping to reduce operating costs while ensuring the efficient operation of the system.
Redundant Power Option: The module supports redundant power configurations, enhancing system reliability and uptime by ensuring continuous power even in the event of a failure.
Wide Input Voltage Range: The 100-240V AC input voltage range ensures that the module can be used in various global regions with different power standards, making it a versatile solution for international projects.
Durability and Reliability: Rated IP20, the BMXCPS2010 is designed to withstand dust and accidental contact, providing long-term durability in industrial environments.
Compact Design: The module’s DIN rail mountable design simplifies installation in control panels, saving space and offering easy integration into existing systems.
Global Certifications: Certified with CE, UL, and RoHS, the BMXCPS2010 meets international standards for safety, quality, and environmental protection.

Technical FAQs

What is the power output of the BMXCPS2010?
The BMXCPS2010 provides 40W of power, making it suitable for larger Modicon M340 PLC setups.
What is the input voltage range for the BMXCPS2010?
The module supports an input voltage range of 100-240V AC, compatible with global power standards.
Does the BMXCPS2010 support redundant power?
Yes, the BMXCPS2010 supports redundant power configurations, ensuring uninterrupted power supply for critical applications.
What is the output voltage of the BMXCPS2010?
The module provides a stable 24V DC output voltage for powering Modicon M340 PLC and other connected modules.
What is the weight of the BMXCPS2010?
The BMXCPS2010 weighs approximately 0.5 kg (1.1 lbs), making it lightweight and easy to handle during installation.
Can the BMXCPS2010 be used in outdoor environments?
The BMXCPS2010 has an IP20 rating, meaning it is protected from dust and accidental contact, but it should be installed in a controlled, indoor environment.
What is the efficiency of the BMXCPS2010?
The BMXCPS2010 has an efficiency of ≥ 90%, ensuring optimal energy use and minimal power wastage.
What is the temperature range for the BMXCPS2010?
The module operates within an ambient temperature range of 0°C to 60°C (32°F to 140°F).
Can the BMXCPS2010 be used with other Schneider Electric PLCs?
While the BMXCPS2010 is specifically designed for the Modicon M340, it may be compatible with other Schneider Electric PLCs that have similar power requirements.
What certifications does the BMXCPS2010 have?
The module is certified for CE, UL, and RoHS compliance, ensuring it meets international standards for safety, environmental impact, and quality.
