The Schneider BMXCRA31210 is a digital input/output (I/O) module designed for use with the Modicon M340 PLC platform. This module plays a critical role in interfacing the PLC with external digital devices, enabling it to collect input signals and control output devices in industrial automation systems. Featuring 16 digital inputs and 16 digital outputs, the BMXCRA31210 is perfect for handling a wide range of industrial processes that require robust digital signal processing.

With its high reliability and compatibility with the Modicon M340 PLC, the BMXCRA31210 is ideal for applications where control and monitoring of digital signals are crucial. Whether you're working in manufacturing, process control, or building automation, this module allows your automation system to efficiently handle external devices such as sensors, switches, relays, and actuators.

Technical Specifications

Model: BMXCRA31210
Type: Digital Input/Output Module
PLC Compatibility: Modicon M340
Number of Inputs: 16 digital inputs
Number of Outputs: 16 digital outputs
Input Voltage Range: 24V DC
Output Voltage Range: 24V DC
Input Type: Sinking/Sourcing (configurable)
Output Type: Transistor (NPN/PNP)
Module Type: Discrete
Mounting Type: DIN rail mountable
Dimensions: 90 mm x 120 mm x 60 mm
Weight: 0.45 kg (0.99 lbs)
Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Protection: IP20 (protection against dust and accidental contact with electrical parts)
Certifications: CE, UL, RoHS compliant
