The Schneider BMXDDO1612 is a 16-channel digital output module specifically designed for use with the Modicon M580 PLC. This module provides high-density output control for industrial automation systems, enabling the management of actuators, motors, relays, and valves with ease and reliability. The BMXDDO1612 is ideal for applications that require both flexibility and high performance, such as manufacturing, process control, building automation, and energy management.

With its 16 digital outputs, the BMXDDO1612 is engineered to operate in environments where multiple outputs are needed to control various devices across complex industrial systems. Designed for seamless integration with the Modicon M580 PLC, this module supports both NPN and PNP output configurations and delivers 24V DC signals, making it a highly versatile solution for modern industrial control systems.

Technical Specifications

Model: BMXDDO1612
Type: 16-Channel Digital Output Module
PLC Compatibility: Modicon M580
Number of Outputs: 16 digital outputs
Output Voltage: 24V DC
Output Type:
- Transistor (NPN/PNP)
Signal Type: Digital (ON/OFF)
Mounting Type: DIN rail mountable
Dimensions: 140 mm x 120 mm x 60 mm
Weight: 0.55 kg (1.21 lbs)
Operating Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Protection Rating: IP20 (dust and accidental contact protection)
Certifications: CE, UL, RoHS compliant

Recommended Related Models

To extend the capabilities of your Modicon M580 PLC system, Schneider Electric offers several complementary I/O modules and accessories:

Schneider BMXDDI1612: A 16-channel digital input module, ideal for applications requiring high-density digital inputs to monitor devices such as sensors and limit switches.
Schneider BMXDAI1602: A 16-channel analog input module, perfect for integrating temperature sensors, pressure sensors, and other analog field devices into your system.
Schneider BMXPIF0200: A communication interface module, enabling communication between the Modicon M580 PLC and field devices over various industrial protocols, including Modbus and Ethernet/IP.

These modules allow you to customize your automation system to meet specific application needs, expanding I/O capacity and communication flexibility.

Popular Schneider Electric Models

Schneider Modicon M580 – A high-performance, Ethernet-enabled PLC designed for critical applications, offering cybersecurity, redundancy, and real-time control.
Schneider Modicon M340 – A scalable PLC solution for mid-range automation projects, offering flexible I/O expansion and communication options.
Schneider ATV320 – A Variable Frequency Drive (VFD) that provides efficient motor control for applications such as HVAC, pumps, and conveyors.
Schneider ATV630 – A robust VFD designed for managing large motors in demanding industrial applications.
Schneider EcoStruxure™ Control Expert – A PLC programming software designed for efficient integration, configuration, and management of Modicon PLCs.

These Schneider Electric products enhance the performance of the BMXDDO1612 by offering more I/O options, better communication capabilities, and advanced control for large-scale automation systems.

Applications

The BMXDDO1612 is designed for applications that require reliable control of multiple digital outputs. Typical use cases include:

Manufacturing Automation: Controls devices such as actuators, motors, and valves in automated production lines, improving process efficiency and throughput.
Process Control: Used in industries like chemical, pharmaceutical, and food processing, where precise control of valves, pumps, and motors is essential.
Building Automation: Ideal for controlling systems like HVAC, lighting, security, and access control in commercial and industrial buildings.
Energy Management: Helps monitor and control devices like energy meters, power relays, and switchgear in energy distribution and smart grid systems.
Water and Wastewater Treatment: Controls pumps, level sensors, and flow meters in water treatment plants to ensure proper water management and distribution.
Material Handling: Used in logistics, warehouses, and distribution centers to control conveyors, sorting systems, and automated guided vehicles (AGVs), optimizing material flow and reducing operational costs.

The BMXDDO1612 is an excellent choice for any system requiring robust, high-density output control for field devices.

Advantages

High-Density Output Control: With 16 digital outputs in a single module, the BMXDDO1612 offers a compact and efficient solution for controlling multiple field devices in automation systems.
Flexible Output Configuration: Supports both NPN and PNP output configurations, making it compatible with a wide range of field devices.
Seamless Integration: Easily integrates into the Modicon M580 PLC, allowing for simple configuration and enhanced system scalability.
Compact Design: Despite providing 16 digital outputs, the BMXDDO1612 maintains a compact form factor, reducing the need for additional modules and saving space in control panels.
Durable and Reliable: The IP20 protection rating ensures that the module is protected from dust and accidental contact, enhancing its reliability in industrial environments.
Wide Operating Temperature Range: Operates in a temperature range of 0°C to 60°C (32°F to 140°F), suitable for most industrial conditions.
Certified for Compliance: Meets CE, UL, and RoHS certifications, ensuring the module adheres to international standards for quality, safety, and environmental impact.

Technical FAQs

How many digital outputs does the BMXDDO1612 have?
The BMXDDO1612 provides 16 digital outputs, ideal for controlling multiple field devices such as actuators, relays, and motors.
What voltage does the BMXDDO1612 operate at?
The module operates with 24V DC, which is commonly used for digital output control in industrial automation systems.
Can the outputs be configured for both NPN and PNP?
Yes, the BMXDDO1612 supports both NPN and PNP output configurations, providing flexibility in controlling different types of field devices.
What is the protection rating of the BMXDDO1612?
The BMXDDO1612 has an IP20 protection rating, ensuring basic protection against dust and accidental contact with live parts.
What is the weight of the BMXDDO1612 module?
The module weighs approximately 0.55 kg (1.21 lbs), making it lightweight and easy to install in industrial control systems.
What is the operating temperature range for the BMXDDO1612?
The module operates within a temperature range of 0°C to 60°C (32°F to 140°F), suitable for use in most industrial environments.
Can the BMXDDO1612 be used in hazardous environments?
The IP20 rating means the module is suitable for general industrial use but may require additional protective measures for use in hazardous or corrosive environments.
What certifications does the BMXDDO1612 have?
The BMXDDO1612 is CE, UL, and RoHS certified, ensuring compliance with international safety, environmental, and quality standards.
Is the BMXDDO1612 compatible with other Schneider Electric PLCs?
The BMXDDO1612 is designed for use with the Modicon M580 PLC, but may also be compatible with other Schneider Electric PLCs that support similar I/O modules.
How is the BMXDDO1612 mounted?
The module is DIN rail mountable, simplifying installation in control panels and making it easy to integrate into your existing setup.
