The Schneider BMXMSP0200 is a service power supply module designed for use with the Modicon M580 PLC. This module provides the necessary power to the Modicon M580 system, ensuring that the CPU, I/O modules, and other components of the Modicon M580 system operate smoothly and reliably. With its robust design and seamless integration into the M580 architecture, the BMXMSP0200 ensures stable power delivery in critical industrial automation systems.

This module is specifically engineered to deliver consistent and reliable power to high-performance PLCs and is ideal for use in applications where high availability and continuous operation are essential, such as in manufacturing, process control, and energy management.

Technical Specifications

Model: BMXMSP0200
Type: Service Power Supply Module
Compatibility: Modicon M580 PLC
Input Voltage: 100-240 V AC, 50/60 Hz
Output Voltage: 24 V DC
Output Power: 20 W
Mounting Type: DIN Rail Mountable
Dimensions: 72 mm x 90 mm x 63 mm
Weight: 0.5 kg (1.1 lbs)
Operating Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Protection Rating: IP20 (Dust and accidental contact protection)
Certifications: CE, UL, RoHS compliant
Status Indicators: LED indicators for status and diagnostics

Recommended Related Models

To expand and enhance the functionality of the Modicon M580 PLC, Schneider Electric offers the following complementary modules:

Schneider BMXCPS2000: A power supply module that provides additional power to Modicon M580 systems, ensuring continuous operation of all components.
Schneider BMXPRA0100: An analog input module designed to integrate analog sensors for monitoring variables such as temperature, pressure, and flow in industrial systems.
Schneider BMXDAI0802: A digital input module used for monitoring digital devices such as switches, sensors, or encoders in real-time.

These related modules allow you to build a comprehensive Modicon M580 automation system that meets your specific needs in industrial control and automation.

Popular Schneider Electric Models

Schneider Modicon M580 – A high-performance, Ethernet-enabled PLC that provides redundancy, cybersecurity, and real-time control for critical applications in industrial automation.
Schneider Modicon M340 – A modular PLC designed for medium-to-large automation systems, offering flexible communication and high scalability for complex control processes.
Schneider ATV320 – A Variable Frequency Drive (VFD) used for controlling motor speeds in applications such as HVAC, pumps, and conveyors, optimizing energy efficiency.
Schneider ATV630 – A heavy-duty VFD used in demanding industrial applications, offering superior motor control and energy-saving features.
Schneider EcoStruxure™ Control Expert – A robust PLC programming software that simplifies configuration and management of Modicon PLCs, ensuring easy integration with BMXMSP0200.

These models, combined with the BMXMSP0200, form a powerful and reliable automation system for various industrial environments.

Applications

The BMXMSP0200 is designed for powering the Modicon M580 PLC system, ensuring continuous and stable operation in a variety of critical automation applications. Some typical use cases include:

Industrial Automation: Ensures reliable power delivery to all components in industrial control systems, enabling efficient management of machines, sensors, and actuators.
Process Control Systems: Powers Modicon M580 PLC modules in process control applications, such as controlling pumps, valves, and motors in water treatment or chemical processing.
Energy Management: Provides stable power to systems monitoring energy consumption, electricity distribution, and smart grids in industrial plants.
Manufacturing Systems: Ensures that production lines and robotic systems receive uninterrupted power, maintaining operational efficiency and reducing downtime in automated manufacturing.
Building Management: Powers HVAC, lighting, and security systems for efficient and sustainable building management and energy optimization.

The BMXMSP0200 ensures reliable power distribution in these demanding industrial environments, contributing to system stability and reduced operational risks.

Advantages

Stable Power Supply: The BMXMSP0200 provides a stable and reliable 24V DC output, ensuring that your Modicon M580 system operates without power interruptions.
Compact Design: With its compact form factor, the module is easy to install in control cabinets and saves space, reducing the complexity of the overall system.
Seamless Integration: Designed specifically for the Modicon M580 PLC, it integrates effortlessly into your automation system for a streamlined configuration and setup.
Durability: The IP20 protection rating ensures that the module is protected against dust and accidental contact, making it suitable for industrial environments.
Temperature Resistance: The module can operate in a wide temperature range from 0°C to 60°C (32°F to 140°F), ensuring reliable performance in varying environmental conditions.
International Compliance: The BMXMSP0200 is CE, UL, and RoHS certified, ensuring compliance with global safety, quality, and environmental standards.
LED Status Indicators: Built-in LED indicators provide clear diagnostics for power status, helping with quick identification of potential issues.
