The Schneider BMXNOE0100 is a high-performance Ethernet communication module designed for the Modicon M580 PLC. This module provides Ethernet-based connectivity, enabling seamless communication between the PLC and a wide range of networked devices such as HMI systems, SCADA systems, remote I/O devices, and other Modicon M580 PLCs. The BMXNOE0100 ensures fast and reliable data transfer with support for Ethernet/IP and Modbus TCP protocols, making it a key component in modern, networked industrial automation systems.

Whether you're implementing distributed control systems (DCS), remote monitoring, or data acquisition, the BMXNOE0100 is built to ensure robust and high-speed communication between devices in industrial environments. Its compact design and wide compatibility make it a versatile solution for a variety of automation needs, from factory automation to energy management systems.

Technical Specifications

Model: BMXNOE0100
Type: Ethernet Communication Module
PLC Compatibility: Modicon M580
Network Protocols:
- Ethernet/IP
- Modbus TCP
- HTTP
- SNMP
- SMTP
Network Speed: 10/100/1000 Mbps (Gigabit Ethernet)
Number of Ports: 1 Ethernet port
Mounting Type: DIN Rail Mountable
Dimensions: 72 mm x 90 mm x 63 mm
Weight: 0.25 kg (0.55 lbs)
Operating Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Protection Rating: IP20 (Dust and accidental contact protection)
Certifications: CE, UL, RoHS compliant
LED Indicators: Diagnostic LEDs for status and diagnostics
Power Consumption: 3 W

Recommended Related Models

To enhance the networking capabilities and improve overall communication performance within the Modicon M580 PLC system, Schneider Electric offers several related modules and accessories:

Schneider BMXCPS2000: A power supply module designed to provide stable, reliable power to the Modicon M580 PLC system and its connected components.
Schneider BMXDAI1602: A 16-channel analog input module, ideal for integrating analog sensors like temperature or pressure sensors into your control system.
Schneider BMXPRA0100: An analog output module, designed to control actuators such as valves and dimmers, providing real-time feedback and control via Ethernet communication.

These models, when paired with the BMXNOE0100, create a robust, Ethernet-enabled automation system that meets the specific needs of complex industrial environments.

Popular Schneider Electric Models

Schneider Modicon M580 – A high-performance PLC with integrated Ethernet capabilities, cybersecurity features, and redundancy options, ideal for mission-critical applications.
Schneider Modicon M340 – A modular PLC offering scalability and flexibility, ideal for medium to large industrial systems requiring real-time data processing and network integration.
Schneider ATV320 – A Variable Frequency Drive (VFD) designed for motor control applications such as HVAC, pumps, and conveyors, optimizing energy efficiency.
Schneider ATV630 – A heavy-duty VFD ideal for controlling motors in demanding industrial environments, featuring advanced energy-saving technologies.
Schneider EcoStruxure™ Control Expert – A PLC programming software that simplifies the configuration, programming, and management of Modicon PLCs, enhancing integration with the BMXNOE0100.

Applications

The BMXNOE0100 is designed for applications that require high-speed Ethernet communication in industrial automation systems. Common applications include:

Distributed Control Systems (DCS): The module connects the Modicon M580 PLC to other PLC systems, HMI devices, and remote I/O devices, allowing for efficient data exchange in large, distributed automation setups.
Remote Monitoring: Enables remote access to system data, allowing operators to monitor and control industrial processes from anywhere via the Ethernet network.
Data Acquisition: Ideal for systems that require high-speed, real-time data exchange from sensors, meters, and other field devices to a central control system, often used in energy management and building management systems.
Factory Automation: Facilitates communication between robotic systems, conveyor belts, and other automated machinery, optimizing overall manufacturing processes.
Energy Management: Used for transmitting data from energy meters and power distribution devices, the module plays a critical role in monitoring and optimizing energy consumption in industrial plants.

The BMXNOE0100 enables fast and secure Ethernet communications, making it essential for building reliable, scalable, and high-performance automation systems.

Advantages

Gigabit Ethernet Speed: Supports 10/100/1000 Mbps (Gigabit Ethernet), ensuring high-speed data transfer between devices for real-time communication and seamless system operation.
Multiple Protocol Support: The module supports Ethernet/IP, Modbus TCP, and other industry-standard protocols, allowing for flexible and easy integration with a wide variety of devices.
Compact Design: The BMXNOE0100 is compact and DIN rail mountable, saving valuable space in control panels and simplifying installation.
Wide Temperature Range: Operates effectively within a temperature range of 0°C to 60°C (32°F to 140°F), making it suitable for diverse industrial environments.
Versatile Connectivity: Offers flexible and scalable network integration, making it ideal for distributed control systems, remote monitoring, and data acquisition.
IP20 Protection Rating: Provides protection against dust and accidental contact with live parts, ensuring durability and reliability in industrial settings.
LED Diagnostic Indicators: Features LED indicators for quick diagnostics and real-time monitoring of communication status, simplifying troubleshooting and maintenance.
Global Certifications: The BMXNOE0100 is CE, UL, and RoHS certified, meeting international standards for safety, quality, and environmental impact.

Technical FAQs

What is the maximum network speed supported by the BMXNOE0100?
The module supports 10/100/1000 Mbps (Gigabit Ethernet), ensuring fast and reliable data transmission.
How many Ethernet ports does the BMXNOE0100 have?
The module has 1 Ethernet port, designed for high-speed communication between the Modicon M580 PLC and other networked devices.
What protocols does the BMXNOE0100 support?
It supports Ethernet/IP, Modbus TCP, HTTP, SNMP, and SMTP protocols, allowing for versatile communication and integration.
What is the operating temperature range of the BMXNOE0100?
The module operates within a temperature range of 0°C to 60°C (32°F to 140°F), making it suitable for most industrial environments.
How is the BMXNOE0100 mounted?
The BMXNOE0100 is DIN rail mountable, which simplifies installation and saves space in control panels.
Can the BMXNOE0100 be used for remote monitoring applications?
Yes, the module is ideal for remote monitoring and control, enabling operators to access and manage industrial systems over Ethernet networks.
What is the protection rating of the BMXNOE0100?
The module has an IP20 protection rating, offering protection against dust and accidental contact with live parts.
What certifications does the BMXNOE0100 have?
The module is CE, UL, and RoHS certified, ensuring compliance with global safety and environmental standards.
What is the weight of the BMXNOE0100?
The BMXNOE0100 weighs approximately 0.25 kg (0.55 lbs), making it lightweight and easy to install.
What is the power consumption of the BMXNOE0100?
The module consumes 3 W of power, ensuring efficient energy use while maintaining stable network communication.
