Schneider BMXNOM0200-1 Schneider BMXNOM0200-2 Schneider BMXNOM0200-3 Schneider BMXNOM0200-4

The Schneider BMXNOM0200 is a 2-port Ethernet communication module designed specifically for use with the Modicon M580 PLC. This module provides an enhanced communication interface, supporting high-speed data exchange between the PLC and a range of networked devices. With two independent Ethernet ports, the BMXNOM0200 offers greater networking flexibility and redundancy for critical industrial systems, ensuring continuous and reliable data flow even in the event of a network failure.

Ideal for distributed control systems, remote monitoring, and real-time data acquisition, this module supports industry-standard communication protocols, such as Ethernet/IP, Modbus TCP, and HTTP, enabling seamless integration with a variety of devices like HMIs, SCADA systems, and remote I/O units. The BMXNOM0200 ensures your Modicon M580 system is well-equipped to handle complex networking needs in modern industrial environments.

Technical Specifications

Model: BMXNOM0200
Type: 2-Port Ethernet Communication Module
PLC Compatibility: Modicon M580
Number of Ports: 2 Ethernet Ports (Dual Ports for Redundancy)
Network Protocols Supported:
- Ethernet/IP
- Modbus TCP
- HTTP
- SNMP
- SMTP
Network Speed: 10/100/1000 Mbps (Gigabit Ethernet)
Mounting Type: DIN Rail Mountable
Dimensions: 72 mm x 90 mm x 63 mm
Weight: 0.3 kg (0.66 lbs)
Operating Temperature Range:
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Protection Rating: IP20 (Dust and accidental contact protection)
Certifications: CE, UL, RoHS compliant
Power Consumption: 3 W
Status Indicators: LED diagnostic indicators for connection and operational status

Recommended Related Models

To complement the BMXNOM0200 and expand the communication capabilities of your Modicon M580 PLC system, consider these Schneider Electric modules:

Schneider BMXCPS2000: A power supply module that ensures stable power to the Modicon M580 PLC, providing reliable operation of connected components.
Schneider BMXDAI1602: A 16-channel analog input module, ideal for integrating various analog sensors such as temperature, pressure, and flow meters into the control system.
Schneider BMXDRA1605: A digital I/O module that provides real-time data processing for devices such as sensors, encoders, and limit switches.

These modules, when integrated with the BMXNOM0200, form a powerful, scalable, and networked industrial automation system capable of handling a wide variety of applications.

Popular Schneider Electric Models

Schneider Modicon M580 – A high-performance Ethernet-enabled PLC that offers advanced cybersecurity and redundancy for mission-critical applications across various industries.
Schneider Modicon M340 – A modular PLC offering flexibility and scalability for medium to large industrial control systems, with support for Ethernet communication and real-time control.
Schneider ATV320 – A Variable Frequency Drive (VFD) for controlling motor speed in applications such as HVAC, pumps, and conveyors, optimizing energy consumption and operational efficiency.
Schneider ATV630 – A high-performance VFD for controlling motors in demanding industrial applications, with advanced features like energy-saving and variable-speed control.
Schneider EcoStruxure™ Control Expert – A powerful PLC programming software that simplifies the configuration and management of Modicon PLCs, supporting easy integration with BMXNOM0200.

Applications

The BMXNOM0200 is designed for environments that require reliable, high-speed Ethernet communication between the Modicon M580 PLC and other networked devices. Some typical use cases include:

Distributed Control Systems (DCS): The module connects multiple Modicon M580 PLCs, HMI systems, and remote I/O devices in a networked control system, enabling synchronized real-time control across large industrial processes.
Factory Automation: Integrates seamlessly with robotic systems, conveyor belts, motor controllers, and sensors, allowing for smooth operation in automated manufacturing environments.
Remote Monitoring: Supports remote diagnostics and control of industrial systems, allowing operators to access and adjust systems from off-site locations.
Energy Management: Enables real-time monitoring and management of energy systems, such as power meters, distribution boards, and solar power systems, to optimize energy efficiency in industrial plants.
Data Acquisition: Ideal for systems requiring high-speed, continuous data collection from various field devices, ensuring accurate feedback and control in process control applications.

The BMXNOM0200 enables these applications by providing high-speed, redundant network connections for critical industrial systems that rely on real-time data exchange.

Advantages

Dual Ethernet Ports for Redundancy: The two Ethernet ports provide network redundancy, ensuring that communication remains uninterrupted even if one connection fails. This is critical for applications that require high availability and reliability.
Gigabit Ethernet Support: The module supports 10/100/1000 Mbps network speed, enabling fast and efficient data transfer, essential for real-time communication in high-performance industrial systems.
Flexible Protocol Support: Supports multiple industrial protocols, including Ethernet/IP, Modbus TCP, HTTP, and SNMP, ensuring compatibility with a wide range of devices and network configurations.
Compact and Space-Saving Design: The BMXNOM0200 has a compact form factor and is DIN rail mountable, saving space in control panels and simplifying installation.
Wide Temperature Range: The module operates within a temperature range of 0°C to 60°C (32°F to 140°F), making it suitable for harsh industrial environments.
Robust Protection: With an IP20 rating, the module is protected against dust and accidental contact, ensuring long-term reliability.
Status LEDs for Diagnostics: The LED indicators provide real-time feedback on network and operational status, allowing for quick diagnostics and troubleshooting.
Energy-Efficient: With a low power consumption of 3W, the module operates efficiently without adding unnecessary load to the system.

Technical FAQs

How many Ethernet ports does the BMXNOM0200 have?
The BMXNOM0200 has 2 Ethernet ports, providing network redundancy to ensure continuous communication.
What is the maximum network speed supported by the BMXNOM0200?
The module supports 10/100/1000 Mbps (Gigabit Ethernet), enabling high-speed communication and data transfer.
Which protocols does the BMXNOM0200 support?
It supports Ethernet/IP, Modbus TCP, HTTP, SNMP, and SMTP, ensuring compatibility with a wide range of devices and systems.
What is the operating temperature range of the BMXNOM0200?
The module operates within a temperature range of 0°C to 60°C (32°F to 140°F), making it suitable for most industrial environments.
How is the BMXNOM0200 mounted?
The module is DIN rail mountable, allowing for easy installation and saving valuable space in control panels.
Can the BMXNOM0200 be used for remote monitoring?
Yes, the BMXNOM0200 is ideal for remote monitoring and data acquisition, allowing operators to access and control systems remotely.
What is the weight of the BMXNOM0200?
The module weighs approximately 0.3 kg (0.66 lbs), making it easy to handle and install.
What is the power consumption of the BMXNOM0200?
The module consumes 3 W of power, ensuring efficient operation while maintaining reliable communication.
What is the protection rating of the BMXNOM0200?
The module has an IP20 protection rating, protecting it from dust and accidental contact with live parts.
Does the BMXNOM0200 support redundancy?
Yes, the dual Ethernet ports provide network redundancy, ensuring communication remains stable even if one network connection fails.
