The Schneider BMXP342010 Modicon X80 32 Digital Input/Output with Relay Module is a versatile and powerful module designed for industrial automation systems requiring both digital I/O and relay control. As part of Schneider Electric’s Modicon X80 series, this module provides a robust solution for applications that demand high-density digital inputs and outputs, as well as the ability to control relay-based devices. With 32 I/O points and integrated relay outputs, the BMXP342010 offers enhanced flexibility and performance in a compact format.

The module is specifically designed for seamless integration within Schneider’s Modicon X80 PLC ecosystem, providing exceptional reliability and ease of configuration. Ideal for industries such as manufacturing, energy, and automation, the BMXP342010 enables efficient control, monitoring, and communication of critical systems in a wide range of applications.

Technical Specifications

Specification	Details
Model	Schneider BMXP342010 Modicon X80 I/O Module with Relay
Series	Modicon X80
I/O Type	32 Digital Inputs/Outputs with Relay Outputs
Input Voltage	24V DC
Output Voltage	24V DC
Relay Output Rating	2A per Relay Channel
Dimensions	4.5 x 7.3 x 10.8 inches (114 x 186 x 274 mm)
Weight	0.85 lbs (0.39 kg)
Power Consumption	1.5W
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Mounting	DIN Rail Mountable
Communication Protocol	Modbus TCP/IP, EtherNet/IP

Recommended Related Models

Schneider BMXDRA0800 – Modicon X80 Power Supply Module
Schneider BMXNOE0100 – Modicon X80 Communication Module for EtherNet/IP
Schneider BMXP341000 – Modicon X80 16 Digital I/O Module

Popular Schneider Models

Modicon M580 – High-Performance PLC with Integrated I/O and Ethernet Capability
Modicon TM3 – Compact I/O Modules for Modular PLC Systems
Modicon BMXRTB0100 – Modicon X80 Relay Output Module

Applications

The Schneider BMXP342010 Modicon X80 I/O Module with Relay is suited for a wide range of industrial automation applications:

Manufacturing: Controls assembly lines, robotics, and quality control systems where relay-based switching is required.
Energy: Integrates with energy management systems for controlling power distribution and circuit protection.
Water Treatment: Automates processes such as valve control, pumps, and sensor monitoring in water treatment plants.
Building Automation: Used to control HVAC systems, lighting, and other critical building operations via relay control.

Advantages

High-Density I/O: With 32 digital I/O points, the BMXP342010 helps reduce hardware requirements and simplifies wiring, streamlining installation and configuration.
Relay Control Integration: The module provides integrated relay outputs (2A per relay), ideal for controlling devices such as motors, solenoids, and other field equipment.
Advanced Communication Protocols: Support for Modbus TCP/IP and EtherNet/IP ensures seamless communication and easy integration into existing control networks.
Compact and Reliable: Despite its high functionality, the module’s compact size makes it easy to integrate into space-constrained industrial control panels.
Energy-Efficient: Operating with a power consumption of just 1.5W, the BMXP342010 is a cost-effective solution for industrial applications where energy efficiency is a priority.

Technical FAQs

What is the primary function of the Schneider BMXP342010?
The BMXP342010 is a 32-point digital I/O module with integrated relay outputs, designed for industrial automation systems requiring digital control and relay-based switching.
How many relay outputs does the BMXP342010 support?
The module includes 32 I/O points, with each point supporting relay outputs rated at 2A per channel, ideal for controlling motors, lights, and solenoids.
Which communication protocols are supported by this module?
The module supports both Modbus TCP/IP and EtherNet/IP protocols, ensuring compatibility with a wide range of industrial networks.
What is the voltage requirement for the BMXP342010?
This module operates with a 24V DC input and output, which is common for many industrial systems.
What is the operating temperature range of the BMXP342010?
The BMXP342010 is designed to operate in temperatures ranging from -20°C to 60°C (-4°F to 140°F), making it suitable for diverse industrial environments.
How much power does the BMXP342010 consume?
The module consumes only 1.5W of power, providing efficient energy use without compromising on performance.
Can the BMXP342010 be used in hazardous environments?
While the module is designed for industrial environments, specific certifications for hazardous locations would need to be checked based on application requirements.
What industries are most suitable for the BMXP342010?
Industries such as manufacturing, energy management, water treatment, and building automation benefit from the BMXP342010’s high I/O density and relay control capabilities.
What is the mounting method for the BMXP342010?
The BMXP342010 is designed to be mounted on a DIN rail, making installation quick and easy within control panels.
Can the BMXP342010 module be integrated into existing Schneider PLC systems?
Yes, the BMXP342010 is fully compatible with Schneider Electric’s Modicon X80 series, allowing easy integration into existing setups.
