The Schneider BMXXBP1200 Modicon X80 Ultra High-Capacity Battery Backup Module is engineered to provide extended backup power for industrial automation systems, ensuring uninterrupted operation and data protection during power failures. Designed for critical applications in industries such as manufacturing, energy management, and process control, this backup module delivers up to 12 hours of reliable power, depending on the connected load.

The BMXXBP1200 is equipped with advanced Li-ion rechargeable battery technology, which ensures long-lasting, efficient, and reliable power during outages, allowing automated systems to continue functioning and preventing potential data loss. It integrates seamlessly with Schneider Electric’s Modicon X80 series, offering a robust solution for systems that cannot afford downtime or disruption in power supply.

Technical Specifications

Specification	Details
Model	Schneider BMXXBP1200 Modicon X80 Battery Backup
Series	Modicon X80
Backup Time	Up to 12 hours (depending on load)
Battery Type	Li-ion Rechargeable
Voltage Output	24V DC
Dimensions	4.5 x 7.3 x 10.8 inches (114 x 186 x 274 mm)
Weight	1.5 lbs (0.68 kg)
Power Consumption	25W
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Mounting	DIN Rail Mountable
Certifications	UL Listed, CE Certified

Recommended Related Models

Schneider BMXDRA0800 – Modicon X80 Power Supply Module
Schneider BMXP341000 – Modicon X80 Digital I/O Module
Schneider BMXRTB0100 – Modicon X80 Relay Output Module

Popular Schneider Models

Modicon M580 – High-performance Ethernet-enabled PLC with Integrated I/O and Ethernet Networking
Modicon TM3 – Modular I/O for Compact and Distributed Control Systems
Schneider BMXNOE0100 – Modicon X80 Communication Module for EtherNet/IP

Applications

The Schneider BMXXBP1200 Modicon X80 Battery Backup Module is particularly suited for critical industrial applications that demand long-duration backup power to ensure operational continuity:

Industrial Automation: Keeps Modicon X80 PLCs, I/O modules, and communication systems running during power interruptions, preventing data loss and downtime in manufacturing systems, production lines, and robotics.
Energy Management: Maintains power to energy distribution systems, smart grid networks, and power metering equipment, ensuring monitoring and control functions remain active during grid failures or electrical disturbances.
Water Treatment: Powers control systems, sensors, pumps, and valves in water treatment plants, ensuring vital processes continue uninterrupted in case of power outages.
Building Automation: Provides backup power to critical building systems such as HVAC, lighting, security, and fire safety, ensuring smooth operation of smart building systems without interruption.

Advantages

Extended Backup Power: The BMXXBP1200 provides up to 12 hours of backup power, ensuring long-duration operational continuity during extended power outages and protecting against system downtime.
Li-ion Rechargeable Battery: The use of Li-ion battery technology ensures longer battery life, superior charge efficiency, and minimal maintenance, reducing the need for frequent replacements.
High Power Efficiency: With a low power consumption of 25W, the BMXXBP1200 delivers reliable backup power while maintaining energy efficiency.
Seamless Integration: The module integrates effortlessly into Schneider Electric’s Modicon X80 system, offering an easy-to-install solution that enhances overall system reliability.
Robust and Durable: Built to perform under industrial conditions, the BMXXBP1200 operates in a temperature range of -20°C to 60°C (-4°F to 140°F), making it suitable for a wide variety of industrial environments.
Safety and Compliance: With UL Listed and CE Certified compliance, the BMXXBP1200 meets international safety standards, ensuring reliable operation in various global markets.

Technical FAQs

What is the main function of the Schneider BMXXBP1200?
The BMXXBP1200 is a battery backup module that ensures uninterrupted power supply to Modicon X80 PLCs, I/O modules, and other automation systems during power interruptions, preventing data loss and downtime.
How long can the BMXXBP1200 provide backup power?
The BMXXBP1200 can provide backup power for up to 12 hours, depending on the load and power requirements of the system.
What type of battery does the BMXXBP1200 use?
The module uses an Li-ion rechargeable battery, providing superior performance and longevity compared to traditional lead-acid batteries.
What is the output voltage of the BMXXBP1200?
The BMXXBP1200 provides a stable 24V DC output, which is ideal for powering automation systems and control devices.
What is the operating temperature range for the BMXXBP1200?
The BMXXBP1200 operates within a temperature range of -20°C to 60°C (-4°F to 140°F), ensuring it can be used in most industrial environments.
How is the BMXXBP1200 mounted?
The BMXXBP1200 is designed for DIN rail mounting, making it easy to install and integrate into control panels or existing automation setups.
What industries benefit from the BMXXBP1200?
The BMXXBP1200 is ideal for industries that require extended backup power, such as manufacturing, energy management, water treatment, and building automation.
How is the BMXXBP1200 charged?
The BMXXBP1200 automatically charges when the main power supply is available. During a power failure, the module switches seamlessly to battery mode to keep connected systems operational.
What is the power consumption of the BMXXBP1200?
The module has a low power consumption of just 25W, providing efficient energy usage while ensuring extended backup time.
Does the BMXXBP1200 comply with global safety standards?
Yes, the BMXXBP1200 is UL Listed and CE Certified, ensuring it meets global safety and regulatory standards for industrial use.
