The Schneider OTB1C0DM9LP Heavy Duty Disconnect Switch is an essential component for safe motor isolation and electrical protection in industrial control systems. Designed to provide manual disconnection of electrical circuits, this switch ensures that operators can safely isolate equipment during maintenance, repairs, or emergency shutdowns, minimizing the risk of electrical accidents.

Built for rugged industrial environments, the OTB1C0DM9LP features a rotary handle for ease of operation and is ideal for applications requiring high-current motor isolation in sectors such as manufacturing, HVAC, energy management, and water treatment. With its durable construction and IP65 rating, this disconnect switch ensures reliable performance under demanding conditions.

Technical Specifications

Specification	Details
Model	Schneider OTB1C0DM9LP Heavy Duty Disconnect Switch
Type	Rotary Handle Disconnect Switch
Rated Current	32A
Voltage Rating	690V AC
IP Rating	IP65 (dust-tight and water-resistant)
Mounting Type	Panel Mount
Terminal Type	Screw Clamp
Dimensions	5.3 x 3.4 x 6.9 inches (135 x 86 x 175 mm)
Weight	2.1 lbs (0.95 kg)
Operating Temperature	-25°C to 60°C (-13°F to 140°F)
Enclosure	IP65 (dust-tight and water-resistant)
Certifications	UL, CE, RoHS compliant

Recommended Related Models

Schneider OTB1C02M9LP – Heavy Duty Disconnect Switch with Multi-Position Rotary Handle
Schneider OTB1C03M9LP – 63A Heavy Duty Disconnect Switch with Rotary Handle
Schneider GV3P06 – Motor Protection Circuit Breaker for Use with Disconnect Switches

Popular Schneider Models

Modicon M580 – High-performance Ethernet-enabled PLC with integrated I/O and Ethernet networking
Schneider GV2ME06 – Motor Circuit Breaker for Overload Protection in Motor Control Applications
TeSys D – Modular motor control solution with relays, contactors, and overload protection

Applications

The Schneider OTB1C0DM9LP Heavy Duty Disconnect Switch is ideal for applications where motor isolation and circuit protection are required. Common applications include:

Manufacturing: Used in production lines, conveyor systems, and assembly machines to provide motor isolation for maintenance and emergency shutdowns.
HVAC Systems: Ideal for isolating motors in air conditioning systems, ventilation fans, and chillers, ensuring safe operation and easy maintenance.
Energy Management: Protects electrical circuits in power distribution panels, ensuring safe isolation and reducing the risk of faults during maintenance in energy systems.
Water Treatment: Provides reliable disconnection for water pumps, filtering systems, and valve actuators in water and wastewater treatment plants.
Industrial Pumps and Fans: Used for isolating motors in industrial pumps, compressors, and HVAC fans, enhancing operational safety.

Advantages

Reliable Circuit Isolation: The OTB1C0DM9LP provides secure isolation of electrical circuits, ensuring safety during maintenance or emergency situations.
Easy Operation: The rotary handle design allows for easy manual operation, providing fast and reliable disconnection of electrical circuits.
High Durability: With an IP65 rating, the OTB1C0DM9LP is dust-tight and water-resistant, offering reliable performance even in harsh industrial environments.
Versatile Mounting: The switch can be mounted on panels, offering flexibility for a wide range of installation options in industrial control systems.
Long Operational Life: Built to withstand the rigors of industrial environments, this switch is designed for a long service life with minimal maintenance.
Safety Compliance: With UL, CE, and RoHS certifications, the OTB1C0DM9LP meets international safety and environmental standards, ensuring it is safe to use in global industrial applications.
