The Schneider TSXDMZ28DTK is a versatile communication module designed for Modicon Premium PLC systems, providing high-performance Ethernet connectivity and supporting a range of industrial communication protocols. This module ensures seamless integration of your control systems with external networks, enhancing the flexibility and efficiency of your automation processes. Whether you're connecting to Ethernet networks, interfacing with remote I/O systems, or integrating with other devices using Modbus or Ethernet/IP, the TSXDMZ28DTK is engineered to meet the needs of demanding industrial applications. Its robust design and powerful features make it an ideal solution for industries where uptime and communication reliability are critical.

Technical Specifications

Specification	Details
Model	TSXDMZ28DTK
Module Type	Communication Module
Supported Protocols	Ethernet/IP, Modbus TCP, MODBUS RTU
Ports	1 x 10/100 Mbps Ethernet Port
Dimensions	4.25 in x 3.60 in x 2.05 in (108 mm x 92 mm x 52 mm)
Weight	0.3 kg (0.66 lbs)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Power Consumption	2.4 W
Certifications	UL, CE, RoHS

Recommended Related Models

For a complete Schneider Electric automation solution, consider pairing the TSXDMZ28DTK with the following related models:

Modicon Premium TSXP574634 Processor: A high-performance controller that integrates well with the TSXDMZ28DTK for advanced control tasks.
Modicon TSXPSY1200 Power Supply: A reliable power supply to support your Modicon Premium system, ensuring uninterrupted operation.
Modicon TM3 Digital Input Module: A compact digital I/O module that integrates smoothly with the TSXDMZ28DTK for versatile automation tasks.

Popular Schneider Models

Modicon M580 Ethernet PLC: A high-performance modular PLC offering superior processing power and Ethernet connectivity for complex applications.
Modicon X80 I/O Modules: Modular I/O solutions for expanding your control system and providing flexible configurations.
Schneider Magelis GTU HMI: A robust human-machine interface that integrates seamlessly with Modicon PLCs for enhanced operator control.

Applications

The Schneider TSXDMZ28DTK is ideal for a wide range of industrial applications that require reliable communication and integration between various systems and devices. Key applications include:

Industrial Automation Systems: Facilitates high-speed communication between PLCs and other automation equipment such as drives, sensors, and actuators.
Process Control: Supports the integration of Modicon Premium PLCs with SCADA systems, enhancing the monitoring and control of industrial processes.
Remote I/O: Enables remote monitoring and control of I/O systems across Ethernet networks, ideal for large-scale distributed automation systems.
Machine Control: Provides connectivity for controlling machines and manufacturing processes, ensuring seamless communication across devices and systems.

Advantages

Flexible Protocol Support: The TSXDMZ28DTK supports multiple communication protocols, including Modbus TCP and Ethernet/IP, allowing for easy integration with existing and new systems.
High-Speed Communication: With Ethernet connectivity, the module offers fast and reliable data transfer, ensuring minimal delays in critical applications.
Compact and Space-Saving: Its compact form factor makes it easy to integrate into various control panels or machines, even in space-constrained environments.
Reliability: Built to operate in demanding industrial environments, the TSXDMZ28DTK delivers stable performance even in harsh conditions.
Seamless Integration: The module is designed to integrate effortlessly with Schneider Electric’s Modicon PLCs and I/O systems, ensuring a cohesive and efficient automation setup.

Technical FAQs

What communication protocols does the TSXDMZ28DTK support?
- The TSXDMZ28DTK supports Ethernet/IP, Modbus TCP, and Modbus RTU protocols, offering flexibility in network and device communication.
What types of devices can be connected using this module?
- The TSXDMZ28DTK can connect various devices such as remote I/O systems, SCADA, HMI systems, drives, and sensors that support Ethernet/IP or Modbus TCP/RTU protocols.
Can I use the TSXDMZ28DTK in outdoor applications?
- The module is designed for indoor use, with an operating temperature range of 0°C to 55°C. Outdoor use would require additional protective housing.
How is the TSXDMZ28DTK powered?
- The module is powered through the Modicon Premium PLC system or an external power supply that meets its power requirements (2.4 W).
What is the maximum number of devices that can be connected to the TSXDMZ28DTK?
- The number of devices depends on network configurations and protocol settings, but the module supports up to hundreds of devices on a typical Ethernet/IP or Modbus TCP network.
Is the TSXDMZ28DTK compatible with other Schneider PLC models?
- Yes, the TSXDMZ28DTK is designed to integrate seamlessly with all Modicon Premium PLCs and other Schneider Electric PLCs that support Ethernet/IP and Modbus protocols.
What are the physical dimensions of the TSXDMZ28DTK?
- The module measures 4.25 inches x 3.60 inches x 2.05 inches (108 mm x 92 mm x 52 mm), making it compact and easy to fit in most control systems.
Can the TSXDMZ28DTK be used in high-temperature environments?
- The TSXDMZ28DTK operates within a temperature range of 0°C to 55°C. For environments with higher temperatures, additional cooling or enclosure might be needed.
How can I monitor the TSXDMZ28DTK’s performance?
- The module includes built-in diagnostic LEDs that indicate operational status, network connection, and fault detection, allowing easy monitoring and troubleshooting.
Can I upgrade the firmware of the TSXDMZ28DTK?
- Yes, firmware updates can be done using Schneider Electric’s development tools and software, ensuring that the module stays up-to-date with the latest enhancements.
