The Schneider TSXDSY16S5 is a 16-channel digital output module designed for integration with Modicon Premium PLCs, providing robust and reliable control over industrial devices and processes. This module offers 24V DC digital output capability, perfect for controlling a wide range of equipment, such as solenoids, relays, and valves. The TSXDSY16S5 is built to meet the demands of high-performance automation systems, delivering stable output and ensuring seamless communication between your PLC and connected devices. Its compact design and solid-state output configuration make it an excellent choice for industries requiring fast, reliable, and durable control solutions.

Technical Specifications

Specification	Details
Model	TSXDSY16S5
Module Type	Digital Output Module
Output Channels	16 Digital Outputs
Output Voltage	24 VDC
Output Current	0.5 A per channel
Relay Type	Solid-State (Transistor)
Dimensions	4.65 in x 3.94 in x 2.05 in (118 mm x 100 mm x 52 mm)
Weight	0.4 kg (0.88 lbs)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Power Consumption	4 W
Certifications	UL, CE, RoHS

Recommended Related Models

For a more complete and scalable automation solution, consider pairing the TSXDSY16S5 with the following Schneider Electric models:

Modicon Premium TSXP574634 Processor: A powerful controller for managing large automation systems, compatible with the TSXDSY16S5 for high-speed data handling and control.
Modicon TSXPSY1200 Power Supply: A reliable power supply ensuring stable voltage delivery for your entire Modicon Premium system.
Modicon TM3 Digital Input Module: A complementary module for adding digital input capabilities to your automation setup, expanding the overall flexibility of your system.

Popular Schneider Models

Modicon M580 PLC: A modular and high-performance PLC that supports Ethernet-based communication and integrates seamlessly with the TSXDSY16S5 for advanced automation applications.
Modicon X80 I/O Modules: Expand your I/O capabilities with this versatile I/O range that integrates seamlessly with Modicon PLCs and supports various input/output configurations.
Schneider Magelis GTU HMI: A human-machine interface that provides intuitive control and monitoring capabilities, enhancing user experience when paired with Modicon PLCs.

Applications

The Schneider TSXDSY16S5 is ideal for a wide range of industrial automation applications where high-density and reliable digital output management is required. Key applications include:

Industrial Automation Systems: Controls multiple industrial devices, including solenoids, actuators, and relays, used in automated manufacturing or assembly lines.
Machine Control: Manages digital outputs to control machinery, robotics, and other systems within a manufacturing process.
Process Control: Interfacing with motors, valves, pumps, and other digital devices to regulate and control processes within industries like chemicals, food processing, and automotive.
Remote I/O Solutions: Efficiently manages digital outputs across distributed industrial systems, enabling remote monitoring and control from centralized locations.

Advantages

Solid-State Reliability: The use of solid-state transistors ensures superior durability and longevity compared to traditional mechanical relays, reducing maintenance costs and downtime.
High Output Density: With 16 digital output channels, the TSXDSY16S5 allows for compact, space-efficient control solutions for a large number of devices.
Compact Design: Its compact size (4.65 in x 3.94 in x 2.05 in) makes it ideal for installations where space is at a premium, such as tight control panels or equipment cabinets.
Energy Efficient: Consumes only 4W of power, minimizing energy costs while maintaining high performance.
Easy Integration: Fully compatible with Modicon Premium PLCs and other Schneider Electric components, ensuring smooth system setup and operation.
Robust Construction: Built to operate in industrial environments, with a wide temperature range and high environmental resistance, the TSXDSY16S5 offers stable performance in challenging conditions.

Technical FAQs

How many digital output channels does the TSXDSY16S5 support?
- The TSXDSY16S5 offers 16 digital output channels, allowing it to control a wide range of industrial devices simultaneously.
What is the maximum current per output channel?
- Each output channel supports a maximum current of 0.5 A, making it ideal for controlling low-to-medium power digital devices.
Is the TSXDSY16S5 compatible with other Schneider PLCs besides Modicon Premium?
- While optimized for Modicon Premium PLCs, the module can be integrated with other Schneider PLCs that support the same input/output configurations and communication protocols.
What type of output relay is used in the TSXDSY16S5?
- The module uses solid-state (transistor) relays, which are more reliable and durable compared to mechanical relays, ensuring long-term operation without physical wear.
Can the TSXDSY16S5 be used in outdoor environments?
- The module is designed for indoor use, with an operating temperature range of 0°C to 55°C. For outdoor use, additional protective housing is required to safeguard against environmental factors.
What power supply is required for the TSXDSY16S5?
- The module is powered through the Modicon Premium PLC or an external 24V DC power supply, depending on the system configuration.
How does the TSXDSY16S5 handle diagnostics?
- The module features LED indicators that provide real-time feedback on the operational status of each output channel, making troubleshooting easier.
What is the expected lifespan of the TSXDSY16S5?
- Due to its solid-state design, the TSXDSY16S5 is built for long-term reliability, with proper maintenance ensuring an operational life exceeding 10 years in many industrial environments.
Can the TSXDSY16S5 be used for controlling high-power devices?
- The TSXDSY16S5 is designed for low-to-medium power digital devices (up to 0.5 A per output). For controlling higher-power devices, additional external relays or modules may be required.
What certifications does the TSXDSY16S5 hold?
- The TSXDSY16S5 is UL, CE, and RoHS certified, meeting international standards for safety, environmental protection, and quality assurance.
