The Schneider TSXETY110 is a Modbus TCP communication module designed for use with Modicon Premium PLCs. This module provides seamless connectivity and reliable communication between Modicon PLCs and Modbus-compatible devices over an Ethernet network. It is ideal for distributed control systems, real-time data exchange, and integration with a wide range of industrial equipment. Supporting the Modbus TCP protocol, the TSXETY110 is perfect for integrating third-party devices, HMIs, SCADA systems, and I/O modules into a unified automation system. With its robust performance and high scalability, this module ensures your Modicon Premium PLC can easily communicate with other Modbus-based systems, making it a powerful solution for modern industrial networking.

Technical Specifications

Specification	Details
Model	TSXETY110
Module Type	Modbus TCP Communication Module
Communication Protocol	Modbus TCP
Ethernet Ports	1 x RJ45 10/100 Mbps
Transmission Speed	10/100 Mbps
Operating Voltage	24V DC
Power Consumption	5W
Dimensions	4.65 in x 3.94 in x 2.05 in (118 mm x 100 mm x 52 mm)
Weight	0.4 kg (0.88 lbs)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Certifications	UL, CE, RoHS

Recommended Related Models

To enhance your industrial automation network, consider pairing the TSXETY110 with the following Schneider Electric products:

Modicon Premium TSXP574634 Processor: A powerful processor for handling complex automation tasks, providing robust performance and full compatibility with the TSXETY110.
Modicon TSXPSY1200 Power Supply: A reliable power supply solution designed to support your Modicon Premium system, ensuring stable and consistent performance.
Modicon TM3 Digital Input/Output Modules: Expand your I/O capabilities with these flexible modules, which work seamlessly with the TSXETY110 for enhanced functionality.

Popular Schneider Models

Modicon M580 Ethernet PLC: A high-performance PLC with native Ethernet connectivity, ideal for large-scale, distributed control systems, and integrates well with the TSXETY110 for seamless communication.
Modicon X80 I/O Modules: A modular and scalable I/O platform that extends the capabilities of your Modicon PLC system, complementing the TSXETY110 to support high-density, real-time control.
Schneider Magelis GTU HMI: A human-machine interface that integrates easily with Modicon PLCs, providing operators with an intuitive interface for managing automated systems.

Applications

The Schneider TSXETY110 module is designed to enable Modbus TCP communication in a wide variety of industrial applications. Here are some key use cases:

Distributed Control Systems (DCS): Enable the communication between Modicon Premium PLCs and other Modbus-compatible devices, such as remote I/O systems, third-party controllers, or SCADA systems, in a distributed setup.
Real-Time Data Exchange: Facilitate real-time data transfer between devices in industries like manufacturing, water treatment, oil & gas, and more.
Remote I/O Solutions: Use the TSXETY110 to connect remote I/O modules to the Modicon PLC over an Ethernet network, improving system scalability and flexibility for large facilities.
SCADA Systems: Integrate the TSXETY110 into SCADA (Supervisory Control and Data Acquisition) networks, allowing for seamless data exchange and control across geographically dispersed systems.
Industrial Ethernet Networks: Create an industrial Ethernet network, connecting Modicon PLCs, devices, and other Modbus TCP-compatible systems to enhance control, monitoring, and automation.

Advantages

Modbus TCP Support: The TSXETY110 provides native Modbus TCP communication, ensuring compatibility with a wide range of industrial devices and systems that use this open and widely adopted protocol.
High-Speed Ethernet Communication: With 10/100 Mbps Ethernet connectivity, the module ensures fast and reliable data transfer for real-time industrial applications.
Compact and Easy to Install: Despite its robust functionality, the TSXETY110 has a compact design (118 mm x 100 mm x 52 mm), making it easy to install even in space-constrained environments.
Energy Efficient: The module operates with low power consumption (5W), contributing to energy savings while delivering high performance.
Wide Temperature Range: The TSXETY110 operates in environments ranging from 0°C to 55°C (32°F to 131°F), making it suitable for various industrial settings.
Reliable Communication: The module ensures robust and secure communication over Ethernet, offering a high level of performance and resistance to network interference, ideal for mission-critical applications.

Technical FAQs

What communication protocol does the TSXETY110 support?
- The TSXETY110 supports Modbus TCP, a widely used protocol for industrial automation systems, enabling communication with a variety of Modbus-compatible devices.
How many Ethernet ports does the TSXETY110 have?
- The TSXETY110 has one Ethernet port (RJ45) that supports 10/100 Mbps communication speeds, ideal for connecting to industrial Ethernet networks.
What is the power consumption of the TSXETY110?
- The TSXETY110 consumes approximately 5W of power, ensuring energy-efficient operation in your automation system.
What is the operating temperature range of the TSXETY110?
- The TSXETY110 operates within a temperature range of 0°C to 55°C (32°F to 131°F), making it suitable for most industrial environments.
Can the TSXETY110 be used outdoors?
- The TSXETY110 is designed for indoor use. If used outdoors, a protective enclosure is recommended to shield it from environmental factors like dust, moisture, or extreme temperatures.
What certifications does the TSXETY110 hold?
- The module is UL, CE, and RoHS certified, ensuring compliance with international standards for safety, environmental, and quality assurance.
What power supply is required for the TSXETY110?
- The module operates on a 24V DC power supply, which can be provided by a Modicon Premium PLC or an external power source.
What are the physical dimensions of the TSXETY110?
- The TSXETY110 has compact dimensions of 4.65 inches x 3.94 inches x 2.05 inches (118 mm x 100 mm x 52 mm), making it easy to fit into control panels or distributed control systems.
How do I integrate the TSXETY110 with my existing Modicon PLC system?
- Integration of the TSXETY110 is straightforward. Connect the module to your Ethernet network and configure it via the Modicon Premium PLC’s programming software.
Is the TSXETY110 compatible with other Modicon PLCs?
- Yes, while the TSXETY110 is optimized for Modicon Premium PLCs, it may also be compatible with other Modicon PLCs that support Modbus TCP.
