The Schneider TSXETY4102 is a high-performance Ethernet communication module designed for Modicon Premium PLCs, featuring a 4-port Ethernet switch. This module enables efficient and reliable communication between Modicon PLCs and other devices over Ethernet networks, supporting high-speed data transfer for complex industrial automation systems. With its built-in Ethernet switch, the TSXETY4102 is ideal for creating scalable, high-speed, and robust industrial Ethernet networks. Whether for Ethernet/IP, Modbus TCP, or other protocols, this module ensures seamless integration and real-time communication for a wide range of industrial applications. Its versatility and advanced features make it a powerful choice for distributed control systems, remote I/O applications, and large-scale networking needs.

Technical Specifications

Specification	Details
Model	TSXETY4102
Module Type	Ethernet Communication Module (4-Port Switch)
Ethernet Ports	4 x RJ45 10/100/1000 Mbps
Communication Protocols	Ethernet/IP, Modbus TCP
Transmission Speed	10/100/1000 Mbps
Operating Voltage	24V DC
Power Consumption	6W
Dimensions	4.65 in x 3.94 in x 2.05 in (118 mm x 100 mm x 52 mm)
Weight	0.45 kg (0.99 lbs)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Certifications	UL, CE, RoHS

Recommended Related Models

To further enhance your automation and networking solutions, consider pairing the TSXETY4102 with the following Schneider Electric products:

Modicon Premium TSXP574634 Processor: A powerful, high-performance processor that works seamlessly with the TSXETY4102, ensuring optimal control and monitoring of complex systems.
Modicon TSXPSY1200 Power Supply: A robust power supply designed to provide stable, continuous power for Modicon Premium PLCs and accessories, including the TSXETY4102.
Modicon TM3 Digital Input/Output Modules: Expand the I/O capabilities of your system with additional TM3 digital modules, complementing the TSXETY4102 for a fully integrated automation solution.

Popular Schneider Models

Modicon M580 Ethernet PLC: A modular, scalable Ethernet-based PLC that integrates well with the TSXETY4102 for large-scale, high-performance systems.
Modicon X80 I/O Modules: A versatile range of I/O modules that can complement the TSXETY4102 to extend your system’s I/O capacity, perfect for high-density automation systems.
Schneider Magelis GTU HMI: A user-friendly interface designed to integrate seamlessly with Modicon PLCs, offering operators an intuitive way to monitor and control automated processes.

Applications

The Schneider TSXETY4102 is designed to provide high-speed Ethernet communication for a range of industrial automation applications. Here are the key use cases:

Industrial Ethernet Networks: The TSXETY4102 is ideal for creating high-speed industrial Ethernet networks, connecting multiple PLCs, devices, and controllers across large facilities or multiple sites.
Distributed Control Systems (DCS): Easily manage distributed control systems by connecting remote I/O systems, sensors, and actuators, enabling real-time communication between Modicon PLCs and Modbus-based devices.
SCADA Systems: Integrate seamlessly with SCADA (Supervisory Control and Data Acquisition) systems, allowing real-time data exchange and control across geographically distributed systems.
Remote I/O and Device Networking: Use the module to connect remote I/O modules, sensors, and other devices to Modicon Premium PLCs, improving scalability and reducing wiring complexity in large control systems.
Ethernet/IP & Modbus TCP Applications: Leverage the TSXETY4102 to enable communication using Ethernet/IP and Modbus TCP, ensuring compatibility with a wide range of devices and systems, including sensors, drives, and other industrial equipment.

Advantages

Built-In 4-Port Ethernet Switch: The 4-port Ethernet switch simplifies network design and installation by allowing multiple devices to be connected to the same network, reducing the need for external switches and improving network performance.
High-Speed Ethernet Communication: The TSXETY4102 supports 10/100/1000 Mbps Ethernet connectivity, ensuring fast data transfer for high-performance, real-time industrial applications.
Flexible Networking: This module is ideal for creating scalable Ethernet networks, allowing users to add new devices and systems to the network with ease, and supporting complex, distributed systems.
Compact and Easy to Install: Despite offering a 4-port Ethernet switch, the TSXETY4102 has a compact size (118 mm x 100 mm x 52 mm), making it easy to integrate into control panels and distributed systems.
Energy Efficient: With a power consumption of just 6W, the module operates efficiently, contributing to the overall energy savings of your automation system.
Wide Temperature Range: The TSXETY4102 is designed to function in a variety of industrial environments, with an operating temperature range of 0°C to 55°C (32°F to 131°F).
Robust Industrial Certifications: The TSXETY4102 is certified for UL, CE, and RoHS, ensuring compliance with global safety, environmental, and quality standards.

Technical FAQs

How many Ethernet ports does the TSXETY4102 provide?
- The TSXETY4102 includes 4 Ethernet ports (RJ45) supporting 10/100/1000 Mbps, allowing for high-speed data transfer between multiple devices.
What protocols are supported by the TSXETY4102?
- The module supports Ethernet/IP and Modbus TCP, enabling seamless communication with a wide range of industrial devices and systems.
What is the power consumption of the TSXETY4102?
- The TSXETY4102 consumes 6W of power, making it an energy-efficient solution for expanding Ethernet-based networks.
What is the operating temperature range of the TSXETY4102?
- The module operates within a temperature range of 0°C to 55°C (32°F to 131°F), suitable for most industrial environments.
Can the TSXETY4102 be used for outdoor applications?
- The TSXETY4102 is designed for indoor use. For outdoor applications, a protective enclosure is recommended to shield the module from harsh environmental conditions.
What certifications does the TSXETY4102 have?
- The TSXETY4102 is certified for UL, CE, and RoHS, ensuring it meets global standards for safety, environmental, and quality compliance.
What is the maximum Ethernet speed of the TSXETY4102?
- The module supports 10/100/1000 Mbps Ethernet communication, offering high-speed data transfer suitable for demanding industrial applications.
How do I integrate the TSXETY4102 into my system?
- Integration is straightforward; simply connect the module to your Ethernet network, and configure it via the Modicon Premium PLC’s programming software.
What are the physical dimensions of the TSXETY4102?
- The module has compact dimensions of 4.65 inches x 3.94 inches x 2.05 inches (118 mm x 100 mm x 52 mm), making it easy to install in control panels or distributed control systems.
Is the TSXETY4102 compatible with all Modicon PLCs?
- The TSXETY4102 is optimized for Modicon Premium PLCs, but it may also work with other Modicon PLCs that support Ethernet-based communication, such as Modicon M340 or Modicon M580, depending on the configuration.
