The Schneider TSXETY4103 is a 4-port managed Ethernet switch designed for Modicon Premium PLCs. This module is optimized for high-speed Ethernet communication and provides advanced networking capabilities for large-scale industrial automation systems. With 10/100/1000 Mbps support, it enables seamless data transfer and connectivity between multiple Modicon PLCs, remote I/O devices, HMIs, and other industrial equipment. The TSXETY4103 offers enhanced network management features such as VLAN (Virtual Local Area Network) support, network monitoring, and traffic prioritization, ensuring reliable, scalable, and secure communication within Ethernet-based networks. Whether you're building a distributed control system (DCS) or integrating SCADA systems, this module is perfect for mission-critical applications requiring high-performance and flexibility.

Technical Specifications

Specification	Details
Model	TSXETY4103
Module Type	4-Port Managed Ethernet Switch
Ethernet Ports	4 x RJ45 10/100/1000 Mbps
Communication Protocols	Ethernet/IP, Modbus TCP, TCP/IP
Transmission Speed	10/100/1000 Mbps
Operating Voltage	24V DC
Power Consumption	7W
Dimensions	4.65 in x 3.94 in x 2.05 in (118 mm x 100 mm x 52 mm)
Weight	0.45 kg (0.99 lbs)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Certifications	UL, CE, RoHS

Recommended Related Models

For a complete and scalable automation solution, consider combining the TSXETY4103 with the following Schneider Electric products:

Modicon Premium TSXP574634 Processor: A powerful processor that integrates seamlessly with the TSXETY4103, providing high-level processing power for complex automation systems.
Modicon TSXPSY1200 Power Supply: A reliable power supply that supports your Modicon Premium PLC system, ensuring stable operation and continuous power for your networked devices.
Modicon TM3 I/O Modules: Expand your system’s input and output capabilities with these flexible, compact modules, ideal for use in combination with the TSXETY4103 for enhanced control.

Popular Schneider Models

Modicon M580 Ethernet PLC: A modular PLC that offers native Ethernet connectivity, allowing you to build scalable automation systems that easily integrate with the TSXETY4103.
Modicon X80 I/O Modules: A flexible I/O platform that can be paired with the TSXETY4103 to extend your system’s I/O capabilities for a variety of industrial applications.
Schneider Magelis GTU HMI: A human-machine interface that integrates with Modicon PLCs, offering operators intuitive control over automated systems and processes.

Applications

The Schneider TSXETY4103 module is designed for high-performance Ethernet communication across a wide range of industrial applications. Some key use cases include:

Industrial Ethernet Networks: Enable high-speed communication within your Ethernet network, connecting PLCs, I/O devices, and other equipment to ensure efficient data transfer across large-scale systems.
Distributed Control Systems (DCS): Create a distributed network of PLCs and remote I/O devices, all managed via the TSXETY4103’s 4-port managed switch, ideal for large, complex industrial environments.
SCADA System Integration: Connect PLCs, field devices, and other automation equipment to SCADA systems, allowing for real-time monitoring, control, and data exchange.
Factory Automation: Use the TSXETY4103 to link devices like sensors, actuators, robots, and more, ensuring seamless communication across all elements of your automation system.
Industrial Internet of Things (IIoT): Integrate smart devices, sensors, and remote modules, leveraging the TSXETY4103 for real-time data exchange and advanced analytics in IIoT applications.

Advantages

Managed Ethernet Switch: The 4-port managed Ethernet switch enables advanced features such as VLAN, traffic prioritization, and network monitoring, making it ideal for mission-critical industrial networks.
High-Speed Ethernet Connectivity: Supports 10/100/1000 Mbps Ethernet, ensuring fast and reliable communication across industrial networks with minimal latency.
Scalable and Flexible Networking: The TSXETY4103 allows for easy network expansion and integration, supporting multiple devices across a wide industrial network while providing centralized control.
Compact and Easy Installation: With its compact size (118 mm x 100 mm x 52 mm), the TSXETY4103 can be installed in tight spaces, reducing the need for external switches or additional hardware.
Power Efficiency: Consuming just 7W of power, the TSXETY4103 operates efficiently, helping reduce the overall energy consumption of your system.
Wide Temperature Range: With an operating temperature range of 0°C to 55°C (32°F to 131°F), the module can function reliably in diverse industrial environments.
Enhanced Network Security: The managed switch capabilities ensure secure communication, reducing the risk of network congestion or unauthorized access to sensitive data.

Technical FAQs

What makes the TSXETY4103 a "managed" Ethernet switch?
- The TSXETY4103 includes features such as VLAN support, traffic prioritization, and network monitoring, which allow for advanced network management, ensuring optimized performance and security.
How many Ethernet ports are available on the TSXETY4103?
- The module features 4 Ethernet ports (RJ45) that support 10/100/1000 Mbps speeds, allowing for efficient communication across multiple devices.
What is the power consumption of the TSXETY4103?
- The TSXETY4103 consumes approximately 7W of power, making it an energy-efficient choice for high-performance industrial networks.
What protocols are supported by the TSXETY4103?
- The module supports Ethernet/IP, Modbus TCP, and TCP/IP, ensuring compatibility with a wide range of industrial communication standards.
What is the operating temperature range of the TSXETY4103?
- The TSXETY4103 operates within a temperature range of 0°C to 55°C (32°F to 131°F), suitable for most industrial environments.
Can the TSXETY4103 be used outdoors?
- The TSXETY4103 is designed for indoor use. To use it outdoors, a protective enclosure should be used to shield it from environmental elements such as dust, moisture, or extreme temperatures.
What certifications does the TSXETY4103 hold?
- The module is UL, CE, and RoHS certified, ensuring compliance with international safety, environmental, and quality standards.
What are the dimensions of the TSXETY4103?
- The module has compact dimensions of 4.65 inches x 3.94 inches x 2.05 inches (118 mm x 100 mm x 52 mm), making it easy to install in control panels or networking setups.
How do I integrate the TSXETY4103 with my existing Modicon system?
- Integration is straightforward—simply connect the module to your Ethernet network and configure it via the Modicon Premium PLC’s programming software to manage communication between devices.
Is the TSXETY4103 compatible with all Modicon PLCs?
- The TSXETY4103 is optimized for Modicon Premium PLCs, but it can also be integrated with other Modicon PLC models supporting Ethernet-based communication protocols.
