The Schneider TSXFPACC3 is a fiber optic communication module designed for use with Modicon Premium PLCs, providing robust, high-speed connectivity over long distances. Utilizing fiber optic technology, the TSXFPACC3 offers enhanced communication reliability, high bandwidth, and excellent noise immunity, making it ideal for applications where electromagnetic interference (EMI) or long-distance communication is required. This module supports Ethernet/IP and Modbus TCP protocols, enabling seamless integration into industrial Ethernet networks. Whether you're building large-scale distributed control systems (DCS), integrating remote I/O devices, or expanding network capabilities across a factory or across multiple sites, the TSXFPACC3 offers the performance and scalability you need for modern industrial communication.

Technical Specifications

Specification	Details
Model	TSXFPACC3
Module Type	Fiber Optic Communication Module
Communication Protocol	Ethernet/IP, Modbus TCP
Transmission Speed	100 Mbps
Ethernet Ports	1 x SC Fiber Optic Port (Single-Mode)
Operating Voltage	24V DC
Power Consumption	5W
Dimensions	4.65 in x 3.94 in x 2.05 in (118 mm x 100 mm x 52 mm)
Weight	0.5 kg (1.1 lbs)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Certifications	UL, CE, RoHS

Recommended Related Models

For complete system integration, consider pairing the TSXFPACC3 with the following Schneider Electric components:

Modicon Premium TSXP574634 Processor: A high-performance processor that can efficiently handle large-scale automation projects, integrating seamlessly with the TSXFPACC3 for high-speed communication.
Modicon TSXPSY1200 Power Supply: A reliable power supply designed to work with the TSXFPACC3, ensuring stable and continuous operation of your networked PLC system.
Modicon TM3 I/O Modules: Expand the capabilities of your Modicon PLC system with the TM3 I/O modules, which integrate with the TSXFPACC3 for scalable and flexible control systems.

Popular Schneider Models

Modicon M580 Ethernet PLC: A modular and scalable Ethernet PLC that pairs well with the TSXFPACC3 for high-performance industrial communication networks.
Modicon X80 I/O Modules: These I/O modules can be integrated with the TSXFPACC3 to expand I/O capabilities, providing additional flexibility for distributed control systems.
Magelis GTU HMI: A human-machine interface that offers seamless integration with the Modicon PLCs, enabling users to monitor and control their automated systems.

Applications

The Schneider TSXFPACC3 fiber optic communication module is designed to support a range of industrial networking applications, including:

Industrial Ethernet Networks: Fiber optic communication is ideal for long-distance, high-speed data transmission in Ethernet/IP and Modbus TCP networks, enabling seamless integration of multiple devices over large geographical areas.
Distributed Control Systems (DCS): The TSXFPACC3 is perfect for connecting remote I/O systems, sensors, and actuators across distant locations within a Modicon Premium PLC network, facilitating real-time data transfer in complex automation systems.
SCADA System Integration: Leverage fiber optic communication to integrate Modicon PLCs with SCADA systems, ensuring high-speed data transfer and reliable connectivity for large-scale industrial monitoring and control.
Factory Automation: Improve factory automation by connecting various devices such as drives, robots, and other automated machinery to a Modicon Premium PLC via the TSXFPACC3, providing enhanced communication and monitoring capabilities.
Long-Distance Communication: Use the single-mode fiber optic port to establish high-speed communication over long distances (up to 10 km or more), ideal for applications where copper wiring is impractical due to distance or electromagnetic interference.

Advantages

High-Speed Fiber Optic Communication: The TSXFPACC3 supports 100 Mbps fiber optic communication, providing fast and reliable data transfer, even over long distances, without degradation in signal quality.
Noise Immunity: Fiber optic cables are immune to electromagnetic interference (EMI), making the TSXFPACC3 an ideal choice for environments with high electrical noise or where data integrity is crucial.
Long-Distance Communication: The single-mode fiber optic port enables reliable communication over distances of up to 10 km or more, offering flexibility in large industrial setups.
Compact and Easy to Install: The compact design (118 mm x 100 mm x 52 mm) allows the module to be installed in space-constrained areas without compromising performance or functionality.
Low Power Consumption: With a power consumption of only 5W, the TSXFPACC3 operates efficiently while supporting high-speed communication.
Versatile Protocol Support: The module supports both Ethernet/IP and Modbus TCP, ensuring compatibility with a wide range of industrial automation devices and systems.
Wide Operating Temperature Range: The TSXFPACC3 operates within a temperature range of 0°C to 55°C (32°F to 131°F), making it suitable for most industrial environments.
Global Certifications: Certified for UL, CE, and RoHS, the TSXFPACC3 meets international standards for safety, quality, and environmental compliance.

Technical FAQs

What communication protocols does the TSXFPACC3 support?
- The TSXFPACC3 supports Ethernet/IP and Modbus TCP, enabling high-speed communication with other industrial devices that use these protocols.
What type of fiber optic cable is required for the TSXFPACC3?
- The TSXFPACC3 uses single-mode fiber optic cables with SC connectors, allowing for long-distance communication (up to 10 km or more).
What is the maximum transmission speed of the TSXFPACC3?
- The TSXFPACC3 supports a 100 Mbps transmission speed over fiber optic cables, ensuring high-speed communication for large-scale industrial applications.
What is the operating voltage of the TSXFPACC3?
- The module operates on 24V DC, which is commonly used in industrial automation systems.
Can the TSXFPACC3 be used outdoors?
- The TSXFPACC3 is designed for indoor use. For outdoor installations, protective enclosures should be used to shield the module from environmental factors such as dust and moisture.
What is the power consumption of the TSXFPACC3?
- The TSXFPACC3 consumes 5W of power, making it an energy-efficient solution for fiber optic communication in industrial networks.
What is the maximum communication distance supported by the TSXFPACC3?
- The TSXFPACC3 supports communication distances of up to 10 km (6.2 miles) over single-mode fiber optic cables, ideal for large industrial systems.
How do I integrate the TSXFPACC3 with my existing Modicon PLC system?
- Simply connect the fiber optic port to your Ethernet network and configure the module through the Modicon Premium PLC programming software to enable communication with other devices over the network.
What are the physical dimensions of the TSXFPACC3?
- The TSXFPACC3 measures 4.65 inches x 3.94 inches x 2.05 inches (118 mm x 100 mm x 52 mm), allowing it to be easily integrated into control panels or other networked systems.
Is the TSXFPACC3 compatible with all Modicon PLCs?
- The TSXFPACC3 is specifically designed for Modicon Premium PLCs, but it can also be integrated with other Modicon PLCs that support Ethernet/IP or Modbus TCP communication protocols.
