The Schneider TSXP57024M is a high-performance Modicon Premium processor, engineered to provide exceptional processing power for industrial automation systems. This module is designed for seamless integration with Schneider Electric’s Modicon Premium PLC series, offering advanced control, real-time data processing, and scalability. With its robust architecture, the TSXP57024M ensures that even the most complex automation processes, such as factory automation, process control, and building management, run smoothly and efficiently. Ideal for large-scale applications, the TSXP57024M supports a wide range of communication protocols, including Ethernet/IP and Modbus TCP, and is capable of handling large I/O configurations and distributed networks. With its high-speed processing, expandable memory, and reliable performance, the TSXP57024M is a powerful solution for industries looking to optimize their automation systems.

Technical Specifications

Specification	Details
Model	TSXP57024M
Module Type	Modicon Premium Processor
Processor Type	High-performance Processor
Processor Speed	400 MHz
Memory	8 MB RAM (Expandable)
Communication Protocols	Ethernet/IP, Modbus TCP, FIPIO
I/O Capacity	Up to 8192 I/O points
Operating Voltage	24V DC
Power Consumption	10W
Dimensions	5.67 in x 4.13 in x 2.17 in (144 mm x 105 mm x 55 mm)
Weight	0.7 kg (1.54 lbs)
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Certifications	UL, CE, RoHS

Recommended Related Models

For a complete and scalable solution when integrating the TSXP57024M, consider pairing it with these Modicon Premium components:

Modicon TSXPSY1200 Power Supply: A high-quality power supply designed to deliver stable voltage to your Modicon Premium PLC components, ensuring reliable operation for complex automation systems.
Modicon TM3 I/O Modules: Expand the I/O capabilities of your Modicon Premium PLC by adding TM3 I/O modules, which can be configured for a variety of digital and analog inputs/outputs.
Modicon X80 I/O Modules: For even greater scalability, the X80 I/O modules integrate seamlessly with the TSXP57024M, allowing for large-scale control in demanding industrial environments.

Popular Schneider Models

Modicon M580 Ethernet PLC: This modular PLC offers enhanced flexibility and performance, ideal for high-speed Ethernet/IP communications and large-scale distributed systems.
Modicon X80 I/O Modules: A scalable solution for I/O expansion in complex automation systems, compatible with the TSXP57024M for seamless control and monitoring.
Magelis GTU HMI: The Magelis GTU HMI provides an intuitive interface for operators, connecting easily with Modicon Premium PLCs for real-time monitoring and control of industrial processes.

Applications

The Schneider TSXP57024M processor is designed for high-demand industrial applications that require fast, reliable, and flexible control. Some of the ideal applications include:

Industrial Automation: The TSXP57024M is designed for complex automation tasks, including controlling production lines, robotics, and automated machinery in industries such as automotive, food & beverage, and electronics.
Process Control: This processor is well-suited for process control applications in industries such as chemicals, petrochemicals, and pharmaceuticals, where precise and reliable control is critical.
Energy Management: Used in energy management systems, the TSXP57024M helps to optimize energy usage, manage distributed energy resources, and ensure seamless communication with smart grid infrastructure.
Building Automation: The processor is ideal for controlling HVAC systems, lighting, and other building systems in large commercial or industrial buildings, offering efficient control and monitoring via Ethernet/IP and Modbus TCP.
Water Treatment Systems: The TSXP57024M is a key component in water treatment plants, controlling pumps, valves, and other systems in real-time for efficient operations and regulatory compliance.

Advantages

Fast Processing Speed: The TSXP57024M is powered by a 400 MHz processor, ensuring rapid data processing for real-time control and monitoring in demanding automation tasks.
Large Memory Capacity: With 8 MB of RAM (expandable), the TSXP57024M can handle large applications with complex logic and extensive I/O operations, supporting up to 8192 I/O points.
Flexible Communication Options: Supporting Ethernet/IP, Modbus TCP, and FIPIO communication protocols, the TSXP57024M ensures smooth integration with a wide range of industrial devices and systems, allowing for seamless data exchange.
Compact Design: With dimensions of 144 mm x 105 mm x 55 mm, the TSXP57024M offers a compact footprint, ideal for installations with limited space or confined control panels.
Energy Efficient: Consuming only 10W of power, the TSXP57024M offers high processing capabilities while maintaining energy efficiency, minimizing operational costs.
Scalable and Expandable: The processor can be integrated with additional I/O modules to support large-scale industrial control systems, making it a flexible solution as your automation needs grow.
High Reliability: The TSXP57024M is built to operate in demanding environments, offering robust performance and meeting global safety and environmental standards with UL, CE, and RoHS certifications.
Wide Temperature Range: Operating between 0°C to 55°C (32°F to 131°F), the processor is suited for use in various industrial conditions, from factory floors to extreme environments.

Technical FAQs

What is the processor speed of the TSXP57024M?
- The TSXP57024M features a 400 MHz processor, which delivers fast and efficient data processing for demanding automation tasks.
What is the I/O capacity of the TSXP57024M?
- The TSXP57024M supports up to 8192 I/O points, making it suitable for large-scale industrial applications with extensive control and monitoring needs.
What communication protocols are supported by the TSXP57024M?
- The processor supports Ethernet/IP, Modbus TCP, and FIPIO, enabling flexible and seamless communication with a wide range of industrial devices.
What is the power consumption of the TSXP57024M?
- The TSXP57024M consumes only 10W of power, providing high performance while remaining energy-efficient.
What is the memory capacity of the TSXP57024M?
- The processor comes with 8 MB of RAM, which can be expanded to support larger and more complex applications.
What is the operating temperature range of the TSXP57024M?
- The TSXP57024M operates within a temperature range of 0°C to 55°C (32°F to 131°F), making it suitable for a wide variety of industrial environments.
Is the TSXP57024M compatible with all Modicon Premium PLC systems?
- Yes, the TSXP57024M is fully compatible with the Modicon Premium PLC series, ensuring seamless integration into your automation system.
What certifications does the TSXP57024M have?
- The TSXP57024M is certified for UL, CE, and RoHS, ensuring it meets global safety, environmental, and quality standards.
How do I install the TSXP57024M in my system?
- The TSXP57024M can be easily installed in the Modicon Premium PLC system, where it connects to the I/O base and can be configured using Schneider Electric's programming software.
Can the TSXP57024M be used for process control applications?
- Yes, the TSXP57024M is ideal for process control applications in industries like chemicals, pharmaceuticals, and food & beverage, offering precise control and real-time data monitoring.
