Bently 106765-13 Power Supply Module

Introduction

The Bently 106765-13 is a high-reliability power supply module designed for use with Bently Nevada 3500 Series machinery protection systems. It ensures a stable and continuous 24 VDC power supply for critical components such as vibration sensors, accelerometers, and other monitoring devices that are essential for machinery condition monitoring. This power supply module plays a vital role in ensuring that the system operates without interruptions, allowing early detection of potential faults, and minimizing the risk of equipment failure or downtime.

Built to endure the harsh environments found in industrial applications, the 106765-13 provides optimal performance even under extreme conditions. It features overload, short-circuit, and thermal protection to ensure both safety and operational reliability. With an efficient power conversion and compact design, it is perfect for a wide range of machinery protection and condition monitoring applications across various industries such as energy, manufacturing, and oil & gas.

Technical Specifications

Specification	Details
Model	106765-13
Module Type	Power Supply Module
Input Voltage	120/240 VAC
Output Voltage	24 VDC
Output Current	6 A
Size (W x H x D)	160 x 120 x 100 mm
Weight	1.3 kg
Mounting Type	Panel Mounting
Operating Temperature	-20°C to +70°C
Power Consumption	144 W
Protection Features	Overload, Short-circuit, Thermal Protection
Certifications	CE, UL, RoHS

Recommended Related Models

Model	Module Type	Output Voltage	Output Current	Input Voltage
Bently 106765-12	Power Supply Module	24 VDC	5 A	120/240 VAC
Bently 106765-10	Power Supply Module	24 VDC	6 A	120/240 VAC
Bently 106765-11	Power Supply Module	24 VDC	5 A	120/240 VAC

Popular Bently Models

Model	Module Type	Output Voltage	Output Current	Input Voltage
Bently 106765-13	Power Supply Module	24 VDC	6 A	120/240 VAC
Bently 106765-10	Power Supply Module	24 VDC	6 A	120/240 VAC
Bently 106765-12	Power Supply Module	24 VDC	5 A	120/240 VAC

Applications

Machinery Protection Systems: The Bently 106765-13 is a core component in machinery protection systems, supplying uninterrupted power to vibration sensors, accelerometers, and other critical components used for real-time monitoring and fault detection in rotating machinery.
Condition Monitoring: The module is essential in condition monitoring applications, where it ensures the continuous operation of sensors and monitoring systems that track machinery health and performance.
Predictive Maintenance: It is ideal for use in predictive maintenance systems, helping to ensure that all power-sensitive components in machinery protection systems remain operational, thus enabling early detection of potential issues before they lead to equipment failure.
Industrial Automation: The 106765-13 supports industrial automation systems that rely on continuous power to operate sensors and control equipment for process monitoring and quality assurance.
Energy & Power Generation: This power supply module is used extensively in energy generation facilities to ensure that machinery such as turbines and generators are continuously monitored and protected from potential failures.

Advantages

High Power Output: The 6 A output is sufficient to power multiple sensors and devices simultaneously, ensuring stable operation of monitoring systems.
Compact and Space-Saving Design: Despite the high power output, the 106765-13 maintains a compact size (160 x 120 x 100 mm), making it ideal for installation in tight spaces.
Efficient Power Conversion: The module is designed for low power loss, operating with a power consumption of 144 W while providing high power output to support the entire monitoring system.
Wide Input Voltage Range: The module can handle both 120 VAC and 240 VAC inputs, making it flexible for use in various global installations.
Integrated Protection: Overload, short-circuit, and thermal protection ensure the safety of both the module and the system it powers, minimizing the risk of damage.
Durability: With an operating temperature range of -20°C to +70°C, the 106765-13 is built to withstand harsh industrial environments, ensuring reliable performance even in extreme conditions.
