The Schneider STBCPS2111 is a power supply module designed for use within the Modicon STB automation systems. This power supply ensures stable, reliable, and efficient operation of all connected modules, including I/O modules, controllers, and other devices within a distributed control system. Engineered for industrial environments, the STBCPS2111 offers a 24V DC output, ensuring a consistent and high-quality power source for your system’s critical components. The module is essential for maintaining optimal system performance and safety, supporting industries such as automotive, food and beverage, chemical processing, energy, and manufacturing.

Technical Specifications

Specification	Details
Model	STBCPS2111
Module Type	Power Supply Module
Output Voltage	24V DC
Output Current	4A
Power Rating	96W
Input Voltage	100-240V AC
Input Frequency	50/60 Hz
Power Factor	>0.95
Dimensions	5.2 in x 4.5 in x 2.9 in (132 mm x 115 mm x 74 mm)
Weight	0.75 kg (1.65 lbs)
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Certifications	UL, CE, RoHS

Recommended Related Models

To complement the STBCPS2111 power supply module, consider integrating the following Schneider Electric products:

Modicon STB I/O Modules: A range of I/O modules designed to seamlessly connect to the STBCPS2111, providing additional control capabilities for industrial automation systems.
Modicon STB Controllers: Programmable logic controllers (PLCs) that work in tandem with the STBCPS2111 power supply for managing and automating complex processes.
Modicon TM3 I/O Modules: These modular I/O solutions integrate easily with the STBCPS2111 for scalable I/O functionality in a variety of industrial applications.

Popular Schneider Models

Modicon M580 Ethernet PLC: This Ethernet-based PLC integrates perfectly with the STBCPS2111, providing advanced control and real-time data processing for large-scale automation systems.
Magelis GTU HMI: A graphical touch screen interface that can be easily connected with the STBCPS2111, offering intuitive control and monitoring for automated systems.
Modicon X80 I/O Modules: A comprehensive range of I/O modules designed for integration with the STBCPS2111, ensuring high-performance control in critical industrial processes.

Applications

The Schneider STBCPS2111 power supply module is an essential component for systems requiring reliable, continuous power in industries like:

Industrial Automation: Powers automation systems, robotics, conveyor systems, and packaging machinery in industries such as automotive, electronics, and consumer goods.
Process Control: Ensures consistent power for control systems managing temperature, pressure, flow, and level in industries like chemical, food & beverage, and pharmaceutical.
Building Automation: Powers HVAC, lighting, energy management, and security systems in commercial and industrial buildings, promoting operational efficiency and energy savings.
Energy Management: Ideal for smart grids, renewable energy systems, and industrial power control, supporting the efficient distribution of energy.
Water Treatment: Supports water pumping systems, filtration units, and water quality monitoring systems in municipal and industrial water treatment plants.

Advantages

Reliable Power Output: The STBCPS2111 provides a stable 24V DC output with 4A current, ensuring reliable operation of connected devices without voltage fluctuations.
High Power Rating: With a power rating of 96W, the module delivers enough power to support multiple connected STB system components and ensure smooth operation.
Wide Input Voltage Range: With an input voltage range of 100-240V AC, the STBCPS2111 can be used globally, adapting to different industrial power sources and environments.
Compact Design: The STBCPS2111 has a compact form factor (132 mm x 115 mm x 74 mm), making it easy to install in space-constrained environments while maintaining high power output.
Efficient Power Factor: With a power factor of >0.95, the module reduces energy waste, contributing to overall energy efficiency and lowering operational costs.
Wide Operating Temperature Range: The STBCPS2111 operates in extreme temperature environments from -20°C to 60°C (-4°F to 140°F), making it suitable for use in various industrial applications.
Certified for Safety: The module is certified with UL, CE, and RoHS, ensuring compliance with international standards for safety, quality, and environmental impact.
Durable and Long-Lasting: With a storage temperature range of -40°C to 85°C, the STBCPS2111 is designed for long-term performance in harsh environments.

Technical FAQs

What is the output voltage of the STBCPS2111?
- The STBCPS2111 provides a stable 24V DC output, ideal for powering various Modicon STB system modules.
What is the power consumption of the STBCPS2111?
- The STBCPS2111 has a power rating of 96W, capable of supplying power to multiple connected modules while maintaining energy efficiency.
What is the input voltage range for the STBCPS2111?
- The module operates with an input voltage range of 100-240V AC, making it suitable for use in various regions and industrial setups.
What is the operating temperature range for the STBCPS2111?
- The STBCPS2111 operates within a temperature range of -20°C to 60°C (-4°F to 140°F), ensuring reliable performance in a variety of industrial environments.
What is the current rating of the STBCPS2111?
- The STBCPS2111 provides 4A of output current, ensuring sufficient power to drive multiple devices within the Modicon STB system.
How do I install the STBCPS2111?
- The STBCPS2111 is easy to install in your Modicon STB system by connecting it to the STB rack and configuring it through Schneider Electric’s programming software.
Is the STBCPS2111 compatible with other Schneider Electric products?
- Yes, the STBCPS2111 is fully compatible with Modicon STB I/O modules, PLCs, and other Schneider Electric products, making it an integral part of a larger automation system.
What certifications does the STBCPS2111 have?
- The STBCPS2111 is certified with UL, CE, and RoHS, ensuring it meets international safety, environmental, and quality standards.
Can the STBCPS2111 be used in outdoor applications?
- The STBCPS2111 is designed for indoor use, but can be used in outdoor environments if housed in an appropriate enclosure that protects against environmental factors.
What industries benefit from using the STBCPS2111?
- The STBCPS2111 is ideal for industries such as industrial automation, process control, energy management, building automation, and water treatment, ensuring reliable power for critical automation systems.
