The Emerson KJ3206X1-BA1 Intelligent Field Transmitter is a versatile, high-performance solution designed to provide precise measurements for pressure, flow, and level in complex industrial applications. Built with Rosemount™ technology, this transmitter is ideal for industries that demand accuracy, reliability, and safety, such as oil & gas, chemical processing, power generation, and water treatment. Featuring multi-variable capabilities, advanced diagnostics, and support for HART®, FOUNDATION™ fieldbus, and Profibus PA communication protocols, the KJ3206X1-BA1 integrates seamlessly with modern industrial control systems, offering superior process monitoring and control. Its rugged design ensures long-term reliability even in extreme conditions, making it a trusted solution for critical measurement needs.

Technical Specifications

Specification	Details
Model	Emerson KJ3206X1-BA1
Module Type	Intelligent Field Transmitter
Measurement Range	0.01 to 5000 m³/h (Flow), 0–15,000 psi (Pressure), 0–100 meters (Level)
Input Type	Differential Pressure, Flow, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4–20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.1" x 7.0" x 6.4" (231 mm x 178 mm x 162 mm)
Weight	2.55 kg (5.6 lbs)
Housing Material	Stainless Steel
Ingress Protection	IP66/IP67

Recommended Related Models

For additional features or different configurations, the following Emerson models are worth considering:

Emerson KJ3207X1-BA1 – A more advanced version offering additional multi-variable measurement capabilities and enhanced diagnostics for more complex industrial environments.
Emerson Rosemount 3051 – A highly versatile multi-variable transmitter, ideal for applications requiring accurate pressure, flow, and temperature measurements.
Emerson Rosemount 8700 – Best suited for non-intrusive, highly accurate flow measurement applications in industries such as chemical processing and water treatment.

Popular Emerson Models

The Rosemount™ series offers a range of highly reliable industrial measurement devices. Some of the most popular models include:

Emerson Rosemount 3051 – Provides multi-variable measurement with exceptional accuracy, used across various industries for pressure, flow, and temperature monitoring.
Emerson Rosemount 2088 – A cost-effective solution for general-purpose pressure and flow measurement, designed for reliable and accurate performance.
Emerson 1151 – A durable, high-performance transmitter for pressure, level, and temperature measurement, widely used in industrial and manufacturing environments.

Applications

The Emerson KJ3206X1-BA1 is engineered for industries that demand high-precision measurement for process control and optimization. It is suitable for a wide range of applications, including:

Oil & Gas: Essential for accurate monitoring of pressure, flow, and level in pipelines, wells, and refining processes. Helps ensure safety, efficiency, and compliance in upstream and downstream operations.
Chemical Processing: Provides high-precision measurement for critical chemical reactors, distillation columns, and storage tanks, helping to maintain process stability and optimize production.
Power Generation: Ideal for monitoring flow and pressure in turbines, boilers, and cooling systems. Ensures optimal power generation efficiency and operational reliability.
Water & Wastewater Treatment: Essential for accurate flow and level measurement in water treatment plants, helping to optimize purification processes and comply with environmental standards.
Food & Beverage: Supports accurate flow and level measurement in food production and processing systems, ensuring consistent product quality and regulatory compliance.

Advantages

Multi-Variable Measurement: The KJ3206X1-BA1 allows simultaneous measurement of pressure, flow, and level, providing a comprehensive and unified solution for process control and optimization.
High Accuracy: With ±0.05% of span accuracy, the transmitter ensures precise and reliable data, even for critical process measurements in harsh industrial environments.
Advanced Diagnostics: Equipped with Emerson Smart Diagnostics, this transmitter offers real-time insights into the performance of the system, allowing for predictive maintenance and minimizing downtime.
Durable Design: Built with stainless-steel housing and IP66/IP67 ingress protection, the KJ3206X1-BA1 is designed to perform reliably in the harshest and most demanding industrial environments.
Wide Operating Temperature Range: With an operating range of -40°C to 85°C (-40°F to 185°F), this transmitter is suitable for use in extreme temperature conditions, making it adaptable to diverse industrial applications.
Seamless Integration: The KJ3206X1-BA1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA communication protocols, ensuring compatibility with a wide range of modern industrial control systems.

Technical FAQs

What is the measurement range of the KJ3206X1-BA1?
The KJ3206X1-BA1 supports measurement of flow from 0.01 to 5000 m³/h, pressure up to 15,000 psi, and level from 0 to 100 meters.
What communication protocols are supported by the KJ3206X1-BA1?
This transmitter supports HART®, FOUNDATION™ fieldbus, and Profibus PA, providing flexible communication options for seamless integration with existing control systems.
What is the accuracy of the KJ3206X1-BA1?
The KJ3206X1-BA1 delivers ±0.05% of span accuracy, ensuring reliable and precise measurements for critical process applications.
What is the temperature range of the KJ3206X1-BA1?
The transmitter operates within a temperature range of -40°C to 85°C (-40°F to 185°F), making it suitable for extreme industrial environments.
What power supply does the KJ3206X1-BA1 require?
The KJ3206X1-BA1 operates on a 12–42 VDC power supply, providing the flexibility needed for various industrial setups.
Is the KJ3206X1-BA1 suitable for use in hazardous environments?
Yes, with IP66/IP67 ingress protection and a rugged stainless-steel housing, the KJ3206X1-BA1 is built to withstand harsh conditions and hazardous environments.
How is the KJ3206X1-BA1 installed?
The transmitter can be mounted using pipe-mounting or panel-mounting, offering versatility for different application needs.
Does the KJ3206X1-BA1 support multi-variable measurement?
Yes, the KJ3206X1-BA1 allows for simultaneous measurement of pressure, flow, and level, providing a comprehensive solution for complex process control systems.
Which industries benefit most from the KJ3206X1-BA1?
The KJ3206X1-BA1 is widely used in oil & gas, chemical processing, power generation, water treatment, and food & beverage industries, where accurate and reliable multi-variable measurement is critical for optimal process performance.
What is the weight of the KJ3206X1-BA1?
The KJ3206X1-BA1 weighs approximately 2.55 kg (5.6 lbs), making it easy to handle and install in various industrial applications.
