The Emerson KJ3208X1-BA1 Intelligent Field Transmitter is designed for high-precision measurement in demanding industrial environments. Featuring Emerson’s renowned Rosemount™ technology, this transmitter provides reliable and accurate measurement for pressure, flow, and level applications across a wide range of industries, including oil & gas, chemical processing, power generation, and water treatment. The KJ3208X1-BA1 is equipped with multi-variable measurement capabilities, advanced diagnostics, and a variety of communication options such as HART®, FOUNDATION™ fieldbus, and Profibus PA protocols. Its robust construction, along with high accuracy and reliability, makes it an ideal solution for optimizing complex processes while ensuring long-term operational stability in harsh environments.

Technical Specifications

Specification	Details
Model	Emerson KJ3208X1-BA1
Module Type	Intelligent Field Transmitter
Measurement Range	0.01 to 5000 m³/h (Flow), 0–15,000 psi (Pressure), 0–100 meters (Level)
Input Type	Differential Pressure, Flow, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4–20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.4" x 7.2" x 6.6" (239 mm x 183 mm x 168 mm)
Weight	2.60 kg (5.7 lbs)
Housing Material	Stainless Steel
Ingress Protection	IP66/IP67

Recommended Related Models

For industries requiring enhanced features or specific configurations, consider the following Emerson models:

Emerson KJ3209X1-BA1 – An advanced version with additional multi-variable measurement options and more sophisticated diagnostic capabilities for demanding process control.
Emerson Rosemount 3051 – A versatile and widely used multi-variable transmitter ideal for accurate pressure, flow, and temperature measurement in industrial applications.
Emerson Rosemount 8700 – Best suited for flow measurement, offering non-intrusive measurement in applications requiring minimal maintenance.

Popular Emerson Models

Emerson’s Rosemount™ series offers a range of reliable and precise measurement solutions. Popular models include:

Emerson Rosemount 3051 – Provides multi-variable measurement with excellent accuracy, making it suitable for a wide variety of industrial processes.
Emerson Rosemount 2088 – A cost-effective transmitter that ensures reliable performance for general-purpose pressure and flow applications.
Emerson 1151 – A rugged and versatile transmitter for precise pressure, level, and temperature measurement in industrial and manufacturing environments.

Applications

The Emerson KJ3208X1-BA1 is designed to deliver accurate and reliable measurements for critical process control across various industries:

Oil & Gas: Essential for pressure, flow, and level measurement in pipelines, refineries, and offshore platforms, ensuring operational safety and process efficiency.
Chemical Processing: Provides precise measurements for chemical reactors, distillation columns, and storage tanks, enabling process optimization and ensuring product quality.
Power Generation: Ideal for monitoring critical parameters such as flow and pressure in turbines, boilers, and cooling systems, improving efficiency and reducing downtime.
Water & Wastewater Treatment: Essential for monitoring flow and level in treatment plants, ensuring safe water quality and compliance with environmental standards.
Food & Beverage: Supports consistent flow and level measurement in production lines, ensuring the quality and compliance of food products with regulatory standards.

Advantages

Multi-Variable Measurement: The KJ3208X1-BA1 allows for simultaneous measurement of pressure, flow, and level, making it an all-in-one solution for complex industrial processes.
High Accuracy: With an accuracy of ±0.05% of span, this transmitter ensures precise measurements, vital for maintaining optimal process control and minimizing errors.
Advanced Diagnostics: Equipped with Emerson Smart Diagnostics, the KJ3208X1-BA1 provides real-time system performance data, enabling predictive maintenance and reducing the risk of unexpected downtime.
Durable Construction: With stainless-steel housing and IP66/IP67 ingress protection, the KJ3208X1-BA1 is built to withstand harsh environments and extreme weather conditions.
Wide Temperature Range: With an operating temperature range of -40°C to 85°C (-40°F to 185°F), the KJ3208X1-BA1 is suited for a wide variety of industrial environments, including those with extreme temperatures.
Seamless Communication Integration: Supports HART®, FOUNDATION™ fieldbus, and Profibus PA protocols, offering flexibility and compatibility with a variety of modern control systems.

Technical FAQs

What is the measurement range of the KJ3208X1-BA1?
The KJ3208X1-BA1 measures flow from 0.01 to 5000 m³/h, pressure up to 15,000 psi, and level from 0 to 100 meters.
What communication protocols are supported by the KJ3208X1-BA1?
The KJ3208X1-BA1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA, providing flexibility for integration into different industrial control systems.
What is the accuracy of the KJ3208X1-BA1?
The transmitter offers ±0.05% of span accuracy, ensuring precise measurements for critical process control.
What is the temperature range of the KJ3208X1-BA1?
The KJ3208X1-BA1 operates in a temperature range of -40°C to 85°C (-40°F to 185°F), making it suitable for diverse industrial environments.
What power supply does the KJ3208X1-BA1 require?
The KJ3208X1-BA1 operates on a 12–42 VDC power supply, providing versatility for various control systems.
Is the KJ3208X1-BA1 suitable for hazardous environments?
Yes, with IP66/IP67 ingress protection and a stainless-steel housing, the KJ3208X1-BA1 is designed for reliable operation in harsh and hazardous environments.
How is the KJ3208X1-BA1 installed?
The KJ3208X1-BA1 can be installed using pipe-mounting or panel-mounting, offering flexibility to suit a wide range of installation needs.
Does the KJ3208X1-BA1 support multi-variable measurement?
Yes, the KJ3208X1-BA1 can simultaneously measure pressure, flow, and level, making it ideal for complex, multi-faceted industrial processes.
Which industries benefit most from the KJ3208X1-BA1?
The KJ3208X1-BA1 is highly effective in industries such as oil & gas, chemical processing, power generation, water treatment, and food & beverage, where accurate and reliable measurements are essential.
What is the weight of the KJ3208X1-BA1?
The KJ3208X1-BA1 weighs 2.60 kg (5.7 lbs), making it easy to handle and install in various industrial settings.
