The Emerson KJ3242X1-BA1 is a state-of-the-art intelligent field transmitter designed to provide precise and reliable measurements for a wide range of industrial applications. Whether measuring pressure, flow, or level, the KJ3242X1-BA1 is engineered with advanced diagnostics and multi-variable capabilities to ensure superior performance in demanding environments. Powered by Emerson’s Rosemount™ technology, this transmitter is perfect for industries requiring high-accuracy measurements, such as oil & gas, chemical processing, power generation, and water treatment.

By offering simultaneous measurements of pressure, flow, and level, the KJ3242X1-BA1 simplifies system integration, reduces operational complexity, and enhances process safety. Its diagnostic features help identify potential issues before they become problems, ensuring reliability, accuracy, and efficiency in industrial processes.

Technical Specifications

Specification	Details
Model	Emerson KJ3242X1-BA1
Module Type	Intelligent Field Transmitter
Measurement Type	Pressure, Flow, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4-20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.6" x 7.5" x 7.0" (244 mm x 190 mm x 178 mm)
Weight	3.20 kg (7.05 lbs)
Ingress Protection	IP66/IP67
Housing Material	Stainless Steel

Recommended Related Models

If you’re looking for additional capabilities or variations, consider the following Emerson models:

Emerson KJ3242X1-BA2 – A similar multi-variable transmitter with enhanced diagnostic functions, ideal for more complex industrial systems.
Emerson Rosemount 3051 – A well-known transmitter that offers multi-variable measurement and high accuracy for pressure, flow, and level in industries requiring reliable performance.
Emerson Rosemount 8700 – A non-intrusive flow measurement solution providing precise and cost-effective performance, suitable for challenging industrial environments.

Popular Emerson Models

Explore other reliable Emerson transmitters that complement the KJ3242X1-BA1:

Emerson Rosemount 3051 – A versatile multi-variable transmitter offering accurate pressure, flow, and level measurements, widely used in industries like oil & gas, chemical processing, and power generation.
Emerson 1151 – Known for its ease of integration, the 1151 is a widely used pressure transmitter for general industrial applications.
Emerson Rosemount 2088 – A cost-effective pressure transmitter designed for everyday use across various industrial processes, offering reliable and accurate performance.

Applications

The Emerson KJ3242X1-BA1 is ideal for process control and monitoring in the following applications:

Oil & Gas: Used for pipeline pressure, tank level, and flow measurements in refining, upstream oil exploration, and storage facilities, ensuring safe and efficient operations.
Chemical Processing: Ensures accurate pressure, flow, and level measurements in chemical reactors, distillation columns, and storage tanks, supporting improved process control, compliance, and safety.
Power Generation: Ideal for monitoring boilers, turbines, cooling towers, and generators, ensuring optimal pressure, flow, and level parameters to reduce energy consumption and enhance system performance.
Water Treatment: Perfect for flow and level measurement in water treatment facilities, helping ensure water quality and regulatory compliance with environmental standards.
Food & Beverage: Critical for level and flow measurements in production lines, ensuring high product quality, consistency, and compliance with safety standards.

Advantages

High Accuracy: The KJ3242X1-BA1 boasts an accuracy of ±0.05% of span, ensuring precision in pressure, flow, and level measurements for industries requiring exacting standards.
Multi-Variable Measurement: With the ability to simultaneously measure pressure, flow, and level, the KJ3242X1-BA1 reduces the need for multiple devices, simplifying integration and reducing system complexity.
Enhanced Diagnostics: The Emerson Smart Diagnostics feature provides real-time data on the health of the transmitter, allowing operators to perform predictive maintenance and reduce unplanned downtime.
Durable and Robust: With an IP66/IP67 ingress protection rating, the KJ3242X1-BA1 is built to withstand harsh environments and offers reliable performance in difficult industrial conditions.
Wide Operating Temperature Range: Operating from -40°C to 85°C (-40°F to 185°F), this transmitter ensures functionality in extreme temperature environments, making it versatile for global applications.
Flexible Integration: The KJ3242X1-BA1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA communication protocols, making it compatible with a wide range of control systems.

Technical FAQs

What measurements can the KJ3242X1-BA1 perform?
The KJ3242X1-BA1 can simultaneously measure pressure, flow, and level, making it ideal for multi-variable applications in industrial settings.
What is the accuracy of the KJ3242X1-BA1?
The KJ3242X1-BA1 offers an impressive accuracy of ±0.05% of span, ensuring precise measurements in critical process control applications.
Can the KJ3242X1-BA1 be used in hazardous environments?
Yes, the KJ3242X1-BA1 is built with IP66/IP67 ingress protection, allowing it to operate reliably in harsh environments exposed to moisture, dust, and chemicals.
What communication protocols does the KJ3242X1-BA1 support?
The KJ3242X1-BA1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA, providing seamless integration with various industrial control systems.
What is the power supply requirement for the KJ3242X1-BA1?
The KJ3242X1-BA1 operates with a 12–42 VDC power supply, which is commonly used for industrial field transmitters.
How does the KJ3242X1-BA1 help with predictive maintenance?
Equipped with Emerson Smart Diagnostics, the transmitter provides real-time feedback on its health, enabling operators to detect potential issues early and reduce downtime.
What industries benefit from the KJ3242X1-BA1?
The KJ3242X1-BA1 is highly suitable for industries like oil & gas, chemical processing, power generation, water treatment, and food & beverage, where high-accuracy and reliable measurement are essential.
What is the weight of the KJ3242X1-BA1?
The KJ3242X1-BA1 weighs approximately 3.20 kg (7.05 lbs), making it manageable for field installations and handling.
Can the KJ3242X1-BA1 integrate with other Emerson products?
Yes, the KJ3242X1-BA1 is designed to seamlessly integrate with other Emerson devices, such as Rosemount™ transmitters and control systems, creating a cohesive and efficient process control solution.
What is the operating temperature range for the KJ3242X1-BA1?
The KJ3242X1-BA1 can operate in a temperature range of -40°C to 85°C (-40°F to 185°F), ensuring reliable performance across various environmental conditions.
