KJ4001X1-BA2 2 KJ4001X1-BA2 3 KJ4001X1-BA2 4

The Emerson KJ4001X1-BA2 is a state-of-the-art intelligent field transmitter engineered for precision measurement in demanding industrial environments. Designed to measure pressure, flow, and level, this versatile transmitter is equipped with advanced diagnostics and multi-variable capabilities, making it ideal for a wide range of applications across industries like oil & gas, chemical processing, power generation, and water treatment.

With its Emerson Rosemount™ technology, the KJ4001X1-BA2 delivers high-accuracy measurements and is built for reliability in both standard and extreme operating conditions. Its ability to handle multiple measurement types simultaneously in a single device not only simplifies installation and maintenance but also ensures better system integration and data accuracy. This device is also designed for ease of use, offering intuitive diagnostics to help operators quickly identify issues and enhance predictive maintenance efforts.

Technical Specifications

Specification	Details
Model	Emerson KJ4001X1-BA2
Module Type	Intelligent Field Transmitter
Measurement Type	Pressure, Flow, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4-20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.6" x 7.5" x 7.0" (244 mm x 190 mm x 178 mm)
Weight	3.20 kg (7.05 lbs)
Ingress Protection	IP66/IP67
Housing Material	Stainless Steel

Recommended Related Models

For expanded capabilities or different configurations, you may want to consider the following Emerson models:

Emerson KJ4001X1-BA1 – A similar multi-variable transmitter with an emphasis on process efficiency and accuracy, ideal for basic pressure, flow, and level measurements.
Emerson Rosemount 3051 – A multi-variable transmitter with advanced features for pressure, flow, and level, widely used in industries requiring high precision.
Emerson Rosemount 8700 – A non-intrusive flow measurement solution with high accuracy, designed for applications requiring robust performance under harsh conditions.

Popular Emerson Models

Other widely used Emerson transmitters include:

Emerson Rosemount 3051 – Known for multi-variable measurement capabilities, providing reliable and precise measurements for pressure, flow, and level across various industries.
Emerson 1151 – A rugged pressure transmitter designed for ease of installation and reliable performance in general industrial applications.
Emerson Rosemount 2088 – A cost-effective pressure transmitter that provides consistent, reliable performance for routine industrial applications.

Applications

The Emerson KJ4001X1-BA2 is suitable for a wide range of applications:

Oil & Gas: Provides accurate pressure and flow measurements for pipeline monitoring, tank level, and flow rate measurements, ensuring operational efficiency and safety in refineries, offshore platforms, and storage tanks.
Chemical Processing: Essential for monitoring pressure, flow, and level in chemical reactors, distillation columns, and tanks, improving safety, process control, and regulatory compliance.
Power Generation: Used for pressure and flow measurement in boilers, turbines, generators, and cooling towers, the transmitter helps optimize energy consumption and ensures system performance.
Water Treatment: Suitable for flow and level measurements in water treatment plants, ensuring high-quality water output and meeting environmental standards.
Food & Beverage: Provides flow and level measurements in production lines, ensuring product quality, consistency, and compliance with health and safety regulations.

Advantages

High Accuracy: The KJ4001X1-BA2 offers ±0.05% of span accuracy, ensuring precise measurement in critical process applications, where precision and reliability are paramount.
Multi-Variable Measurement: The transmitter can measure pressure, flow, and level simultaneously, allowing for simplified system integration, reduced maintenance, and more efficient monitoring.
Enhanced Diagnostics: Equipped with Emerson Smart Diagnostics, the KJ4001X1-BA2 provides real-time feedback on the health of the transmitter, enabling operators to detect issues early and avoid unplanned downtime.
Rugged Construction: With IP66/IP67 ingress protection, the KJ4001X1-BA2 is designed to withstand harsh industrial environments, including dust, moisture, and chemical exposure, ensuring long-term performance.
Wide Temperature Range: Operating in a temperature range of -40°C to 85°C (-40°F to 185°F), the KJ4001X1-BA2 is suitable for both cold and hot industrial environments.
Flexible Integration: The device supports HART®, FOUNDATION™ fieldbus, and Profibus PA, providing compatibility with various control systems and networks.

Technical FAQs

What types of measurements can the KJ4001X1-BA2 handle?
The KJ4001X1-BA2 is capable of measuring pressure, flow, and level, making it ideal for multi-variable applications in industries such as oil & gas, chemical processing, and power generation.
What is the accuracy of the KJ4001X1-BA2?
The KJ4001X1-BA2 provides an impressive accuracy of ±0.05% of span, ensuring precise measurements for pressure, flow, and level.
Can the KJ4001X1-BA2 be used in harsh environments?
Yes, with IP66/IP67 ingress protection, the KJ4001X1-BA2 is designed for reliable performance in dusty, wet, and chemical environments.
What communication protocols does the KJ4001X1-BA2 support?
The KJ4001X1-BA2 supports HART®, FOUNDATION™ fieldbus, and Profibus PA communication protocols, providing seamless integration with various industrial control systems.
What power supply does the KJ4001X1-BA2 require?
The KJ4001X1-BA2 operates on a 12–42 VDC power supply, making it suitable for a wide range of industrial applications.
How does the KJ4001X1-BA2 improve predictive maintenance?
The Emerson Smart Diagnostics feature provides real-time monitoring of the transmitter’s health, enabling early detection of potential issues, helping to reduce maintenance costs, and minimizing downtime.
Which industries benefit most from the KJ4001X1-BA2?
The KJ4001X1-BA2 is ideal for industries like oil & gas, chemical processing, power generation, water treatment, and food & beverage, where precise measurements and reliable performance are critical.
What is the weight of the KJ4001X1-BA2?
The KJ4001X1-BA2 weighs approximately 3.20 kg (7.05 lbs), making it easy to handle during installation and routine maintenance.
Can the KJ4001X1-BA2 integrate with other Emerson products?
Yes, the KJ4001X1-BA2 is designed to integrate with other Emerson field devices, such as Rosemount™ transmitters, offering a comprehensive solution for process control and automation.
What is the operating temperature range for the KJ4001X1-BA2?
The KJ4001X1-BA2 operates within a temperature range of -40°C to 85°C (-40°F to 185°F), ensuring reliable performance in a variety of industrial environments.
