KJ4006X1-BT1 6 KJ4006X1-BT1 5 KJ4006X1-BT1-2 KJ4006X1-BT1-1

The Emerson KJ4006X1-BT1 Intelligent Field Transmitter is designed for accurate and reliable measurement of pressure, flow, and level in industrial applications. Built with Emerson’s Rosemount™ technology, this transmitter excels in providing high-precision data for process control systems across a range of industries, including oil & gas, chemical processing, power generation, and water treatment.

This multi-variable transmitter not only provides real-time, precise data for pressure, flow, and level but also includes advanced diagnostics that can detect potential issues before they lead to system failures. The KJ4006X1-BT1 is engineered to endure tough industrial environments, with a rugged design and IP66/IP67 protection against dust and moisture, ensuring optimal performance even in harsh conditions.

The KJ4006X1-BT1 integrates seamlessly into existing process control systems, supporting HART®, FOUNDATION™ fieldbus, and Profibus PA communication protocols, offering flexibility for future-proof installations.

Technical Specifications

Specification	Details
Model	Emerson KJ4006X1-BT1
Module Type	Intelligent Field Transmitter
Measurement Type	Pressure, Flow, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4-20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.6" x 7.5" x 7.0" (244 mm x 190 mm x 178 mm)
Weight	3.20 kg (7.05 lbs)
Ingress Protection	IP66/IP67
Housing Material	Stainless Steel

Recommended Related Models

For applications requiring different configurations or additional features, consider these Emerson transmitters:

Emerson KJ4001X1-BT1 – A similar multi-variable transmitter focused on pressure and flow measurement for standard industrial applications.
Emerson Rosemount 3051 – A high-accuracy multi-variable transmitter for pressure, flow, and level applications, ideal for advanced diagnostics and real-time monitoring.
Emerson Rosemount 8700 – A non-intrusive flow measurement solution designed for high-pressure environments, reducing maintenance while offering reliable performance.

Popular Emerson Models

The Emerson KJ4006X1-BT1 is part of a comprehensive range of high-performance transmitters:

Emerson Rosemount 3051 – Known for its precise and multi-variable measurement capabilities, this model is ideal for advanced process control applications.
Emerson 1151 – A dependable pressure transmitter designed for general industrial applications requiring accuracy and reliability.
Emerson Rosemount 2088 – A cost-effective pressure transmitter used in general industrial applications, offering ease of integration and long-term stability.

Applications

The KJ4006X1-BT1 is well-suited for industries that require accurate, real-time data for critical process monitoring:

Oil & Gas: Perfect for wellhead control, pipeline monitoring, and tank level management, where high-precision data ensures safe and efficient operations.
Chemical Processing: Used in reactors, distillation columns, and chemical storage tanks, the KJ4006X1-BT1 ensures accurate measurements to optimize chemical reactions and ensure safety.
Power Generation: Ideal for boilers, turbines, and cooling systems, where precise flow and pressure measurements help optimize energy usage and maintain system efficiency.
Water Treatment: Essential for monitoring flow and level in water treatment plants, ensuring compliance with water quality standards and reducing operational costs.
Food & Beverage: Monitors flow and level in production lines, ensuring consistent product quality while meeting industry safety and regulatory standards.

Advantages

Exceptional Accuracy: The KJ4006X1-BT1 provides ±0.05% of span accuracy for pressure, flow, and level measurements, ensuring precise data collection and reliable process control.
Multi-Variable Measurement: With the ability to measure multiple parameters simultaneously, the KJ4006X1-BT1 reduces the need for multiple devices, streamlining system design and maintenance.
Advanced Diagnostics: Integrated Smart Diagnostics allow for proactive monitoring of the transmitter's performance, enabling predictive maintenance and reducing unplanned downtime.
Durable Construction: Built with an IP66/IP67 ingress protection rating, the KJ4006X1-BT1 is ideal for demanding environments where exposure to dust, moisture, or chemicals is common.
Wide Temperature Range: The KJ4006X1-BT1 operates in temperatures ranging from -40°C to 85°C (-40°F to 185°F), offering flexibility for use in both extreme heat and cold environments.
Seamless Integration: Compatible with HART®, FOUNDATION™ fieldbus, and Profibus PA communication protocols, the KJ4006X1-BT1 can be easily integrated into existing process control systems.

Technical FAQs

What measurements can the KJ4006X1-BT1 provide?
The KJ4006X1-BT1 provides measurements for pressure, flow, and level, allowing for multi-variable data collection in complex industrial processes.
How accurate is the KJ4006X1-BT1?
The KJ4006X1-BT1 offers ±0.05% of span accuracy, ensuring high-precision measurements for critical applications.
What environments can the KJ4006X1-BT1 be used in?
With an IP66/IP67 ingress protection rating, the KJ4006X1-BT1 is designed to perform reliably in dusty, moist, and chemically challenging environments.
What communication protocols are supported?
The KJ4006X1-BT1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA, ensuring flexibility for integration into various control systems.
What power supply does the KJ4006X1-BT1 require?
The KJ4006X1-BT1 operates on a 12–42 VDC power supply, which is standard for industrial transmitters.
Can the KJ4006X1-BT1 help reduce maintenance costs?
Yes, the Smart Diagnostics feature helps identify issues before they become critical, enabling predictive maintenance and reducing downtime and maintenance costs.
Which industries can benefit most from the KJ4006X1-BT1?
The KJ4006X1-BT1 is ideal for industries such as oil & gas, chemical processing, power generation, water treatment, and food & beverage, where reliable, real-time measurements are required for efficient operations.
What is the weight of the KJ4006X1-BT1?
The KJ4006X1-BT1 weighs 3.20 kg (7.05 lbs), which is ideal for ease of handling and installation.
Can the KJ4006X1-BT1 integrate with other Emerson products?
Yes, the KJ4006X1-BT1 is fully compatible with other Emerson devices, including Rosemount™ transmitters, offering a comprehensive solution for process control.
What is the temperature range of the KJ4006X1-BT1?
The KJ4006X1-BT1 operates within a wide temperature range from -40°C to 85°C (-40°F to 185°F), making it suitable for a variety of industrial environments.
