The Emerson KL3102X1-BA1 Intelligent Field Transmitter offers precise and reliable measurement for pressure and level in demanding industrial environments. Combining Emerson's Rosemount™ technology with advanced diagnostics and multi-variable measurement capabilities, this transmitter provides superior performance for a variety of industrial applications, including oil & gas, chemical processing, power generation, and water treatment.

Built to withstand extreme conditions, the KL3102X1-BA1 features IP66/IP67 ingress protection, making it resistant to dust, moisture, and harsh chemicals. It provides multi-variable measurements in one unit, enabling real-time monitoring of both pressure and level, which simplifies installation, reduces system complexity, and lowers overall maintenance costs.

With HART®, FOUNDATION™ fieldbus, and Profibus PA communication protocols, the KL3102X1-BA1 can be easily integrated into modern and legacy control systems. Its advanced diagnostic capabilities help predict maintenance needs, improving operational reliability and minimizing unplanned downtime.

Technical Specifications

Specification	Details
Model	Emerson KL3102X1-BA1
Module Type	Intelligent Field Transmitter
Measurement Type	Pressure, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4-20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.6" x 7.5" x 7.0" (244 mm x 190 mm x 178 mm)
Weight	3.20 kg (7.05 lbs)
Ingress Protection	IP66/IP67
Housing Material	Stainless Steel

Recommended Related Models

For applications that require alternative configurations or additional capabilities, consider the following Emerson models:

Emerson KJ4001X1-BA1 – A multi-variable transmitter for pressure and flow, designed for broad industrial applications requiring flexibility and high performance.
Emerson Rosemount 3051 – Offers multi-variable measurement capabilities for pressure, flow, and level, suitable for critical process control applications in complex systems.
Emerson Rosemount 8700 – A non-intrusive flow transmitter for high-pressure environments, minimizing maintenance needs while providing long-term reliable measurement.

Popular Emerson Models

For industrial measurement solutions in pressure and level, explore these Emerson transmitters:

Emerson Rosemount 3051 – Known for multi-variable measurement and advanced diagnostics, ideal for complex process control systems.
Emerson 1151 – A durable and cost-effective transmitter for pressure measurement in a wide variety of industries.
Emerson Rosemount 2088 – A simple and economical solution for pressure measurements, perfect for less demanding environments.

Applications

The KL3102X1-BA1 Intelligent Field Transmitter is designed for high-accuracy pressure and level measurement in the following industries and applications:

Oil & Gas: Used for monitoring wellhead pressure, pipeline flow, and downhole conditions, ensuring safe operation and optimized production across upstream, midstream, and downstream applications.
Chemical Processing: Measures pressure and level in chemical reactors, distillation columns, and storage tanks, ensuring compliance with safety standards and optimizing production efficiency.
Power Generation: Monitors critical systems such as boilers, turbines, and cooling systems, ensuring safe and efficient operation within power plants.
Water Treatment: Provides level and flow measurements in treatment plants, helping ensure water quality, purification, and regulatory compliance.
Food & Beverage: Monitors level and flow in production lines, ensuring product quality and process consistency while meeting health and safety standards.

Advantages

High Accuracy: The KL3102X1-BA1 provides ±0.05% of span accuracy, offering precise measurements for mission-critical applications.
Multi-Variable Measurement: The KL3102X1-BA1 measures pressure and level simultaneously, simplifying system architecture and reducing the need for additional devices.
Advanced Diagnostics: Integrated Smart Diagnostics allow for continuous monitoring of the transmitter’s performance, helping to identify potential issues before they cause unplanned downtime.
Durability in Harsh Environments: With IP66/IP67 ingress protection, the KL3102X1-BA1 is protected against dust, moisture, and harsh chemicals, making it ideal for tough industrial settings.
Wide Temperature Range: The transmitter operates across a temperature range of -40°C to 85°C (-40°F to 185°F), providing flexibility for use in both extreme heat and cold environments.
Seamless Integration: Supporting HART®, FOUNDATION™ fieldbus, and Profibus PA, the KL3102X1-BA1 can easily integrate into existing control systems, reducing installation and maintenance complexity.
