The Emerson KL3103X1-BA1 Intelligent Field Transmitter is engineered to deliver high-precision pressure and level measurements in demanding industrial environments. Built on Emerson’s Rosemount™ technology, this transmitter is designed to ensure accuracy, reliability, and performance across various applications in industries such as oil & gas, chemical processing, power generation, and water treatment.

With multi-variable measurement capabilities, the KL3103X1-BA1 offers simultaneous pressure and level measurement in one compact unit, reducing complexity and maintenance costs. Its advanced diagnostics help optimize operations by providing real-time health monitoring and predictive maintenance insights, minimizing downtime and enhancing operational efficiency.

The KL3103X1-BA1 features IP66/IP67 ingress protection for durability in harsh environments and supports industry-standard communication protocols like HART®, FOUNDATION™ fieldbus, and Profibus PA, allowing easy integration into existing systems.

Technical Specifications

Specification	Details
Model	Emerson KL3103X1-BA1
Module Type	Intelligent Field Transmitter
Measurement Type	Pressure, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4-20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.6" x 7.5" x 7.0" (244 mm x 190 mm x 178 mm)
Weight	3.20 kg (7.05 lbs)
Ingress Protection	IP66/IP67
Housing Material	Stainless Steel

Recommended Related Models

If you need additional features or alternative configurations, consider these Emerson models:

Emerson KJ4001X1-BA1 – A multi-variable transmitter ideal for measuring pressure and flow, offering advanced functionality for flexible industrial applications.
Emerson Rosemount 3051 – A versatile transmitter providing multi-variable measurement for pressure, flow, and level in critical process control systems.
Emerson Rosemount 8700 – A non-intrusive flow transmitter designed for high-pressure systems, perfect for applications requiring minimal maintenance and maximum reliability.

Popular Emerson Models

For reliable pressure and level measurement, consider these popular Emerson transmitters:

Emerson Rosemount 3051 – Advanced diagnostics and multi-variable measurement capabilities, ideal for a wide range of industrial applications.
Emerson 1151 – A cost-effective solution for pressure measurement, providing reliability in a variety of general industrial applications.
Emerson Rosemount 2088 – A simple, economical transmitter suitable for standard pressure measurements in less demanding environments.

Applications

The KL3103X1-BA1 Intelligent Field Transmitter is designed for high-accuracy pressure and level measurement in the following industries:

Oil & Gas: Measures wellhead pressure, pipeline flow, and downhole conditions, ensuring safe operation and optimized production across upstream, midstream, and downstream operations.
Chemical Processing: Provides precise pressure and level measurements in chemical reactors, distillation columns, and tanks, helping to optimize production and maintain safety standards.
Power Generation: Monitors critical systems such as boilers, turbines, and cooling systems, ensuring the efficient operation of power plants and preventing costly downtime.
Water Treatment: Used to measure level and flow in treatment plants, ensuring efficient water purification and compliance with water quality standards.
Food & Beverage: Provides reliable level measurement in production lines, ensuring consistency and quality while helping to meet strict health and safety regulations.

Advantages

High Accuracy: The KL3103X1-BA1 offers ±0.05% of span accuracy, providing precise measurement for demanding applications where reliability is crucial.
Multi-Variable Measurement: The transmitter measures pressure and level simultaneously, reducing the complexity of installations and minimizing the need for additional devices.
Advanced Diagnostics: Built-in Smart Diagnostics enables continuous monitoring of the transmitter’s health, offering real-time insights for predictive maintenance and preventing unplanned downtime.
Durability: With an IP66/IP67 ingress protection rating, the KL3103X1-BA1 is built to withstand exposure to dust, moisture, and harsh chemicals, making it ideal for rugged industrial environments.
Wide Operating Temperature Range: The KL3103X1-BA1 operates in temperatures ranging from -40°C to 85°C (-40°F to 185°F), allowing it to be used in a variety of environments, from extreme heat to freezing conditions.
Flexible Integration: The transmitter supports HART®, FOUNDATION™ fieldbus, and Profibus PA, ensuring seamless integration into both modern and legacy process control systems.

Technical FAQs

What measurements does the KL3103X1-BA1 provide?
The KL3103X1-BA1 provides simultaneous pressure and level measurements, simplifying industrial process control by offering multi-variable measurement in a single unit.
What is the accuracy of the KL3103X1-BA1?
The KL3103X1-BA1 delivers ±0.05% of span accuracy, ensuring highly precise and reliable measurements in critical industrial applications.
How does the KL3103X1-BA1 contribute to predictive maintenance?
The transmitter features Smart Diagnostics that continuously monitor its performance, helping predict potential issues before they occur, reducing downtime, and extending the transmitter’s operational life.
What industries use the KL3103X1-BA1?
The KL3103X1-BA1 is suitable for industries such as oil & gas, chemical processing, power generation, water treatment, and food & beverage, where high-precision pressure and level measurement is critical.
What communication protocols are supported by the KL3103X1-BA1?
The KL3103X1-BA1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA, ensuring compatibility with modern control systems and seamless integration.
What is the temperature range of the KL3103X1-BA1?
The KL3103X1-BA1 operates in temperatures ranging from -40°C to 85°C (-40°F to 185°F), making it suitable for use in various industrial environments with extreme temperature conditions.
What ingress protection rating does the KL3103X1-BA1 have?
The transmitter has an IP66/IP67 ingress protection rating, making it dust-tight and resistant to moisture and harsh environmental conditions.
What is the weight of the KL3103X1-BA1?
The KL3103X1-BA1 weighs approximately 3.20 kg (7.05 lbs), which makes it easy to handle and install.
What power supply does the KL3103X1-BA1 require?
The transmitter operates with a 12–42 VDC power supply, which is standard for most industrial field transmitters.
How can the KL3103X1-BA1 integrate with existing control systems?
The KL3103X1-BA1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA protocols, allowing for easy integration into both new and existing control systems.
