The Emerson KL3103X1-LS1 Intelligent Field Transmitter is designed to provide highly accurate pressure and level measurements in industrial applications where reliability and precision are paramount. Leveraging Emerson's Rosemount™ technology, the KL3103X1-LS1 integrates advanced diagnostics and multi-variable measurement capabilities in a single, compact unit.

This transmitter is ideal for use in oil & gas, chemical processing, water treatment, and power generation industries, where extreme environments and fluctuating pressures demand robust, real-time data. With its ability to measure both pressure and level simultaneously, it reduces the need for multiple devices and streamlines system design, making it an excellent solution for simplifying complex industrial systems.

Built with IP66/IP67 ingress protection, the KL3103X1-LS1 offers reliable performance in harsh conditions, including moisture, dust, and chemical exposure. Its advanced diagnostics enable predictive maintenance, ensuring high uptime and operational efficiency.

Technical Specifications

Specification	Details
Model	Emerson KL3103X1-LS1
Module Type	Intelligent Field Transmitter
Measurement Type	Pressure, Level
Communication Protocol	HART®, FOUNDATION™ fieldbus, Profibus PA
Output Signal	4-20 mA, Digital (HART)
Accuracy	±0.05% of Span
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Power Supply	12–42 VDC
Dimensions	9.6" x 7.5" x 7.0" (244 mm x 190 mm x 178 mm)
Weight	3.20 kg (7.05 lbs)
Ingress Protection	IP66/IP67
Housing Material	Stainless Steel

Recommended Related Models

If you need additional features or alternative configurations, consider these Emerson models:

Emerson KJ4001X1-BA1 – A multi-variable transmitter ideal for pressure and flow measurements across industrial systems.
Emerson Rosemount 3051 – A multi-variable solution providing precise pressure, flow, and level measurements for process control in complex industrial setups.
Emerson Rosemount 8700 – A non-intrusive flow transmitter designed for high-pressure systems, offering ease of installation and minimal maintenance.

Popular Emerson Models

For accurate and reliable pressure and level measurement, the following Emerson models are commonly used:

Emerson Rosemount 3051 – Known for its multi-variable measurement and advanced diagnostics, perfect for controlling critical processes in industrial settings.
Emerson 1151 – A cost-effective solution for pressure measurement in a wide range of industries, ensuring reliable performance in simple applications.
Emerson Rosemount 2088 – A simple, economical transmitter designed for pressure measurements in less demanding environments.

Applications

The KL3103X1-LS1 Intelligent Field Transmitter is suitable for use in a wide variety of industries that require accurate pressure and level measurements:

Oil & Gas: Measures wellhead pressure, pipeline flow, and downhole conditions to ensure safe, efficient operation of upstream, midstream, and downstream systems.
Chemical Processing: Provides pressure and level measurements in chemical reactors, distillation columns, and storage tanks, helping to optimize chemical production and ensure safety.
Power Generation: Measures critical parameters such as boiler pressure, turbine performance, and cooling system levels, helping maintain efficient operation in power plants.
Water Treatment: Monitors water levels and pressure across treatment plants, ensuring efficient water purification and compliance with regulatory standards.
Food & Beverage: Monitors level and pressure in production lines, ensuring quality control and meeting strict regulatory guidelines.

Advantages

High Accuracy: The KL3103X1-LS1 offers ±0.05% of span accuracy, providing highly reliable measurements for critical industrial applications.
Multi-Variable Measurement: The transmitter measures both pressure and level simultaneously, simplifying installation and reducing the need for additional devices, resulting in lower overall system costs.
Advanced Diagnostics: Integrated Smart Diagnostics enable continuous monitoring of the transmitter’s health, offering predictive maintenance insights and minimizing unplanned downtime.
Durability in Harsh Environments: With IP66/IP67 ingress protection, the KL3103X1-LS1 is protected from dust, moisture, and harsh chemicals, making it ideal for challenging industrial conditions.
Wide Temperature Range: The KL3103X1-LS1 operates in a temperature range from -40°C to 85°C (-40°F to 185°F), making it suitable for use in both extreme cold and high-temperature environments.
Flexible Integration: Supporting HART®, FOUNDATION™ fieldbus, and Profibus PA, the KL3103X1-LS1 can be easily integrated into existing or new control systems, enhancing system flexibility.

Technical FAQs

What types of measurements can the KL3103X1-LS1 provide?
The KL3103X1-LS1 can measure both pressure and level, offering multi-variable measurement in one device, simplifying system design and reducing costs.
What is the accuracy of the KL3103X1-LS1?
The KL3103X1-LS1 delivers ±0.05% of span accuracy, ensuring high precision and reliable performance for demanding industrial applications.
How does the KL3103X1-LS1 help with predictive maintenance?
With Smart Diagnostics, the KL3103X1-LS1 continuously monitors the transmitter’s performance, providing predictive maintenance insights to prevent unplanned downtime and extend the life of the equipment.
In which industries can the KL3103X1-LS1 be used?
The KL3103X1-LS1 is ideal for industries such as oil & gas, chemical processing, power generation, water treatment, and food & beverage, where precise pressure and level measurements are critical for optimizing processes.
What communication protocols are supported by the KL3103X1-LS1?
The transmitter supports HART®, FOUNDATION™ fieldbus, and Profibus PA, providing flexibility and easy integration into a wide variety of control systems.
What is the operating temperature range of the KL3103X1-LS1?
The KL3103X1-LS1 operates between -40°C to 85°C (-40°F to 185°F), making it suitable for use in a broad range of environments, from freezing to high heat conditions.
What ingress protection rating does the KL3103X1-LS1 have?
The KL3103X1-LS1 has an IP66/IP67 ingress protection rating, ensuring it is dust-tight and protected from moisture and chemical exposure in challenging environments.
What is the weight of the KL3103X1-LS1?
The KL3103X1-LS1 weighs approximately 3.20 kg (7.05 lbs), making it easy to handle and install during setup and maintenance.
What power supply is required for the KL3103X1-LS1?
The KL3103X1-LS1 operates on a 12–42 VDC power supply, which is standard for most industrial field transmitters.
How does the KL3103X1-LS1 integrate into control systems?
The KL3103X1-LS1 supports HART®, FOUNDATION™ fieldbus, and Profibus PA, ensuring compatibility with both modern and legacy process control systems.
