The GE IC693CBL315 is a dedicated I/O interface cable for GE Fanuc Series 90‑30 PLC systems, designed to connect high‑density 32‑point I/O modules to field wiring or terminal blocks. It’s widely used in industrial automation to provide dependable signal connection between PLC I/O modules and external devices or junction points. Although an older design, it remains compatible with many legacy 90‑30 high‑density modules.
Technical Specifications (mm)
| Specification | Details |
|---|---|
| Product Type | I/O Interface Cable |
| PLC Platform | GE Fanuc Series 90‑30 |
| Function | Connects 24‑pin high‑density I/O modules to field wiring |
| Connector Type | Fujitsu‑style 24‑pin straight connector |
| Cable Length | 3000 mm (10 feet) |
| Connector Dimensions (approx.) | 68 × 12 × 34 mm (24‑pin connector housing) |
| Cable Jacket | Industrial‑grade flexible PVC |
| Shielding | Yes, braided shield for EMI protection |
| Conductor Size | Approx. 28 AWG (signal conductors) |
| Operating Temperature | –20°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Weight | Approx. 900 g (2.0 lbs) |
| Typical Use | High‑density 32‑point I/O module interfacing |
Recommended Related Models
The IC693CBL315 is typically paired with:
-
IC693MDL654 / IC693MDL655 – 32‑point high‑density digital I/O modules
-
IC693MDL752 / IC693MDL753 – Alternate high‑density digital I/O modules
-
IC693CBL327 / IC693CBL328 – Right‑angle replacement cables for tighter panel space
-
IC693CBK001–CBK003 – Backplane kits for structured rack configurations
These components help build robust control systems with modular I/O expansion.
Popular GE PLC Models
This cable is commonly used in systems with:
-
IC693CPU350 – Core Series 90‑30 CPU
-
IC693CPU363 / IC693CPU374 – Higher‑capacity CPUs
-
IC693ALG / IC693ADC / IC693ACC series – Analog and accessory modules
It remains relevant in installations where high‑density discrete I/O is present.
