ABB 5SHY4045L0006 Power Supply Module

Introduction

The ABB 5SHY4045L0006 is a highly reliable and energy-efficient power supply module, specifically designed to provide 24 VDC power for various industrial automation applications. This module ensures a steady power supply for control systems, sensors, actuators, and other critical components, playing a vital role in maintaining the smooth operation of industrial processes. With its robust design, advanced protection features, and high efficiency, the 5SHY4045L0006 is ideal for demanding environments, ensuring both reliability and performance in harsh industrial conditions. It is widely used in manufacturing, power generation, process control, and telecommunications.

Technical Specifications

Specification	Details
Model	5SHY4045L0006
Module Type	Power Supply Module
Input Voltage	380-480 VAC
Output Voltage	24 VDC
Output Current	40 A
Size (W x H x D)	180 x 120 x 65 mm
Weight	1.5 kg
Mounting Type	DIN Rail
Efficiency	> 90%
Operating Temperature	-20°C to +60°C
Certifications	CE, UL, RoHS

Recommended Related Models

Model	Module Type	Input Voltage	Output Voltage	Output Current
ABB 5SHY4046L0006	Power Supply Module	380-480 VAC	24 VDC	40 A
ABB 5SHY4045L0005	Power Supply Module	380-480 VAC	24 VDC	35 A
ABB 5SHY4045L0007	Power Supply Module	380-480 VAC	24 VDC	45 A

Popular ABB Models

Model	Module Type	Input Voltage	Output Voltage	Output Current
ABB 5SHY3505L0006	Power Supply Module	380-480 VAC	24 VDC	10 A
ABB 5SHY3525L0006	Power Supply Module	380-480 VAC	24 VDC	15 A
ABB 5SHY3545L0006	Power Supply Module	380-480 VAC	24 VDC	20 A

Applications

Advantages

Technical FAQs

What is the input voltage for the ABB 5SHY4045L0006 power supply module?
The input voltage is 380-480 VAC.

What is the output voltage provided by the ABB 5SHY4045L0006 module?
The output voltage is 24 VDC.

What is the output current capacity of the ABB 5SHY4045L0006?
The output current capacity is 40 A.

What are the dimensions of the ABB 5SHY4045L0006 module?
The module measures 180 x 120 x 65 mm.

What is the weight of the ABB 5SHY4045L0006 module?
The weight is 1.5 kg.

What is the efficiency of the ABB 5SHY4045L0006 module?
The module has an efficiency greater than 90%.

What is the operating temperature range for the ABB 5SHY4045L0006 module?
The module operates within a temperature range of -20°C to +60°C.

How is the ABB 5SHY4045L0006 module mounted?
The module is designed for DIN rail mounting.

Is the ABB 5SHY4045L0006 module certified for global standards?
Yes, it is CE, UL, and RoHS certified.

Can the ABB 5SHY4045L0006 module be used in process control applications?
Yes, it is ideal for use in process control systems, providing reliable power to ensure consistent operations in industries such as chemicals, pharmaceuticals, and food processing.
