Brand:GE Fanuc PLC Item No.:DS3800XTFP1E1C Product Origin:USA Product Dimensions:90 × 90 × 15 mm Product Weight:0.109 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE Fanuc DS3800XTFP1E1C Thyristor Fan-out Board is a precision-engineered module designed to distribute a single thyristor control signal to multiple outputs. Ideal for turbine, generator, and industrial process automation, it provides efficient signal routing while maintaining high-speed switching and reliability. Its compact and robust construction ensures seamless integration in DS3800 series control systems, supporting continuous industrial operation.
Technical Specifications
Parameter
Specification
Product Type
Thyristor Fan-out Board
Manufacturer
GE Fanuc
Model Number
DS3800XTFP1E1C
Function
Distribute thyristor control signals to multiple outputs
System Compatibility
GE DS3800 series control systems
Mounting
Control cabinet or rack
Operating Environment
Industrial automation, turbine and generator control
Dimensions
90 × 90 × 15 mm
Weight
0.109 kg
Recommended Related Models
Model
Description
GE Fanuc DS3800XTFP1E1B
Thyristor Fan-out Board Variant
GE Fanuc DS3800XTFP1E2C
Fan-out Board for DS3800 Control
GE Fanuc DS3800VAIC1C
Analog Input Board
GE Fanuc DS3800TBCIH1C
Terminal Board
Popular Related Models
Model
Description
GE Fanuc DS3800XTFP1E1A
Thyristor Fan-out Board
GE Fanuc DS3800XTFP2E1C
High-Capacity Fan-out Board
GE Fanuc DS3800VAICH1D
Analog Input Board
GE Fanuc DS3800ISBEH1A
Synchronous Bus Expansion Board
GE Fanuc DS3800DSPXH1A
Digital Signal Processor Board
Typical Applications
Distributing thyristor control signals to multiple load devices in industrial automation
Integration with GE DS3800 series turbine and generator control systems
Power control for excitation systems, drives, and rectifier circuits
Industrial process control requiring high-speed switching and signal routing
Expansion of digital power distribution networks in control cabinets
Key Advantages
Efficient Signal Distribution – Fan-out design allows a single thyristor signal to drive multiple outputs reliably.
Compact Industrial Design – Small footprint ensures easy integration in control cabinets.
High-Speed Switching – Supports precise and rapid thyristor control applications.
Seamless GE Integration – Compatible with DS3800 series control and automation systems.
Robust and Reliable – Engineered for continuous operation under industrial conditions.
Technical FAQs
1. What is the function of the DS3800XTFP1E1C board?
It fans out a thyristor control signal to multiple outputs, enabling simultaneous device control.
2. Where is this board typically installed?
Inside industrial control cabinets as part of GE DS3800 turbine and generator control systems.
3. Can it handle multiple load devices simultaneously?
Yes, the fan-out design distributes the input signal efficiently to multiple devices.
4. Is it suitable for high-speed switching applications?
Yes, it is designed to handle rapid thyristor control without signal degradation.
5. Does it integrate with DS3800 series control systems?
Yes, it is specifically engineered for DS3800 turbine and industrial automation platforms.
6. Can it operate reliably in industrial environments?
Yes, it is built for continuous operation under vibration, temperature variations, and mechanical stress.
7. How is the board mounted?
It installs inside standard control cabinets, typically on a rack or mounting panel.
8. Does it improve system reliability?
Yes, by distributing control signals accurately, it ensures consistent operation of connected devices.
9. Can it be used for predictive maintenance systems?
Indirectly, yes—by ensuring stable thyristor control, it helps maintain system performance and avoids faults.
10. Is replacement or maintenance straightforward?
Yes, the compact design allows quick replacement without disrupting other modules.
